Nikon D2X Mode d'emploi
作成承認印 配布許可印
VBA10501-R.3657.A
Copyrigh ｃ2005 by Nikon Corporation.
All Rights Reserved.
無断転載を禁ず
!!
Printed in Japan February 2005
VBA10501
Ｍ
サービス
計画課
REPAIR MANUAL
VBA10501-R.3657.A
- Ｍ1 ･ -
Specications
Type Single-lens reex digital camera with interchangeable lenses
Effective pixels 12.4 million
Image sensor 23.7 × 15.7 mm; total pixels: 12.84 million
Image size (pixels) 4288 × 2848 (L), 3216 × 2136 (M), 2144 × 1424 (S)
High-speed crop on I3216 × 2136 (L), 2400 × 1600 (M), 1600 × 1064 (S)
Lens mount Nikon F mount (with AF coupling and AF contacts)
Compatible lenses*
Type G or D AF Nikkor All functions supported
Micro Nikkor 85 mm
F2.8D
All functions supported except autofocus and some exposure modes
Other AF Nikkor † All functions supported except 3D color matrix metering and 3D
multi-sensor balanced ll-ash for digital SLR
AI-P Nikkor All functions supported except 3D color matrix metering, 3D
multi-sensor balanced ll-ash for digital SLR, and autofocus
Non-CPU Can be used in exposure modes A and M; electronic range nder can
be used if maximum aperture is f/5.6 or faster;color matrix metering,
multi-sensor balanced ll-ash for digital SLR, and aperture value
display supported if user provides lens data
* IX Nikkor lenses can not be used † Excluding lenses for F3AF
Picture angle Equivalent in 35-mm format is approximately 1.5 times lens focal
length (2 times when high-speed crop is on)
Viewnder Optical xed eye-level pentaprism
Diopter adjustment –3 – +1 m–1
Eyepoint 19.9 mm (–1.0 m–1)
Focusing screen Ships with type V clear-matte Mark III screen installed
Fame coverage Approximately 100% of lens (vertical and horizontal)
Magnication Approximately 0.86× (50-mm lens at innity; –1.0 m–1)
Re ex mirror Quick return
Lens aperture Instant return with depth-of-eld preview
Focus-area selection Single area or group can be selected from 11 focus areas (9
focus areas when high-speed crop is on)
Lens servo Instant single-servo AF (S); continuous-servo AF (C); manual (M);
predictive focus tracking automatically activated according
to subject status in single- and continuous-servo AF
VBA10501-R.3657.A
- Ｍ2 ･ -
Autofocus TTL phase detection by Nikon Multi-CAM2000 autofocus module
Detection range
(ISO 100 at 20 °C / 68 °F)
–1 – +19 EV (0 – +19 EV for two focus areas outside high-speed
crop)
AF-area mode Single-area AF, dynamic-area AF, group dynamic-AF, dynamic-area
AF with closest subject priority
Focus lock Focus can be locked by pressing shutter-release button halfway
(single-servo AF) or by pressing AE-L/AF-L button
Exposure
Metering Three-mode through-the-lens (TTL) exposure metering
Matrix 3D color matrix metering supported with type G and D lenses;
color matrix metering available with other CPU lenses and with
non-CPU lenses if user provides lens data
Center-weighted Weight of 75% given to 6, 8, 10, or 13-mm circle in center of
frame, or weighting based on average of entire frame
Spot Meters 3-mm circle (about 2% of frame) centered on selected
focus area (on center focus area when non-CPU lens is used)
Range
(ISO 100 equivalent,
f/1.4 lens, 20 °C/68 °F)
0 – 20 EV (3D color matrix or center-weighted metering)
2 – 20 EV (spot metering)
Exposure meter coupling Combined CPU and AI
Exposure control
Exposure modes Programmed auto with exible program; shutter-priority auto;
aperture priority auto; manual
Exposure compensation –5 – +5 EV in increments of 1/3, , or 1 EV
Bracketing Exposure and / or ash bracketing (2–9 exposures in increments
of 1/3, , 2/3, or 1 EV)
Exposure lock Luminosity locked at detected value with AE-L/AF-L button
Shutter Electronically-controlled vertical-travel focal-plane shutter
Speed 30 – 1/8000 s in steps of 1/3, , or 1 EV, bulb
Sensitivity
(ISO equivalent)
100 – 800 in steps of 1/3, , or 1 EV, 1600, 3200; auto gain to 800
White balance Auto (TTL white-balance with main image sensor, 1,005 pixels
RGB sensor, and ambient light sensor), six manual modes with
ne-tuning, color temperature setting
Bracketing 2–9 exposures in increments of 1, 2, or 3
VBA10501-R.3657.A
- Ｍ3 ･ -
Flash
Sync contact X-contact only; ash synchronization at up to 50 s
Flash contrrol
