User manual
Warning: the wall structure must be capable of supporting the total weight, which
includes the cabinet plus its maximum static load. Otherwise, the wall structure must be
reinforced.
Caution: this product is heavy, at least two qualified people should perform the
assembly procedure. Personal injury and/or property damage can result from dropping
or mishandling the enclosure.
Do not exceed the recommended load capacity per rack, and the maximum weight
supported by the enclosure, as indicated by the manufacturer’s specifications. Failure
to comply will void the warranty of this product.
For safety, use proper equipment and tools during the assembly to prevent personal
injury and to avoid damaging its parts.
FALLING EQUIPMENT HAZARD: ensure that the cabinet is properly anchored to the
wall prior to loading equipment inside.
Carefully read and follow the safety
instructions included in this manual before
assembling and using the cabinet.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN LEAD TO
SERIOUS INJURY, DEATH, OR DAMAGE TO YOUR EQUIPMENT
IMPORTANT SAFETY INFORMATION
Main features
• No assembly required, the system ships ready to mount to a wall
• Hinged cabinet opens away from the wall for ease of equipment Installation
• Accessibility from both the front and rear for simplified diagnostic, maintenance and
service of devices housed inside the enclosure
• Pivoting frame with locking mechanism swings out 180 degrees
• Features a fully welded frame construction reinforced with heavy gauge steel, specially
designed to support heavy equipment
• 132lb (60kg) maximum static load capacity and 66lb (30kg) maximum dynamic load
capacity
Caution: for dynamic weight applications, do not open the door if the cabinet load
rating is equivalent to or greater than 132lb (60kg)
• Toolless, reversible glass door installation
• Solid and removable side panels
• Standard square-punched mounting rails for faster equipment loading
• The front door can turn 180 degrees
• U-rack units are numbered front and back for easy equipment installation
• Finished surface to prevent damage caused by rust and other external factors
• High-grade, cold-rolled steel structure with a 5-year warranty
For support and to find out more about our complete line of products and solutions,
we invite you to visit us at nexxtsolutions.com.
ELECTRICAL
SHOCK
HAZARD.
DANGER All parts of the unit must be properly grounded to the frame
of the enclosure and connected to the Common Bonding
Network (CBN) of your facility.
1. Introduction
Thank you for purchasing the welded swing frame wallmount cabinet system from
Nexxt Solutions. This enclosure is made up of heavy-gauge steel and a sturdy mounting
frame. It also features a tempered-glass front door, with lockable access to keep
network gear and communication cabling safe and properly organized. Each enclosure
supports optional fans to ensure optimum ventilation inside the unit.
Available with 6, 9, 12, 15 and 18 rack spaces, these enclosures are designed for
housing patch panels, switches, PDUs and any standard 19in equipment where floor
space is at a premium. Flexible and versatile, our cabinets come fully assembled for
rapid deployment, offering a practical and cost-effective solution for applications
requiring protection, structural integrity and cable management capabilities.
