Nikon Monarch/Titanium Manuel utilisateur

Nikon Riflescope Monarch/Titanium

6.5-20x44 A0

5.5-16.5x44 A0

4-12x40 A0

3.3-10x44 A0

3.5-10x50

1.5-4.5x20

2.5-8x28

6x42

3-9x40

2-7x32

4x40

2x20

Instruction Manual

Congratulations on your choice of a Nikon RIFLESCOPE. Your new scope is the

finest example of Nikon’s rugged and durable construction and precision bright

optics; important qualities for a serious shooter’s riflescope.

Whether you use your scope for hunting or for target shooting, the procedure for

mounting is identical. You should acquire a set of high quality steel mounting

rings which have a standard diameter of 25.4 mm (1inch). Follow the ring

manufacturer’s instructions for mounting procedures. After mounting the scope

on your rifle, follow the procedures for reticle alignment.

Caution

(1) Do not look at the sun through the riflescope. It will permanently damage

your eye. This precaution applies to all optical devices such as cameras and

binoculars.

(2) The riflescope is effectively sealed against moisture and dust. You may use

your scope safely either in the rain or in dusty climates. To preserve the

appearance of the scope, we suggest that it be dried and cleaned prior to

storage. Use a soft cloth for cleaning metal surfaces and use photographic lens

tissue to clean the scope’s lenses.

When setting the reticle for hunting, you should determine your standard range

and then adjust the reticle based upon that target distance. For targets which

vary from the standard distance you may simply adjust the position of the reticle

in relation to your target, or you may wish to use the procedure for trajectory

compensation. It’s up to your personal preference.

We hope that you will enjoy your new Nikon RIFLESCOPE for many years to

come. Enjoy using it, and above all, always follow safe shooting procedures!

The product(s) described herein may be subject to export control regulations in

the relevant country(ies). It (they) should not be exported without authorization of

the exporting governmental authority if the regulations apply.

1. Nomenclature

(1) Objective Lens

(2) Eyepiece Lens

(3) Elevation Adjustment

(4) Windage Adjustment

(5) Eyepiece Lock Ring

(6) Eyepiece Adjustment

(7) Power Index Dot

(8) Power Scale

(9) Power Selector Ring

(10) Adjustable Objective Adjustment Ring

(11) Adjustable Objective Distance Scale

(12) Distance Index Dot

(13) Adjustment Cap

ITEMS SUPPLIED

Body 1pc.

Eyepiece Cap 1pair

Objective Cap

Grips (6.5-20x44 only) 2pcs.

Hex Key (6.5-20x44 only) 1pc.

Instructions

(1) Focusing

(1) Look through the eyepiece with your eye positioned about 10cm (4 in) away

from the eyepiece lens (Fig. 3-1), and you will see the Nikoplex reticle (Fig. 3-2),

the Crosshair with dot reticle (Fig. 3-3) or the Turkey Pro reticle (Fig. 3-4) the

Crosshair reticle (Fig. 3-5) or the Miliradian Dot reticle (Fig. 3-6), or the BDC

reticle (Fig. 3-7).

Be sure your eye is positioned within proper alignment and proper eye relief

otherwise the view will “black out”.

(2) Point the objective end of the scope at the sky (Do not point at the sun) or at

a plain unpatterned wall.

Loosen the lock ring. (2x20 only)

Turn the eyepiece adjustment counter-clockwise and then turn it clockwise until

the reticle appears sharp.

(2x20 only)

(3) Finally, without moving the eyepiece adjustment, turn the eyepiece lock ring

as Fig. 3-8 to end so that the eyepiece adjustment will be firmly locked.

The lock ring must be firmly tightened to ensure an air-tight seal.

The reticle should be immediately crisp and clear to the quick glance.

(2) Magnification

• The Nikon Riflescope 6x42 has a fixed magnification of 6X, 4x40 of 4x, 2x20 of

1.75X.

• The Nikon Riflescope 3-9x40 has a variable magnification from 3 to 9X, 2-7x32

from 2 to 7X, 1.5-4.4x20 from 1.5 to 4.5X, 4-12x40 A0 from 4 to 16.5X, 3.5-

10x50 from 3.5 to 10X. 3.3-10x44 A0 from 3.3 to 10X, 2.5-8x28 from 2.5 to 8x.

To change powers, just rotate the power selector ring until the desired

magnification appears adjacent to the power index dot.

(3) Adjustment of the riflescope

Sighting through the riflescope, align the rifle with your aiming point on the

target and shoot a trial round. If the bullet does not hit the aiming point, adjust

the elevation and windage, as follows:

•If the bullet hits under the aiming point, turn the elevation adjustment

(counter-clockwise) in the direction of the arrow marked “U” for up as in

Fig. 3-9. If the bullet hits high, turn adjustment (clockwise) in the direction

of the arrow marked “D” for down.

•If the bullet hits to the right of the aiming point, turn the windage

adjustment (clockwise) in the direction of the arrow marked “L” for left as

in Fig. 3-10. If the bullet hits to the left of the aiming point, turn

adjustment (counter-clockwise) in the direction of the arrow marked “R”

for right.

•For the Nikon Riflescope 6.5-20x44 A0 adjustment is made by turning the

grip by hand. If the bullet hits under the aiming point, turn the grip in the

direction of the arrow marked “U” (Fig. 3-11). If the bullet hits to the left of

the aiming point, turn the grip in the direction of the arrow marked “R”

(Fig. 3-12).

(4) Adjustable objective

The Nikon Riflescope 6.5-20x44 A0, 4-12x40 A0, 3.3-10x44 A0 and 5.5-16.5x44

A0 can be more precisely focused within the range of at least 50 yards (45.72 m)

~ infinity by rotating the objective adjusting ring.

Parallax can be eliminated and sight alignment will be accurate.

Use its distance scale as a reference guide.

Rotation of the adjusting ring is intentionally adjusted to be heavy at the factory

so that it will not move easily during shooting.

(5) Changing the grip (6.5-20x44 A0 only)

Remove the protective cap of the grip by turning it counterclockwise. Align the

grip to the 0 (zero) position of the scale ring. This is to assure that the scale ring

will be correctly aligned to the new grip (the alignment position should be

remembered).

With the grip held with your fingers to avoid shifting of the aligned scale ring,

turn the bolt in the top of the grip counterclockwise with the hex key supplied

until the bolt comes out. Then remove the grip (Fig. 3-13).

Insert the new grip into position and align the scale ring to 0.

Insert the bolt. By securing the grip with our fingers to avoid shifting of the scale

ring, turn the bolt clockwise with the hex key supplied, until the grip is firmly

secured.
