NKE Gyropilot Graphic Manuel

nke - Sailing competition

Z.I. Kerandré –Rue Gutenberg –56700 HENNEBONT- FRANCE

http://www.nke.fr –tel : +33 (0) 297 365 685.

Multifonction

Gyropilot Graphic

Command interface of the GYROPILOT 2

Product reference: 90-60-348 white / 90-60-352 carbon

USER GUIDE

and

INSTALLATION GUIDE

REV 4

- 2 - Gyropilot Graphic user guide –33-60-025-003 rev3

TABLE OF CONTENT

1. USING THE GYROPILOT GRAPHIC IN PILOT MODE .......................................................4

1.1 PRESENTATION.................................................................................................................4

1.2 GENERAL OPERATION OF THE GYROPILOT GRAPHIC.............................................................6

1.3 FUNCTIONS OF THE KEYS OF GYROPILOT GRAPHIC DISPLAY.................................................7

1.4 FIRST STARTUP OF THE PILOT.............................................................................................8

1.5 DESCRIPTION OF THE FIVE OPERATING MODES...................................................................10

1.6 PILOT SETTING MENU:OPTIMISING THE PERFORMANCES OF THE PILOT ................................15

1.7 PROTECT YOUR SETTINGS WITH A OWNER CODE ................................................................19

1.8 PERFORMING A TACKING OR JIBING MANOEUVRE UNDER PILOT CONTROL .............................20

1.9 LIGHTING SETTING...........................................................................................................20

1.10 SETTING THE ALARMS OF THE PILOT...............................................................................22

1.11 OPERATION OF THE GYROPILOT IN DEGRADED MODE...................................................23

1.12 « MAN OVER BOARD » FUNCTION.............................................................................23

1.13 POWER CONSUMPTION OF THE GYROPILOT ................................................................24

2. USING THE GYROPILOT GRAPHIC IN MULTIFUNCTION DISPLAY MODE..................25

2.1 CONFIGURE YOUR DISPLAY FOR THE DISPLAY OF 1, 2, 3OR 4CHANNELS. ............................25

2.2 LIST OF CHANNELS CREATED............................................................................................26

2.3 CONFIGURING THE DISPLAY OF THE CHANNELS ..................................................................27

2.4 DISPLAY CONFIGURATIONS BACKUP AND RESTORE.............................................................27

2.5 WHAT IS A SUB-CHANNEL?...............................................................................................28

2.6 ALARMS SETTING FOR THE CHANNELS OF TOPLINE INSTRUMENTS.....................................28

2.7 FILTERING (DAMPING)OF THE CHANNELS...........................................................................30

2.8 CHOICE OF THE UNIT .......................................................................................................30

2.9 ZERO SETTING OF THE DAY TRIP AND TOTAL TRIP ...............................................................31

2.10 CHOICE OF LANGUAGES................................................................................................32

2.11 USE OF THE RACE TIMER..............................................................................................32

2.12 NMEA LINK...............................................................................................................33

2.13 THE NMEA CONSOLE:A TOOL TO VISUALISE THE NMEA FRAMES....................................35

2.14 TECHNICAL SPECIFICATIONS .........................................................................................35

2.15 VERSION OF THE GYROPILOT GRAPHIC...................................................................35

2.16 DIAGNOSTIC FOR 1ST LEVEL TROUBLES SHOOTING...........................................................36

2.17 INITIALIZATION OF THE GYROPILOT GRAPHIC:SEE CHAPTER 4.6.......................................36

3. SENSOR CALIBRATION ...................................................................................................37

3.1 SETTING PROCEDURE OF THE CALIBRATION COEFFICIENT ...................................................37

3.2 OFFSET SETTING.............................................................................................................38

3.3 AUTOCOMPENSATION OF THE FLUXGATE COMPASS ............................................................38

3.4 SETTING THE DEPTH-FINDER BLANKING .............................................................................39

4. CALIBRATION UTILITIES..................................................................................................40

