Nibe F1145PC Manuel utilisateur

User manual

LEK

NIBE™ F1145PC

Ground source heat pump

UHB GB 1335-1

231789

4XLFN JXLGH

1DYLJDWLRQ

2N EXWWRQ FRQILUPVHOHFW

%DFN EXWWRQ EDFNXQGRH[LW

&RQWURO NQRE PRYHLQFUHDVHUHGXFH

A detailed explanation of the button functions can be found on page

11.

How to scroll through menus and make different settings is described

on page 15.

6HW WKH LQGRRU FOLPDWH

;

The mode for setting the indoor temperature is reached, when in the

start mode in the main menu, by pressing the OK button twice. Read

more about the settings on page 24.

,QFUHDVH KRW ZDWHU YROXPH

;

;

To temporarily increase the amount of hot water (if a hot water heater

is installed to your F1145PC), first turn the control knob to mark menu

2 (water droplet) and then press the OK button twice. Read more about

the settings on page 44.

In event of disturbances in comfort

If a disturbance in comfort of any type occurs there are some measures

that can be taken before you need to contact your installer. See page

68 for instructions.

Table of Contents

1 Important information 2

Installation data 2

Safety information 3

Serial number 4

Contact information 5

F1145PC – An excellent choice 7

2 The heat pump – the heart of the house 8

Heat pump function 9

Contact with F1145PC 10

Maintenance of F1145PC 20

3 F1145PC – at your service 24

Set the indoor climate 24

Set the hot water capacity 44

Get information 49

Adjust the heat pump 53

4 Disturbances in comfort 67

Manage alarm 67

Troubleshooting 68

Only additional heat 71

5 Technical data 72

6 Glossary 73

Item register 79

1NIBE™ F1145PCTable of Contents |

1Important information

Installation data

F1145PCProduct

Serial number

Installation date

Installer

Type of brine -

Mixing ratio/freezing point

Active drilling depth/collector

length

Accessories

✔

SetDefault

settings

NameNo.

0heating curve (off-

set)

1.9.1

7heating curve (curve

slope)

1.9.1

Serial number must always be given

Certification that the installation is carried out according to instructions

in NIBE's installer manual and applicable regulations.

_________________________Signed__________________Date

NIBE™ F1145PCChapter 1 | Important information2

Safety information

This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children

shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without

supervision.

Rights to make any design or technical modifications

are reserved.

©NIBE 2013.

Symbols

NOTE

This symbol indicates danger to machine or person.

Caution

This symbol indicates important information about what you should ob-

serve when maintaining your installation.

TIP

This symbol indicates tips on how to facilitate using the product.

Marking

The CE marking means that NIBE ensures that the product meets all regu-

lations that are placed on it based on relevant EU directives. The CE mark

is obligatory for most products sold in the EU, regardless where they are

made.

3NIBE™ F1145PCChapter 1 | Important information

Serial number

The serial number can be found at the bottom right of the front cover and

in the info menu (menu 3.1).

6HULDO QXPEHU

Caution

Always give the product's serial number (14 digits) when reporting a fault.

NIBE™ F1145PCChapter 1 | Important information4

Contact information

KNV Energietechnik GmbH, Gahberggasse 11, 4861 SchörflingAT

Tel: +43 (0)7662 8963-0 Fax: +43 (0)7662 8963-44 E-mail: mail@knv.at

www.knv.at

NIBE Wärmetechnik AG, Winterthurerstrasse 710, CH-8247 FlurlingenCH

Tel: (52) 647 00 30 Fax: (52) 647 00 31 E-mail: inf[email protected] www.nibe.ch

Druzstevni zavody Drazice s.r.o, Drazice 69, CZ - 294 71 Benatky nad

Jizerou

Tel: +420 326 373 801 Fax: +420 326 373 803 E-mail: [email protected]

www.nibe.cz

NIBE Systemtechnik GmbH, Am Reiherpfahl 3, 29223 CelleDE

Tel: 05141/7546-0 Fax: 05141/7546-99 E-mail: inf[email protected]

