REACTOR

80W BATTERY (TC)

INTRODUCTION

Thank you for purchasing the REACTOR battery. Please read

this manual carefully before using to ensure optimal lifespan

and performance.

The REACTOR is an advanced vaping system offering an

enormous 5000 mAh battery capacity and adjustable

power ranging from 1W–80W. Additional benefits of the

REACTOR include temperature control, extraordinary vapor

production, and the ability to customize settings. This

system is manufactured to the highest quality standards,

and when coupled with our line of premium e-liquids, offers

an exceptional vaping experience.

GETTING STARTED GETTING STARTED

It is important to turn “o” this device before storing.

There is no harm in leaving your REACTOR battery “on,” as

the battery life will not be consumed unless the ring button

is pressed. It is important however, to turn your battery “o”

when placing it in drawers, pockets, or purses to ensure the

button is not pressed inadvertently.

To turn the REACTOR battery “o,” follow the same steps used

to turn the battery “on.” Simply press the ring button ve

times in rapid succession, and the LED screen will go blank.

Please note, you will need to turn the REACTOR battery back

“on” again before using.

REACTOR batteries must be turned “on” before using for the

rst time.

To turn on your REACTOR, press the ring button on the side of

the battery ve times in rapid succession. Once the battery is

turned on, the digital LED screen will become visible. To use this

device, rst ensure the battery is “on” and the tank is lled with

e-liquid. Once ready, place your lips around the mouthpiece and

inhale while holding down the ring button. Release the button

at the end of each drag and repeat as desired. The wattage can

be adjusted to personal preference as described later in this

instruction manual.

REACTOR 80w

COMPONENT’S FRONT & BOTTOMCOMPONENT’S SIDE

FRONT VIEW

BOTTOM VIEW

FIRING BUTTON

OLED SCREEN

• Battery Indicator

• Resistance Level

• Wattage

• Voltage

• Temperature

• Coil Type

FIRING BUTTON

OLED SCREEN

UP/DOWN

ADJUSTMENT

BUTTON

USB

CHARGING

PORT

POWER ADJUSTMENT

Overview

Adjusting the power (wattage) of your REACTOR battery oers

the ability to customize your vaping experience. Flavors taste

better at dierent power levels, so the ability to adjust wattage

allows users to nd the “sweet spot” of their favorite e-liquids.

Increased power will generate increased heat, which typically

results in warmer, more plentiful vapor production.

Adjusting Power

The wattage can be adjusted by pressing the “up” or “down” power

adjustment buttons until the desired level is reached. An increase

in wattage will translate to an increase in power. It is recommended

to start with lower levels and slowly increase the wattage.

POWER ADJUSTMENT

Advanced Users

Advanced users can further customize their vaping experience

by using coil heads of varying resistance. The resistance of the

attached coil head (ohms) can be viewed next to the battery

level indicator. Lower resistance coils will increase the power.

Locking the Wattage

Once a preferred wattage level is found, the device can be

locked to ensure the arrow buttons are not pressed accidentally.

To lock the wattage, press the up arrow and the down arrow

simultaneously for two seconds. Once successful, the LED

screen will display the word “Lock.” To unlock the device, repeat

the process until the LED screen displays the word “Unlock.”

TEMPERATURE CONTROL

TC Overview

The REACTOR battery oers advanced temperature control

(TC) functionality, allowing users to set a maximum coil

temperature. This is often used to maintain a consistent avor

prole while preventing “dry hits.” When a TC compatible

coil is attached to the battery, the corresponding mode must

be selected for the functionality to work properly. NI200 and

Titanium coils should never be used in Variable Wattage Mode

or red for extended periods of time.

The chart to the right indicates the available modes and

corresponding coil types required.