4.1 OBTAINING THE KEY NUMBER OF YOUR GYROPILOT GRAPHIC ENTERING THE « CALIBRATION

UTILITIES »CODE ......................................................................................................................40

4.2 AUTOMATIC CALIBRATION OF BOAT SPEED .........................................................................41

4.3 CALIBRATION OF THE NKE COMPASS BASED ON THE CORRECTION TABLE..............................43

- 3 - Gyropilot Graphic user guide –33-60-025-003 rev3

4.4 CALIBRATION OF APPARENT WIND ANGLE...........................................................................46

5. INSTALLATION..................................................................................................................48

5.1 PACKING LIST..................................................................................................................48

5.2 LIST OF ACCESSORIES .....................................................................................................48

5.3 INSTALLATION PRECAUTIONS............................................................................................49

5.4 WALL MOUNTING.............................................................................................................49

5.5 CONNECTION TO THE TOPLINE BUS AND TO THE NMEA BUS ...............................................51

5.6 INITIALIZATION OF THE GYROPILOT GRAPHIC .....................................................................52

5.7 INITIALIZATION OF THE PILOT INSTALLATION........................................................................53

- 4 - Gyropilot Graphic user guide –33-60-025-003 rev3

1. USING THE GYROPILOT GRAPHIC IN PILOT MODE

1.1 Presentation

We thank you for your confidence in the nke trademark, by choosing the Gyropilot Graphic.

You have just acquired a pilot command, identical to that which is fitted on sailing boats of

ocean skippers: Vendée Globe, Route du Rhum and Transat the single handed

raicing.

The nke pilot includes:

-the Gyropilot Graphic, it is the user interface. It allows to control the pilot and adjust the

settings,

-the Gyropilot 2 calculator, which is the brain of the pilot,

-the hydraulic unit or electrical unit, which provides the power to actuate the boat’s rudder,

-the sensors, which provide the information on the boat’s behaviour and external parameters.

Depending on the level of equipment of your installation, you will find: the fluxgate

compass, the speedometer, a rudder angle sensor, a masthead unit (optional for wind

mode) and the gyro sensor (integrated in the calculator).

This user and installation guide includes information that will allow you to:

-to be able to set up the Gyropilot 2 computer and the sensors,

-To become accustomed to your Gyropilot Graphic, and to master all its functions,

-carry out the installation,

-achieve optimum performances with your autopilot and your boat.

The Gyropilot Graphic is also a Multifunction display. Its graphic screen offers a wide range

of display options:

-A detailed representation of the Gyropilot 2 control parameters.

-A Multifunction that is easily displayed, for screen display of 1, 2, 3 or 4 channels.

-A pull-down menu, which indicates the settings and configurations in full.

PILOT page MENU page Multifunction page

True wind mode G5

Reference True wind

Rudder angle

-10 10

-30° -30°

Main menu

Piloting mode

Pilot setting

Screen Page

Alarm

Unite

Configuration

Filtering

ENT

Unit

ENT

Boat spped k

nots

20.50

True wind ag

degrees

70°

- 5 - Gyropilot Graphic user guide –33-60-025-003 rev3

Architecture of the installation

The presence of the equipment in the following diagram is for information only, and does not

represent the equipment of your installation.

nke Gyrop

lot 2

CRP

RVP

Calculateur Gyro2

Bus Angle

Barre Tiller Embrayage Alim.

Pompe

réversible

TOPLINE cable

20-61-001

GND

DATA black

12VDC white

Figure 1

log depth interface

90-60-450

log

speedometer depth

Connecting box

90-60-417

NMEA -

NMEA +

Input NMEA

Auto

Stop

Page

Ent

True wind mode G5

Reference True wind

Rudder angle

-10 10

-30° -30°

Gyropilot Graphic

nke

Helm spindle

Rudder angle

hydraulic ram

Anemovane

- 6 - Gyropilot Graphic user guide –33-60-025-003 rev3

1.2 General operation of the Gyropilot Graphic

The Gyropilot Graphic display is designed to control your pilot and your system. The

performance of the Gyropilot is excellent at any sailing speed. It will assist the helmsman

effectively, but must not be used as the primary means to navigate.

