Nextar X4B Manuel utilisateur

，

POWER SUPPLY:

Connect the supplied adapter to the side of the unit in the slot marked “DC 5V IN”. Plug

the two-prong end of the power cord into an AC outlet or the cigarette lighter socket of

the vehicle. If you have difficulty inserting the plug, turn it over and reinsert it. If the unit

will not be used for a long time, disconnect the plug from the socket.

NOTE:

Before plugging the power cord into an AC outlet or a cigarette lighter socket of vehicle,

make sure that all the connections have been made.

CAUTION: These servicing instructions are for use by qualified service personnel only.

To reduce the risk of electric shock, do not perform any servicing other than that

contained in the operating instructions unless you are qualified to do so.

Refer to service manual for servicing instructions. To reduce the risk of fire or electric

shock, do not expose this apparatus to rain or moisture.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of uninsulated “dangerous voltage”

within the product’s enclosure that may be of sufficient magnitude to

constitute a risk of electric to persons.

The exclamation point within an equilateral triangle is intended to alert the

user to the presence of important operating and maintenance (servicing)

instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OF MOISTURE.

Important Safety

Instructions

NOTES

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with a damp cloth.

7) Do not block any of the ventilation openings. Install in accordance with the

manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or

other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A

polarized plug has two blades with one wider than the other. A grounding type plug

has two blades and a third grounding prong. The wide blade or the third prong is

provided for your safety. When the provided plug does not fit into your outlet,

consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of

time.

14) Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate normally, or has

been dropped.

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with

liquids, such as vases, shall be placed on the apparatus.

Important Safety

Instructions

Warning

Failure to avoid the following potentially hazardous situations may result in injury or

property damage.

The unit is designed to provide you with route suggestions. It does not reflect road

closures or road conditions, traffic congestion, weather conditions, or other factors that

may affect safety or timing while driving.

Use the unit only as a navigational aid. Do not attempt to use the unit for any purpose

requiring precise measurement of direction, distance, location, or topography. This

product should not be used to determine ground proximity for aircraft navigation.

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

The images in this manual are only for reference and they may be

different from the actual ones.

Important Safety

Instructions

Accessories List

ITEM

NAME

QTY

Owner’s Manual

AC Adaptor

Car Adaptor

Mounting Bracket

USB Cable

Mounting cradle

Touch Pen

Dashboard mount disk

Pouch

NOTE

Accessories and their parts numbers are subject to modification without prior notice due

to improvements.

Accessories

…………………………………….………..1

……………………………….………..…...4

……………………………….………….....6

……………………………….……….…....8

…………………………….……….….….10

……………………………….……………12

…………………………….………………16

……………………………….……………18

……………………………….…………...20

……………………………….…………...28

……………………………….…………...29

………………………………………….…31

Important Safety Instructions

System Connections

Power Supply Preparation

Troubleshooting

Specifications

Accessories

View of Main Unit

Use of the Mount Accessories

Contents

Playing Music

Photo Viewer

General Setup

Bluetooth Function

Front and Side panel

1. POWER button

Press the power button for longer time to enter or exit the standby mode.

2. Volume Control

Used to adjust the volume of the headphone and speaker.

3. Headphone Jack

Used to connect headphones for private listening. When the headphones are

connected to this jack, the speaker will be turned off automatically.

4. DC 5V Input Jack

Used to connect to the supplied car adapter.

5. Charge Indicator

When charging the battery, it is red. When the battery is fully charged, it turns

green.

6. LCD Screen

7. USB Port

Used to connect to the USB device.

8. Microphone Hole

9. Card Port

Insert the SD card into the port.

View of Main Unit

Rear View

10. External GPS Antenna Jack

Connected to the external antenna (optional).

11. ON/OFF Switch

Used to switch power on or off.

View of Main Unit

Always ensure that the unit and any other external device connected to the unit are

switched off and unplugged from the power supply before you attempt to connect

the unit to any external device.

Connecting to PC

The unit is designed with a USB port which allows you to connect the unit to PC for map

updating. See the below figure for details:

System requirements:

-Windows 98SE, ME, 2000 and XP

(Driver required for Windows 98SE)

-DVD Rom Drive (for map upgrade purposes)

-Intel Pentium II 233 Mhz

-64 MB RAM

-50 MB available hard drive space

-Available serial port and/or USB Port

-256-color display adapter and monitor

(16 bit color required)

In the near future map updates will be available for down load from our website. Please

check www.nextar.com periodically for the information on downloads.

System

Connections

Inserting SD Card

The unit is designed with SD Card jack which allows you to insert the SD card into the

unit as shown below:

To remove the card, gently press the card in with your fingernail. The card unlocks and

protrudes slightly. Then remove the card

Connecting to Earphones

Connect the earphones to the right side of the unit for private listening.

When earphone is connected, the speakers will automatically turn off.

Note: Excessively loud volume could damage your hearing. So turn down the volume

before you connect the earphones, and then raise the volume to comfortable level.

System

Connections

Using the AC Adaptor

The unit is supplied with an AC adaptor for powering it and charging its battery.

Note:

Turn unit's power off before unplugging.

In the case of using the adaptor, the LCD screen will be brighter than with the

rechargeable battery.

Using of Car Adaptor

The unit is supplied with a CarAdaptor for powering it while in a vehicle.

Attention

Place the unit in a proper position for viewing.

Disconnect the unit from the CarAdaptor when starting the vehicle.

Your portable GPS unit comes with a built-in rechargeable battery. Please see details in

the following segment.

Power Supply

Preparation

Connect the Car Adaptor Power Plug to

the unit’s power jack and plug the other

end to the vehicle’s 5V accessory/

cigarette socket, as shown on the right

figure.

1. Connect AC adaptor to the right side

of the unit in the jack marked DC 5V

IN, as shown on the right.

2. Plug the two-prong end of the power

cord into a grounded electrical

outlet.
