Nimbus Water Systems WiMi310 Manuel utilisateur

WiMi310 User Manual v1.0

Wired/Wireless Multi-media interface

WiMi310

User Manual

Ver. 1.0

2017. 1. 16

WiMi310 User Manual v.1.0

Document Revision History

Revision Date Description

v1.0 January 16, 2017Initial release of WiMi310 Product Datasheet v1.0

WiMi310 User Manual v.1.0

•The RF module limited to OEM installation ONLY.

The OEM integrator is responsible for the compliance to all the rules that apply to the

product in to which this certified RF module is integrated.

•This module must be integrated into a device where the user cannot access the antenna

connector and should not be able to remove or install the module.

Dipole antenna(Under 6.26 ㏈i) can be used with this module. The antenna gain must

not exceed it.

•This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received. Including interference that may cause undesired

operation.

•This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

• This equipment generates uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of

the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

- Consult the dealer or an experienced radio/TV technician for help.

• FCC Caution

Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment. This transmitter must

not be co-located or operating in conjunction with any other antenna or transmitter.

• Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with minimum distance

WiMi310 User Manual v.1.0

20cm between the radiator & your body.

• This device is intended only for OEM integrators under the following conditions:

The antenna must be installed such that 20 cm is maintained between the antenna and

users, and The transmitter module may not be co-located with any other transmitter or

antenna. As long as 2 conditions above are met, further transmitter test will not be required.

However, the OEM integrator is still responsible for testing their end-product for any

additional compliance requirements required with this module installed.

• IMPORTANT NOTE:

In the event that these conditions cannot be met (for example certain laptop configurations

or colocation with another transmitter), then the FCC authorization is no longer considered

valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM

integrator will be responsible for re-evaluating the end product (including the transmitter)

and obtaining a separate FCC authorization.

• End Product Labeling

This transmitter module is authorized only for use in device where the antenna may be

installed such that 20 cm may be maintained between the antenna and users. The final end

product must be labeled in a visible area with the following:

“Contains FCC ID: ZD7-WIMI310”.

The grantee's FCC ID can be used only when all FCC compliance requirements are met.

• Manual Information To the End User

The OEM integrator has to be aware not to provide information to the end user regarding

how toinstall or remove this RF module in the user's manual of the end product which

integrates this module. The end user manual shall include all required regulatory

information/warning as show in this manual.

WiMi310 User Manual v.1.0

Purpose of this Document

This document provides simple circuit description and detailed specifications of the

WiMi310™ WiFi Module. The document is intended for Hardware designer wishing to

implementation of WiMi310 module into their own systems.

Related Documents

Additional information related to this document can be found in the Following documents

: PCB Form Factor

PCI Express TM Card Electromechanical Specification Revision 1.1 (March 28, 2005)

WiMi310 User Manual v.1.0

Key Features

•2x3 MIMO antenna configuration using two spatial streams

•IEEE Std. 802.11 n Network Standards

•Modulation modes: OFDM

•WPS Certified- Wireless Protected Setup for easy set up and security configuration

•Functions as a legacy endpoint device that conforms to the PCI Express Base Specification,

Rev 1.1

•Optimal channel selection and connection management

•Seamless channel switch under interference

•Only 40 MHz channel bandwidth support.

•300MHz PHY Rate Support and STBC Support for Extended Range

•Antenna: 3x IPex Connectors (2T/3R) - U.FL

•MAC Filtering - No Restriction Mode, White List Mode, Black List Mode; Up to 32

connections

•WDS Enables network management units to collect statistics and manage the device

remotely

•Support Low Power Mode

•RoHS Compliance

WiMi310 User Manual v.1.0

Electrical Specifications

Parameter Symbol Value Unit Note

Min. Typ. Max.

