Nikro PDC4000 Manuel utilisateur
AIR DUCT CLEANING
SYSTEM
MODEL #PDC4000
INSTRUCTION MANUAL
RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY
• Unit must be electrically grounded.
• Do not operate in standing water.
• If electrical components become wet, allow them to dry completely before
using.
• Unplug unit before performing any maintenance, filter changes or
cleaning.
• Inspect cord and plug for damage before use.
• Do not touch cord with wet hands or while standing on wet surface.
• Do not operate in flammable or explosive areas.
• Do not clean unit while plugged in.
• This unit has been designed for indoor use only.
• Do not use to exhaust hazardous or explosive materials or vapors
IMPORTANT SAFETY INSTRUCTIONS
a. “Do not operate any unit with a damaged cord or plug. Discard unit or return it to an authorized
service facility for examination and/or repair.”
IMPORTANT
SAFETY
INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
“READ AND SAVE THESE INSTRUCTIONS”
RISK OF ELECTRIC SHOCK CAN CAUSE
INJURY OR DEATH.
UNPLUG UNIT BEFORE SERVICING.
TO REDUCE THE RISK OF ELECTRIC SHOCK:
b. “Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings.
c. Arrange cord away from traffic area and where it will not be tripped over.”
All NIKRO Industries Inc. products that have rated efficiencies of 99.97% @ 0.3 microns and/or
99.99% @ 0.3 microns, have H.E.P.A. filters that have been individually tested to meet these
minimum efficiencies.
Although all the filters have been pre-tested, the possibility of leaks or filter failure due to handling,
transportation, punctures, loaded filters, moisture, wear and tear, etc., does exist.
Therefore, when using this equipment in highly sensitive areas or where any release of
particles above and beyond the minimum efficiencies would be detrimental and harmful to
humans, plants or property; it is strongly recommended that the units be individually tested
prior to their use.
This is to assure that they are maintaining the efficiency levels, which they were designed to
filter out.
FAILURE TO DO SO COULD RESULT IN SERIOUS HARM TO HUMAN LIFE, PLANT LIFE
AND/OR PROPERTY.
BACKDRAFTING AND CARBON MONOXIDE FUMES
To prevent the backdrafting of deadly carbon monoxide, when using your PDC4000 to create a
negative pressure in a containment area, turn off all open combustion devices such as but not
limited to fireplaces, hot water heaters, furnaces, boilers etc.
1115 N. Ellsworth Ave., Villa Park, IL 60181
Telephone: 630-530-0558 FAX: 630-530-0740 Toll Free: 800-875-6457
PRODUCT INSPECTION
1. Thoroughly inspect your machine for any shipping damage.
2. Your machine has already been thoroughly tested at the Nikro Industries
manufacturing plant prior to shipping.
3. Please do not discard any of the packaging until you have inspected the vacuum and
it is operational. Make sure the contents are intact and complete. If there are any
missing parts please contact NIKRO Industries immediately.
CONTENTS
1 - #PDC4000 – Air Duct Cleaning System
1 – #860147 – 12” x 25’ PVC Flex Duct
2 – #860249 – 12” Quick Connect Hose Clamps
1 – #860111 – 12” Duct Mounting Flange
Replacement Filters:
#862328 – Reusable Bulk Collection Bag (1 installed in Unit)
#862200 – Merv 11 Cube Filter (1 installed in Unit)
#862323 – HEPA Filter (1 installed in Unit)
#860111
#860249
#860147
#PDC4000
Your #PDC4000 Portable Air Duct Cleaning System has been thoroughly tested and inspected at the
factory and is fully assembled and ready for use. However, prior to plugging the unit in, inspect it for
any damage that may have incurred during shipping.
ELECTRICAL RATING:
115V 10 Amps 60 HZ - Each Motor
Use minimum of 12-3 gauge extension cords.
Each motor cord requires a separate 15 amp or 20 amp circuit.
FILTER AND SET-UP PROCEDURES
1) Turn off and unplug unit.