TTL TTL ash control by combined ve-segment TTL multi sensor with
single-component IC and 1,005-pixel AE sensor
• SB-800, 600: i-TTL balanced ll- ash for digital SLR and
standard i-TTL ash for digital SLR
• SB-80DX, 28DX, or 50DX with type G or D lens: 3D multi-sensor
balanced-ll ash for digital SLR
• SB-80DX, 28DX, or 50DX with other lens: multi-sensor balanced-
ll ash for digital SLR
• SB-80DX, 28DX, or 50DX with spot metering: standard TTL ash
for digital SLR
Auto aperture Available with SB-800, 80DX, or 28DX and CPU lens
Non-TTL auto Available with such Speedlights as SB-800, 28, 27, and 22s
Range-priority manual Available with SB-800
Sync modes Front curtain sync (normal), slow sync, rear-curtain sync, redeye
reduction, red-eye reduction with slow sync
Flash-ready indicator Lights when SB-series Speedlight such as 800, 600, 80DX,
28DX, 50DX, 28, 27, or 22s is fully charged; blinks for 3 s
after ash is red at full output
Accessory shoe Standard ISO hot-shoe contact with safety lock
Creative Lighting
System
With SB-800 and 600, supports Advanced Wireless Lighting
(SB-600 only supports AWL when used as remote ash), Auto
FP High-Speed Sync, Flash Color Information Communication,
modeling illumination, and FV Lock
Storage
Media Type I and II CompactFlash memory cards; Microdrives
File system Compliant with Design Rule for Camera File System (DCF) and
Digital Print Order Format (DPOF)
Compression • Compressed 12-bit NEF (RAW): approximately 50–60%
• JPEG: JPEG baseline-compliant, can be selected from Size priority
and Optimal quality
Self-timer Electronically controlled timer with 2 – 20 s duration
Depth-of-eld preview Lens aperture stopped down when depth-of- eld preview button is
pressed
Monitor 2.5
″ ,
232,000-dot, low-temperature polysilicon TFT LCD with
brightness adjustment
VBA10501-R.3657.A
- Ｍ4 ･ -
Video output Can be selected from NTSC and PAL
External interface USB 2.0
Tripod socket
″
(ISO)
Firmware User upgradeable
Supported languages Chinese (Simplied), Dutch, English, French, German, Italian,
Japanese, Korean, Spanish, Swedish
Power source • One 11.1 V EN-EL4 rechargeable Li-ion battery
• EH-6 AC adapter (available separately)
Dimensions (W × H × D) Approximately 157.5 × 149.5 × 85.5 mm (6.2
″
× 5.9
″
× 3.4
″
)
Weight Approximately 1070 g (2 lb 6 oz) without battery, memorycard,
body cap, or monitor cover
Operating environment
Temperature 0 – 40 °C (32 – 104 °F)
Humidity Less than 85% (no condensation)
• Unless otherwise stated, all gures are for a camera with a fully-charged batteryoperating at an
ambient temperature of 20 °C (68 °F).
• Nikon reserves the right to change the specications of the hardware and software described in this
manual at any time and without prior notice. Nikon will not be held liable for damages that may
result from any mistakes that this manual may contain.
VBA10501-R.3657.A
- Ｄ1 ･ -
Precautions for disassembly/(re)assembly
Notes： ① In disassembly/(re)assembly, be sure to use conductive mat (J5033) and wrist strap (J5033-5), in order to
protect electric parts from static electricity.
② Before disassmbling, be sure to remove batteries, AC power cord, and battery for clock (CR1616).
③ In disassembling, be sure to memorize the processing state of wires and FPC, screws to be xed and their
types, etc.
④ The low-pass lter of the image PCB is easily damaged. Handle it very carefully.
⑤ In the chapter of Disassembly, sometimes a large assembly unit is removed. In case such a unit is further
disassembled , refer to the exploded technical drawings.
⑥ In Disassembly/(re)assembly chapters, the dip-proof sponge is not mentined. In case parts are replaced, be
sure to attach the dip-proof sponge by referring to the exploded technical drawings.
⑦ All wires are special parts (supporting UL), so be sure to use specied wires.
External rubber
#B60-1
1. External units and Imaging-related PCBs
Disassembly
・Lead-free solder is used for this product.
・For soldering work, the special solder and soldering iron are required.
・Do NOT mix up lead-free solder with traditional solder.
・Use the special soldering iron respectively for lead-free solder and lead solder. They
cannot be used in common.