Mode Coil Material Temp Control

VW Any (Kanthal) No

TC-Ni NI200 Yes

TC-Ti Titanium Yes

TC-SS 316L Stainless Steel Yes

TCR-M1 Advanced Memory 1 Yes

TCR-M2 Advanced Memory 2 Yes

TCR-M3 Advanced Memory 3 Yes

TEMPERATURE CONTROL

TC Modes

To use the temperature control functionality, rst ensure a TC

compatible coil from the list on the last page is attached to the

device. Next, press and hold the “menu” button to toggle between

available modes. Release the button when the desired mode is

visible on the screen. The device can also be manually set to run

without temperature control by selecting the variable wattage

(VW) mode, bypass mode or smart mode. In variable wattage mode,

only overall power can be adjusted without the ability to limit the

maximum temperature. When setting the maximum temperature

of the coil, it is highly recommended to start low and slowly increase

the temperature. In bypass mode, the device can support a coil with

TEMPERATURE CONTROL

a resistance level within the range of 0.1 ohms - 3.5 ohms. Direct

voltage output system is applied in this mode. Therefore, the higher

the battery level, the higher the voltage output. In Smart Mode, the

wattage can be adjusted from 1W to 80W by pressing the up button

or down button only when an atomizer is installed on the device. The

Smart Mode will save one output power setting for each resistance

value and can totally save 10 groups of such proles. Once you

change the output power setting for a resistance, it will resave the

changed setting automatically. When the Smart Mode has already

remembered 10 proles and you want to add another new resistance,

the rst saved prole will be deleted. When set in this mode, thedevice

can support a coil whose resistance is within the range of 0.1-3.5 ohms.

TEMPERATURE CONTROL

Note: When using a non-TC coil in one of the temperature

control modes by mistake, the device will automatically

switch to variable wattage (VW) mode.

Adjusting Wattage

When in a temperature control mode, the wattage output can

be adjusted from 1W - 80W. Keep pressing the “menu” button

and the up button simultaneously to increase the wattage

level. To decrease the wattage level, simultaneously press the

“menu” button and the down button.

Adjusting Temperature

When in a temperature control mode, the maximum coil

TEMPERATURE CONTROL

temperature can be adjusted from 200-600°F by pressing the

up button to increase and down button to decrease. Each

press of the up or down button will increase or decrease the

temperature setting by 10°F. Holding the up or down button

will rapidly increase or decrease the temperature.

Shift Between °C and °F

If you increase temperature to 315 °C and continue to press the

up button, the temperature reading will automatically change

to the lowest Fahrenheit (200°F). Equally, if the temperature is

set at the lowest Fahrenheit (200°F) and you continue to press

the down button, the temperature reading will automatically

change to the highest Celsius (315°C).

TEMPERATURE CONTROL TEMPERATURE CONTROL

TCR Mode Advanced

TCR (Temperature Coecient of Resistance) mode allows the

user to manually adjust the TCR values for dierent types of

wire to further improve on the accuracy of the device’s ability to

limit and sense an atomizer coil’s temperature. There are three

storage slots available (M1,M2,M3), each of which can store a

user dened TCR value. For your reference, the following table

indicates standard TCR value ranges for dierent wire types:

Material Nickel Titanium NiFe SS (303,304,316,317)

TCR Value Range 600-700 300-400 300-400 80-200

Note: The TCR values listed above are 10X the actual

Temperature Coecient of Resistance.

M1 MODE VIEW

TEMPERATURE CONTROL TEMPERATURE CONTROL

Resistance Locking

Resistance Lock Mode allows the device to maintain the same

“base resistance” even though the coil resistance may increase

due to a rise in temperature. When locked, the device will

remember the last resistance used after a coil is removed and

then put back on.

In Resistance Unlock Mode, the resistance will be checked each

time a new coil is attached. After removing a coil, the screen

will display “New coil up same down” to check if the same coil

is being re-attached. If the same coil is being re-attached, press

the down button and if it is a new coil, press the up button.

Lock/Unlock Resistance

To lock or unlock the base resistance, ensure the device is

turned on and is set to one of the temperature control modes

(TC-Ni/TC-Ti/TC-SS/TCR M1, M2, M3). The attached coil must be

at room temperature for the device to correctly set the “base

resistance.” Next, hold down the re button and up button

simultaneously for 2 seconds to lock or unlock the resistance.

The lock sign will appear when resistance is locked and “Ω”

symbol will come back when unlocked.

Note: Be sure to unlock the base resistance when you want to

change an atomizer or a coil to a dierent resistance.