When the helmsman activates the pilot, the Gyropilot 2 computer stores the current value of

the channel concerned: magnetic heading, wind angle or GPS course. This value becomes

the reference point.

Then, the computer integrates the data transmitted by the sensors and performs rudder

corrections according to two criteria:

- the cross-track error compared to the reference point, which is provided by the fluxgate

compass (compass mode) or by the masthead unit (wind mode).

- the speed of rotation of the boat, which is provided by the gyro sensor. This rotation is caused

by the action of the rudder, the wind or the waves.

Hence the correction value is proportional to:

the cross-track error measured,

the gain value,

and inversely proportional to the speed of the boat.

CAUTION:

Never leave the helm without supervision. The helmsman must remain watchful and

attentive to the sudden events that can occur while the autopilot is operating. He must be

ready to retake control of the rudder at any moment.

- 7 - Gyropilot Graphic user guide –33-60-025-003 rev3

1.3 Functions of the keys of Gyropilot Graphic Display



Page

key

Pressing this key allows you to select the pilot page, the multifunction display page or the

menu page.

It also allows to leave the setting menus, without performing a backup.



Ent

key

Press this key to accept your changes. It also allows to enter a menu.

The browser

In the pilot page:

-the ◄1and 1► keys allow to increase or decrease the setting by 1°.

-the ▲ and ▼ keys allow to adjust the Gyropilot GAIN.

In the Multifunction display page :

-the ▲ and ▼ keys allow to select the display row you wish to modify.

-the ◄1and 1► keys allow to change the channel on display.

In the menus page:

-the ◄1and 1► keys allow to enter or exit a menu.

-the ▲ and ▼ keys allow to select a menu or parameter in a list.



Auto

key

Press this key to engage the Gyropilot.



Stop

key

Press this key to disengage the Gyropilot.



key (red colour)

This key allows to decrease the set point by 10° on port side.



key (green colour)

This key allows to increase the set point by 10° on starboard side.

Man Over Board

Mob

key

Press this key for 5 seconds, and the « Man over board » function is enabled.

- 8 - Gyropilot Graphic user guide –33-60-025-003 rev3

1.4 First startup of the pilot

This first part of the guide explains how to use the Gyropilot Graphic, on the basis that it is

installed and initialised. If that is not the case please refer to the installation chapter of this

guide.

The Gyropilot Graphic, delivered with a factory setup configuration, will achieve a good level

of performance on the majority of boats. This setup configuration is called « initial setup», and

is saved in the Config restore menu. You can restore this initial setup at all times (see chapter

1.7.7).

Powering up or powering down your installation is done using the auxiliary switch of the electric

switchboard of your boat. Your installation must comprise two separate 12V power supplies:

one for power to the hydraulic pump and to the computer and the other for the Gyropilot

Graphic, the TOPLINE bus and the sensors. If it is not possible to have 2 batteries pack you

must set up a converter 12V/12V.

1.4.1 Procedure for the use of the Gyropilot in compass mode

-reach the open sea with your boat before engaging your pilot,

-steer your boat and maintain the heading you wish to follow : the rudder must be in line with

the axis of the boat,

-when you follow the right heading, press the auto key to engage the Gyropilot.

-the pilot then takes the current heading as reference. The Gyropilot is then engaged and

steers the boat.

-to disengage the Gyropilot, retake hold of the helm and press the stop key.

The Pilot Page below is displayed on the Gyropilot Graphic screen.

Note that when the pilot is engaged, the set point is displayed in the reference window. When

the pilot is disengaged, three dashes «---» are displayed in this window.

CAUTION:

The Auto key will engage the automatic pilot, i.e. to activate it.

The Stop key disengages the automatic pilot, i.e. to deactivate it.

Before cutting the power supply of your installation, disengage the pilot.

CAUTION: It is imperative to power up your Gyropilot computer before the TOPLINE bus.