Points to notice for Lead-free solder products
#B66
#B61
・Remove the grip rubber (#B60-1), apron lower rubber (#B66), and rubber at the lm rewind side (#B61).
Note 1: Before disassembling a camera, of which the main FPC should be replaced, be sure to read and note down the
adjustment value of the environment light sensor by adjustment software for the camera unit.
If the value cannot be
read out from the camera, replace the top cover unit, too. (Refer to Page A28 for the details when replaced.)
Note 2: When "Seprating Front and Rear bodies", "Disassembling Image PCB", and "Disassembling Bayonet", be sure to perform
"Reset of AF defocus compensation amount" by D2X adjustment software after reassembly.
#729
VBA10501-R.3657.A
- Ｄ2 ･ -
I/F Block
Grip Cover
#1534×2 #1510×2
Grip cover
①Take out 3 screws (#1589).
② Slacken A-part of I/F block.
③ Displace the I/F block downward a little, then unhook B-part.
④ Remove the earth lug plate from the clearance between the back door and I/F PCB, being careful not to bend
the plate.
・Take out 2 screws (#1534) and 2 screws (#1510) to detach the grip cover.
I/F Block
#1589×3
A-part
B-part
①
②
③
④
Lug plate
VBA10501-R.3657.A
- Ｄ3 ･ -
1. Remove Vertically position FPC
Bottom Cover Unit
2. Remove Bottom cover unit
Vertically position FPC
Bottom cover unit
・Remove the vertically position FPC from
the connector.
・Take out 3 screws (#1512) and 3 screws
(#1517).
・Remove the bottom cover unit from the
camera body.
#1512×3
#1517×3
Note: Between the bottom cover and
the body (i.e. A part), there is the
washer (T=0.3) inserted.
When assembling, be sure to put
it back into the original position.
(This measure is for lling in a
gap between the back door and
bottom cover.)
A part
VBA10501-R.3657.A
- Ｄ4 ･ -
Back door unit
1. Remove Back door unit
2. Remove TFT Monitor
・Take out 4 screws (#1514) and detach the
back door unit slowly.
・Remove the TFT (Memory compression PCB
connection-FPC: #5041) from the connector.
(ref. Fig.1）
Fig.1
#5041
Connector
#1514×4
Back door unit
・Remove the red and black
wires of the TFT back light
harness.
・Remove the TFT monitor
FPC and AF area FPC from
the connector.
・Take out 2 screws (#436)
and remove the TFT
retaining (#432) and TFT
monitor (#5043).
#436×2
#432
#5043
Red: TFT back light
Black: TFT back light
TFT monitor FPC AF area FPC
VBA10501-R.3657.A
- Ｄ5 ･ -
・Remove the TFT & Memory compression PCB connection-FPC (#5041) from the connector.
Connector
TFT & Memory compression PCB connection-FPC
3. TFT-PCB, Speaker, Microphone, other small parts
#5041
�
�
Speaker
Microphone
TFT PCB
#1531×2
#1513×2
#1508×3
#1560×2
#453
#B439
#1522×2
#B428
#442
#427
#460
#463
#425
#456
#467
#445
#437
Autres manuels pour D2X
3
Table des matières
Autres manuels Nikon Appareil photo numérique
Nikon
Nikon Coolpix AW130 Manuel utilisateur
Nikon
Nikon D500 Guide de démarrage rapide
Nikon
Nikon Coolpix L120 Manuel utilisateur
Nikon
Nikon Coolpix L12 Manuel utilisateur
Nikon
Nikon F6 Manuel utilisateur
Nikon
Nikon Coolpix 5000 Manuel utilisateur
Nikon
Nikon COOLPIX 8700 Manuel utilisateur
Nikon
Nikon 25593 - Coolpix P60 8.1MP Digital Camera Guide de l'utilisateur
Nikon
Nikon Coolpix L30 Manuel utilisateur
Nikon
Nikon Coolpix 5600 Manuel utilisateur
Nikon
Nikon COOLPIX S5200 Manuel utilisateur
Nikon
Nikon Z 6 II Manuel utilisateur
Nikon
Nikon D5 Professional Instructions d'installation et d'entretien
Nikon
Nikon CoolPix S51c Manuel utilisateur
Nikon
Nikon CoolPix P60 Manuel utilisateur
Nikon
Nikon D200 Manuel utilisateur
Nikon
Nikon COOLPIX S6 Manuel utilisateur
Nikon
Nikon CoolPix S570 Guide de l'utilisateur
Nikon
Nikon J3 Manuel utilisateur
Nikon
Nikon Coolpix S6100 Manuel utilisateur