Supply Voltage VDD 5.0V-0.3 +6.0 V

Input voltage to digital pins Vin +3.6 V

Storage temperature TSTG -20 +50 ℃

Table 2. Absolute Maximum Ratings

Attention

: Stress above the Max. values listed here may cause permanent damage to the

device. Exposure to absolute maximum rating conditions for extended periods may affect

device reliability. Maximum ratings are absolute ratings : exceeding only one of these value

may cause irreversible damage to the integrated circuit.

The Following Table is defined in typical conditions:Ta=25℃, unless otherwise specified.

Parameter Symbol Value Unit Note/Test Condition

Min. Typ. Max.

Supply Voltage VDD 5.0V3.9 5.0 5.5 V

Input high voltage VIH 2.0 5.5 V

Input low voltage VIL -0.3 0.8 V

Output high voltage VOH 2.4 V without DC load

Output low voltage VOL 0.4 Vwithout DC load

Tri-

State Output leakage

current

IOZ ±10 uA

Pull-up resistor Rpu 26 38 59 KΩ

Pull-down resistor Rpd 33 47 81 KΩ

I/O pins input capacitance CI 4 pF

Total Power Consumption 5.5 W

Table 3. DC Parameters Information

WiMi310 User Manual v.1.0

Pinout Description

PIN # Name Type Description

1WAKE# In Link reactivation

45,47,49,51 +5.0V Power +5.0V Power

3,5,8,10,12,14,

16,17,19,20,

45,47,49,51

Reseved Reserve

Leave unconnected

4,9,15,18,21,

26,27,29,34,

35,37,40,43,50

GND Power Ground

6,28,48 +1.5V (Reserved) Reserve

Not used until now, leave unconnected.

7CLKREQ# Out Reference clock request

11 REFCLKn In Reference Clock, Differential Pair Negative

13 REFCLKp In Reference Clock, Differential Pair Positive

22 PERST# In Functional reset

23 PERn In PCI Express x1 data Input, negative

25 PERp In PCI Express x1 data Input, positive

30 SMB_CLK In SMBus Clock

32 SMB_DATA In/Out SMBus Data

31 PETn Out PCI Express x1 data Output, negative

33 PETp Out PCI Express x1 data Output, positive

36 USB_Dn In/Out USB Serial Data, negative

38 USB_Dp In/Out USB Serial Data, positive

42 LED_WWAN# Out Status Indication LED signal, active low

44 LED_WLAN# Out Status Indication LED signal, active low

46 LED_WPAN# Out Status Indication LED signal, active low

Table 4. Pinout Description

WiMi310 User Manual v.1.0

PCI Express Interface Description

•PCI Express Interface Unit(PCIE) functions as a PCI Express legacy endpoint device that

conforms to the PCI Express Base Specification, Rev 1.1.

•As PCIe endpoint device, it can be configured to be either a master initiating PCIe

operation or a target responding to a PCIe operation. The PCIe I/F is a 2.5GHz signaling, x1

differential link

Parameters Description

Master transaction types All memory transactions, except lock

Supports PCIe master DMA

IO and configuration transactions – not supported

Target transaction types Supports two outstanding non-posted requests as a target (computer)

All memory transactions – type 0 only

Message support Supports interrupt and error messages

Configuration space Extended 4KB PCIe Configuration Space

Single function device

Interrupts Support of both MSI and interrupt messages

Error reporting Full support of PCIe baseline error reporting

Full support of advanced error reporting capability

Three error severity levels – correctable, non-fatal and fatal

Header logging and pointer to first uncorrectable error

Programmable error severity

PCI error mapping – mapping errors to PCI error reporting mechanism

Address space Two 32-bit memory BARs

Virtual channels Support of baseline TC0-VC0 mapping

Single VC0 HW resource

Table 5. WiMi310 PCIe Supported Features

WiMi310 User Manual v.1.0

Mechanical Description

PCB Form Factors are complied with

“PCI Express Mini Card Electomechanical Specification

Rev.1.2”, (Oct 26, 2007)

•width : 30.0mm

•width : 50.95mm

•Thickness : 5.0mm
