Weapon Sights
APPLICATIONS
TARGET ACQUISITION
RECONNAISSANCE
COVERT OPERATIONS
SURVEILLANCE
SPECIAL LAW ENFORCEMENT
FEATURES
Compatible with Standard
Day Optic
Longwave thermal
imaging sensor
Multi use design
Rubber Shroud
Small and lightweight
Simple operation
No special batteries required
It’s all FLIR inside
BENEFITS
Designed to interface with day sights such as Trijicon Advanced
Combat Optical Gunsight (ACOG) Model TA31, 4x32 presenting
the soldier with the same field of view, keeps reticles
calibrated, maintaining boresight
Provides crisp imagery through total darkness, fog, smoke,
dust, and many other obscurants
Offers mission flexibility for use as a thermal weapon sight
and as a rugged hand held imager for a variety of scouting,
surveillance, and covert operations
Ensures covert operation by eliminating illumination of the
operator from the viewfinder
Highly portable design reduces operator fatigue
Large, rugged, single button controls for basic image
adjustment, no complicated menus to navigate
Runs on CR123 photo cells
FLIR controls the entire supply chain on the critical technology
inside the ACTS ensuring fast service and long term support
ThermoSightTM T50
ADVANCED COMBAT THERMOSIGHT
CORPORATE HEADQUARTERS
FLIR Systems, Inc.
27700 SW Parkway Ave.
Wilsonville, OR 97070
PH: +1 800.727.3547
BOSTON
FLIR Systems, Inc.
25 Esquire Road
North Billerica, MA 01862
PH: +1 800.464.6372
HUNTSVILLE
FLIR Systems, Inc.
Huntsville, AL USA
PH: +1 256.325.3547
PITTSBURGH
FLIR Systems, Inc.
Freeport, PA USA
PH: +1.724.295.2880
WASHINGTON, D.C.
FLIR Systems, Inc.
2800 Crystal Drive, Suite 330
Arlington, VA 22202 USA
PH: +1 703.416.6666
EUROPE
FLIR Systems Ltd.
West Malling, Kent
United Kingdom
PH: +44.1732.220011
CANADA
FLIR Systems Ltd.
Burlington, ON
Canada
PH: +1 800.613.0507
SWEDEN
FLIR Systems AB
Täby, Sweden
PH: +46.8.753.2500
MIDDLE EAST
FLIR Systems Middle East, FZCO
Dubai Airport Free Zone
PH: +9714.299.6898
www.flir.com/GS
THERMAL IMAGING PERFORMANCE
Sensor type 320 x 240 VOx microbolometer
Fields of view 9.33° (h) x 7° (v)
Spectral band 7.5-13.5 μm
Automatic features Contrast, brightness, STACETM (digital image enhancement)
SYSTEM FEATURES
Silent operation Inaudible beyond 1 m
Bore sight retention Holds boresight through extensive rounds of firing
OUTPUTS
Video Built in Display VGA monochrome and RS-170 output
POWER
Power requirements 3 CR123 batteries
Battery life Approximately 9 hours continuous use
ENVIRONMENTAL
IP rating IP 68
Operating temp -40°C to +75°C (-40°F to +131°F)
Storage temp -50°C to +85°C (-58°F to +149°F)
DIMENSIONS, WEIGHT & MOUNTING
Dimensions (lens covers off) 5.3” L x 3.5” W x 4.0” H
Weight 24 oz with batteries, lens covers, and rail mount
Mounting Picatinny Rail mount
INTERFACES
Command and Control Auto/manual gain/level, polarity, manual NUC,
2x, 4x digital zoom
STANDARD PACKAGE
Laser Pointer 30 mW @ 850 nm and safety mode of 0.5 mW
Batteries 3 each, CR123, fit into plastic sleeve for quick removal
and replacement
ThermoSightTM T50
30mW AT 850 nm
Equipment described herein may require US Government authorization for export purposes. Diversion contrary to US law
is prohibited. ©2010 FLIR Systems, Inc. Specifications are subject to change. Check website: www.flir.com/GS 10222010
