SMS Commands without APP use
Incase if you do not have Android phone, you can send all remote SMS commands by simple text message to your
camera SIM number. Below is the list of different commands:
Mounting of the Camera
This camera is designed to use the Nylon mounting strap (included) to obtain maximal mounting versatility.
It is recommended to mount the camera 1m – 1.5m height pointing to desired area. Distance about 5m away from target
center area for maximum sensitivity in most situations. Adjustments may be required depending on animal size and
environment. PIR motion detection distance changes based on ambient temperature and setup. Higher ambient
temperatures will reduce PIR motion detection range thereby requiring camera to be closer to desired location. Mounting
camera too high or tilting camera may result in animal or humans going under or above the PIR motion detection range.
Position the camera perpendicular to the ground to maximize the Flash lighting potential. Cars and other motorized
vehicles are not animals. Those are emitting heat motion differently vs humans and animals. Cold vehicle iron is not
emitting heat. Avoid installing the camera directly at sunrise or sunset, so that the sunlight will not directly shine on the
lens. If installed in a dusty environment, regularly clean the camera lens cover, flash cover and PIR sensor cover.
SMS commands list for NITEforce EZmail camera
Message Function Note
Get
#110# To take a picture / video and send
Camera
status
#370# Camera status (status data)
Send
Mode #220#value1#value2#
#220#0#10# Instant，max num=10 (Value "0")
#220#1#2030# Daily report, 20:30 (Value "1")
#220#2#10#2030# Both, Max num=10 ，20:30 （Value "2"）
#220#3# Off, （Value "3"， the maximum is "3" ）
Send
Size #230#1# #230#1#0# Send to Email(big photo/video)
#230#1#1# Send to Email(smaller photo)
SMS
Switch #240#value#value# #240#00#00# Works the whole day(If two values are the same, it
means work the whole day)
#240#18#20# Works from 18:00 to 20:00
Camera
mode #310#value#
#310#0#
The camera mode is set as Photo.
#310#1# The camera mode is set as Video.
Video
settings
#330#Video Size# Video
Length#
Set Video Size and video length. 0=1080P, 1=720P, 2=WVGA ; Video length is from
5 to 60.
Trigger
Mode
#350#0#PIR interval#PIR
Sensitivity# PIR trigger
#350#1#Time Lapse# Time Lapse
#350#2#PIR interval#PIR
Sensitivity#Time Lapse# Both
Note: PIR
Sensitivity=0(Low),1(Normal),2(High),3(Off)
eg: #350#0#m1#2# means PIR trigger, 1 min
delay ，High sensitivity;
eg: #350#0#s30#3# means PIR trigger, 1 min
delay ，High sensitivity;
eg:#350#1#h1# means Time Lapse, 1 hour delay.)