2) Remove the door w/12” flange by loosening the 4 – twist lock latches
(See Photo #1).
3) Place the HEPA filter in the HEPA filter cabinet, make sure the air
flow arrows on filter
are pointing towards the blower assembly. Use the 4 bolts to secure
the HEPA filter.
4) Connect the cube filter spacer frame to the 4 HEPA hold down bolts
and secure with the 4 – 5/16 nuts (See photo 3)
5) Place the Merv 11 Cube Filter inside the filter holding frame of the
door. (See photo 4)
6) Place door on the HEPA filter cabinet and secure by tightening the
latches. (See photo 5)
7) Connect the HEPA filter cabinet to the blower cabinet and secure
them together using the 4 latches.
8) Connect the 12” clear hose to the 12” intake flange on the door of the
prefilter cabinet and using the hose clamp provided, secure tightly.
9) Mount the duct intake collar at your access point.
10) Connect the 12” clear hose to the duct intake connector using the
hose clamp provided.
11) Unit is ready for operation.
FILTER CHANGING PROCEDURE
Your NIKRO Portable Air Duct Cleaner is equipped with a filter monitor gauge which is
located on the lower filter cabinet. When this gauge reads 4" or higher, the following
steps should be taken:
1) Turn off unit.
2) Inspect the 12" clear hose assuring that it is not kinked or clogged.
3) Empty or replace the Merv 11 cube filter.
4) If gauge continues to read at 4" or higher, go to Step #5.
5) Replace the HEPA filter.
6) If gauge remains at 4" or higher with clean filters and no hose attached to the unit DO NOT
USE THE UNIT. Contact the Nikro Factory immediately.
1) 12” Intake
2) Merv 11 Cube Filter
3) 99.97% HEPA Filter
DO NOT ATTEMPT TO LIFT THE ENTIRE UNIT BY TILTING BACK THE
DOLLY AND STAIR CLIMBER ASSEMBLY. LIFTING THE ENTIRE UNIT WILL
CAUSE SERIOUS DAMAGE TO THE MACHINE AND POSSIBLY CAUSE
BODILY INJURY. THE STAIR CLIMBING WHEELS HAVE BEEN DESIGNED
TO TRANSPORT THE MOTOR CABINET ONLY. ALWAYS DISCONNECT THE
HEPA FILTER CABINET FROM THE MOTOR CABINET BEFORE
ATTEMPTING TO USE THE STAIR CLIMBING WHEELS. SEE BELOW.
WARNING
#PDC4000 ASSEMBLY
PC NO PART NO DESCRIPTION QTY
1 862209 MOTOR CABINET 1
2 862210 FILTER CABINET 1
3 862232 DOOR 1
4 862201 EXHAST PANEL 1
5 861550 5 X 1 CASTER 2
6 860576 LATCH 8
7 860726 STRIKE 8
8 862229 AXLE MOUNTING / BRACKET 1
9 862194 10” WHEEL 2
10 862231 HANDLE 1
11 862200 MERV 11 CUBE FILTER 1
12 862323 HEPA FILTER 1
13 862204 BAFFLE 1
14 860695 BLOWER CONE 2
15 860682 MOTOR ASSEMBLY 2
16 860973 HANDLE 2
17 862206 PDC MOTOR SHELF LEG 2
18 862205 PDC4000 MOTOR SHELF 1
19 862207 PDC400 MOTOR STAND 1
20 862196 CONTROL PANEL 1
21 862237 AXLE 1
22 862208 CASTER PLATE 2
NOT SHOWN 862244 LOCKING SWIVEL CASTERS 4
NOT SHOWN 862328 REUSABLE BULK COLLECTION BAG 1
#PDC4000 CONTROL PANEL
PC
NO PART NO PART NAME QTY
1 860699 GAUGE 1
2 862293 SWITCH 2
3 860722 HOSE BARB NUT 1
4 860721 HOSE BARB 1
5 860570 BREAKER 2
6 861067 RUNNING LIGHT 2
7 862196 CONTROL PANEL PLATE 1