www.nibe.de

Vølund Varmeteknik A/S, Member of the Nibe Group, Brogårdsvej 7,

6920 Videbæk

Tel: 97 17 20 33 Fax: 97 17 29 33 E-mail: inf[email protected] www.volun-

dvt.dk

NIBE Energy Systems OY, Juurakkotie 3, 01510 VantaaFI

Puh: 09-274 697 0 Fax: 09-274 697 40 E-mail: [email protected] www.nibe.fi

AIT France, 10 rue des Moines, 67000 HaguenauFR

Tel : 03 88 06 24 10 Fax : 03 88 06 90 15 E-mail: inf[email protected] www.nibe.fr

NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way,

Chesterfield S41 9QG

Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: inf[email protected]

www.nibe.co.uk

NIBE Energietechniek B.V., Postbus 2, NL-4797 ZG WILLEMSTAD (NB)NL

Tel: 0168 477722 Fax: 0168 476998 E-mail: inf[email protected] www.nibenl.nl

ABK AS, Brobekkveien 80, 0582 Oslo, Postadresse: Postboks 64 Vollebekk,

0516 Oslo

Tel. sentralbord: +47 23 17 05 20 E-mail: [email protected] www.nibeen-

ergysystems.no

NIBE-BIAWAR Sp. z o. o. Aleja Jana Pawła II 57, 15-703 BIAŁYSTOKPL

Tel: 085 662 84 90 Fax: 085 662 84 14 E-mail: sekretariat@biawar.com.pl

www.biawar.com.pl

Tel./fax +7 831 419 57 06 E-mail: inf[email protected] www.nibe-evan.ru

5NIBE™ F1145PCChapter 1 | Important information

NIBE AB Sweden, Box 14, Hannabadsvägen 5, SE-285 21 MarkarydSE

Tel: +46-(0)433-73 000 Fax: +46-(0)433-73 190 E-mail: inf[email protected]

www.nibe.se

For countries not mention in this list, please contact Nibe Sweden or check www.nibe.eu

for more information.

NIBE™ F1145PCChapter 1 | Important information6

F1145PC – An excellent choice

F1145PC is part of a new generation of heat pumps, which have been in-

troduced to supply your home with inexpensive and environmentally

friendly heating and/or cooling. Heat production is safe and economical

with integrated immersion heater, circulation pumps and control system.

The heat pump can be connected to an optional low temperature heat

distribution system. e.g. radiators, convectors or under floor heating. It is

also prepared for connection to several different products and accessories,

e.g. hot water heater, ventilation recovery, pool, free cooling and climate

systems with different temperatures.

An immersion heater of 7 kW can be connected automatically if anything

unforeseen should occur or as reserve operation (then 6 kW).

F1145PC is equipped with a control computer for good comfort, good

economy and safe operation. Clear information about status, operation

time and all temperatures in the heat pump are shown on the large and

easy to read display. This means, for example, that external unit thermo-

meters are not necessary.

Excellent properties for F1145PC:

႑Scheduling the indoor comfort and hot water (accessory)

Heating and hot water as well as cooling and ventilation in some cases,

can be scheduled for each day of the week or for longer periods (vaca-

tion).

႑Display with user instructions

The heat pump has a large display with easy-to-understand menus that

facilitate setting a comfortable climate.

႑Simple troubleshooting

In the event of a fault, the heat pump display shows what happened

and the actions to be taken.

7NIBE™ F1145PCChapter 1 | Important information

2The heat pump – the heart of

the house

Värmekälla

Förångare

Kondensor 100 °C

0 °C-3 °C

-2 °C

50 °C40 °C

Expansionsventil

Växelventil

Kompressor

LEK

+HDWLQJ PHGLXP

%ULQH

5HIULJHUDQW

(YDSRUDWRU

&RQGHQVHU

([SDQVLRQ YDOYH &RPSUHVVRU

+HDW VRXUFH







6KXQW YDOYH

The temperatures are only examples and may vary between different installations and

time of year.

NIBE™ F1145PCChapter 2 | The heat pump – the heart of the house8
