NX-5610-24F8G
Core Aggregation Switch
Product Guide
Statement of Copyright
Nodexon Networks©2021
All copyrights in this document are reserved by Nodexon Networks. Without Nodexon Networks'
prior written approval, any reproduction, excerption, backup, modification, transmission,
translation, or commercial use of this document or any portion of this document, in any form or by
any means, is forbidden.
Statement of Exemption
This material is being distributed "as is." This document's contents are subject to change at any
time without notice. Please visit the Nodexon Networks website for the most up-to-date
information. Nodexon Networks makes every effort to guarantee content accuracy, but cannot be
held liable for any losses or damages incurred as a result of content omissions, inaccuracies, or
mistakes.
Preface
Thank you for using our products. This manual will guide you through the installation of the device.
This manual describes the functional and physical features and provides the device installation
steps, hardware troubleshooting, module technical specifications, and specifications and usage
guidelines for cables and connectors.
The product user's manual mainly introduces the software
and hardware parameters, installation method and matters needing attention in the installation
process of
NX-5610-24F8G
switch.
Audience
It is intended for the users who have some experience in installing and maintaining network
hardware. At the same time, it is assumed that the users are already familiar with the related terms
and concepts
Obtaining Technical Assistance
Website:https://www.nodexon.com/
Technical Support Website:https://nodexon.com/support
Community:http://www.nodexon.com/community
Case Portal :https://www.nodexon.com/caseportal
Website:https://www.nodexon.com/
This Manual Includes The Following Chapters
Chapter 1: product introduction. Describe the basic functional characteristics of the switch, detailed
hardware and software specifications and appearance information.
Chapter 2: hardware connectivity. Instruct the connection between switch and other equipment
and matters needing
attention.
Chapter 3: product installation. Instruct switch hardware installation method and matters needing
attention.
Chapter 4: product packaging and usage recommendations.
Chapter 1 product introduction
1.1 product introduction
The NX-5610-24F8G three-tier, stackable administrative switch is designed for small and medium
enterprises (SMEs), large enterprises and Internet service providers (ISPs). They offer high
performance, flexibility, fault tolerance, and advanced software capabilities to achieve maximum
return on investment. NX-5610-24F8G switches with gigabit Ethernet RJ45 and SFP ports, 10G SFP+
ports, advanced security features and advanced quality of service (QoS), can be used as core,
distribution or access layer switches, with high-end port density, switch stack and easy
management, is an ideal choice for all kinds of commercial
network applications.
1. 2 Product features
Full gigabit port full gigabit RJ45 Combo ports, 4 10 gigabit SFP optical fiber ports, 24 gigabit SFP
ports, breaking the traditional 100 MB limit, data transmission does not slow down
Broadcom high-end chip, performance is more stable and strong
Broadcom's high-end chips can greatly improve the speed of network data processing
Support stacked function
Support physical stack of 9 switches, virtual stack of 32 switches, support ring/Daisy chain stack link
Support Apollo cloud platform one-stop management
Support the cloud platform to visually manage the resources of switches and PD devices, making
operation and maintenance management simpler
1.3 Product software and hardware technical specifications
Hardware
Chip
Broadcom high performance chip
Flash
16MB
storage
256MB DDR
Port
8 10/100/1000Mbps RJ45 ports (Combo）
4 10G SFP ports
24 Gigabit SFP ports
1 RJ45 Console port，1 10/100/1000Mbps
management RJ45 port
1 USB 2.0,1 Mini-usb Console port
performance
Forward mode: store and forward
Back width：128Gbps
Rate：96Mpps
Support 16K MAC
Thunder Proof
±6KV
ESD
touch：±6KV air：±8KV
Input
100-240V/50-60Hz
Size (L×W×H）
440mm×320mm×44mm
Software Features
Route
Support RIP V1/V2, OSPFv1\OSPFv2dynamic
routing
Support static route
DHCP
Support DHCP Service
Support DHCP Relay
Support DHCP Snooping
VLAN
Support 4K VLAN
Support 802.1Q VLAN MAC VLAN, IP VLAN
Voice VLAN
MAC List
Follow IEEE 802.1d standard
Support MAC Address automatic learning
and aging
Support static, dynamic, filter address table
Safety performance
password protection
Support user access restrictions based on
port number, IP address, MAC address
Support HTTPS、SSL V3、TLS V1、SSH
V1/V2
Support IP-MAC-PORT 3 in one
Support ARP protect, IP protect, DoS
protect
Support DHCP Snooping, DHCP attack
protect
Support 802.1X AC, AAA
Support port security and port isolation
Support CPU protect function
Support L2(Layer 2)-L4(Layer 4)Packet
ACL
filtering function
Support port mirroring, port redirection,
flow speed limit, QoS remarking
QoS
Supports 8 port queues
Support port priority, 802.1p priority, DSCP
priority
Support SP, WRR, WFQ priority scheduling
algorithm
Support automatic identification,
management and acquisition of information
Tree
Support STP(IEEE 802.1d)，RSTP(IEEE
802.1w) and MSTP(IEEE 802.1s)standard
Support loop protection, root bridge protection, TC protection,
BPDU protection,
BPDU filtering
Multicast
Support IGMP v1/v2 Snooping
Support for quick exit mechanism
Support Multicast VLAN
Supports multicast filtering, message
statistics and unknown multicast discarding
Storm
Control
Support multicast control
Support broadcast control
Support Unknown unicast control
Link
Together
Support static aggregation
Support dynamic convergence
Support IP, MAC, mixed load balancing
mode
Maximum support is 32 aggregation groups
IPv6
Support IPv6 Ping、IPv6 Tracert、IPv6 Telnet
Support IPv6 SSH 、IPv6 SSL
Support WEB Management (HTTP、
HTTPS、SSL V3）
Support CLI (Telnet,SSH V1/V2, Local
port）
Support SNMP V1/V2/V3
Manage and
Support LLDP、RMON
Maintain
Support ARP protect IP protect bDoS
protect
Support Apollo
Support CPU monitoring 、Storage
monitoring
Support system log, grading warning
Support Ping. Tracert test, line test
1.4 Product appearance
The front panel
Contains indicator light, RJ45 port, SFP port, CONSOLE port & USB port
PWR
Power
light
red
on
Power normal
off
Power out, power switch
not open, power abnormal
LINK/AC
T
Device
connect
light
green
flicker
The corresponding RJ45
port is connected
off
The corresponding RJ45
port is unconnected
SYS
System
light
green
flicker
System working normal
off
System working
abnormally, System
damaged
XG
SFP
light
green
flicker
The corresponding RJ45
port is unconnected