Operating mode

Gain

Current value of the sensor

(depending on the pilot mode)

Channel associated to the

pilot mode

reference displayed if

the pilot is engaged

Rudder angle graph

Compass

Reference compass h

Rudder angle

-10 10

-20-30 30

270° 271°

Gain 5

- 9 - Gyropilot Graphic user guide –33-60-025-003 rev3

1.4.2 Adjusting the pilot setting

If you wish to modify the heading the pilot is set to follow, you can adjust the Gyropilot

reference point at any time without disengaging the pilot. Use the keys below to adjust the

reference point

-The

key allows to decrease the reference point by 10° on port side.

-The

key allows to increase the reference point by 10° on starboard side.

-The ◄1and 1► keys allow to increase or decrease the setting by 1°.

1.4.3 Setting the pilot gain

The Gain setting is essential for good operation of the pilot. This parameter sets the reactivity of

the rudder and determines the amount of rudder movement. The gain calculation takes into

account the boat speed and is inversely proportional to that speed. Indeed, the higher the boat

speed, the lower the rudder angle.

We recommend that you set the Gain value to adapt the performances of the Gyropilot,

according to the sailing conditions and the speed of the boat.

The Gain can be set between 1and 9, here are some examples of setting :

-At close-haul, calm sea, constant wind: Gain = from 1 to 5.

-At close-haul, rough sea, variable wind: Gain = 4 to 8.

-Beam wind, rolling sea: Gain = 5 to 9.

Keys for fast access to GAIN setting

-Display the Pilot Page,

-using the ▲ and ▼ keys, set the new Gain value,

-press the

Ent

key to validate your setting : the new Gain is saved to the memory.

Useful tip: Before engaging the pilot, set the gain to 7. Steer your boat and maintain the

heading you wish to follow. Then, position the rudder in the centre, at the exact time when you

press the AUTO key. The pilot will thus take control of the rudder in the best conditions. Then,

reduce the gain to optimise the power consumption.

IMPORTANT:

The Gyropilot uses very little energy (a few tens of milliamps) when the pilot is

disengaged. Hence when you are sailing and the pilot is disengaged, it is not necessary to

cut off the power supply of the pilot to save energy.

- 10 - Gyropilot Graphic user guide –33-60-025-003 rev3

1.5 Description of the five operating modes

The Gyropilot Graphic has five operating modes: compass mode, apparent wind mode, true

wind mode (in option), GPS mode and rudder mode. The choice of one of these five modes

allows you, depending on the sailing conditions, to make the most of the performances of the

nke pilot.

These five modes will be accessible on the Gyropilot Graphic depending on the level of your

installation:

-The compass mode requires a speedometer log sensor and a compass sensor.

-The apparent wind mode requires a speedometer log sensor, a compass sensor and an

masthead unit.

-The true wind mode requires a speedometer log sensor, a compass sensor, a masthead

unit, and a « true wind » software option.

-The GPS mode requires a speedometer log sensor, a compass sensor, as well as a GPS, or

any other instrument providing GPS NMEA frames. The latter must be connected to the

NMEA input of your nke installation.

-Rudder mode: no sensor required.

1.5.1 Selecting the pilot mode

-your pilot is disengaged,

-press the Page key to select the main menu,

-using the browser

, enter the Pilot Mode menu,

-select the Pilot mode of your choice,

-press the Ent key to validate your selection : the new pilot mode is saved to the memory.

CAUTION:

If you are sailing in wind mode and you wish to change sail, we recommend that you

switch to compass mode before performing the manoeuvre, because a sudden ship

imbalance can cause the pilot to operate abnormally for a short period of time. For safety

reasons, stay alert.

Gps

Menu: Pilot Mode

Compass

Apparent wind

True wind

Helm

Menu : main

Pilot Mode

Pilot Setting

Screen Page

Alarms

Unit

Filtering

ENT

Configuration

Table des matières

Autres manuels NKE Moniteur

NKE

NKE TL25 Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
