New Digital T2 01 Manuel utilisateur

This symbol on the product means that your equipment is suitable only for indoor use.

1. Read and follow these instructions.

2. Do not use this apparatus near water, heat sources, do not expose to direct sunlight and the

temperatures higher than in a normal household. For Indoor use only!

3. Clean only with a dry cloth, protect from moisture and dirt, do not cover the ventilation grid.

4. Operate this product only from the type of power source indicated on the label. Protect the

Device and the power cord from the moisture, physical damage.

5. Unplug this apparatus during lightning storms or when unused for a longer period.

6. Do not disassemble the unit or try to insert any extraneous items into it.

7. Refer all servicing to qualified service personnel only. Servicing is required when the apparatus

has been damaged in any way, including damage to the mains cord or plug, if the unit was

exposed to liquids or moisture, has been dropped, or not operating correctly.

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

Risk of electric shock!

DO NOT OPEN!

ATTENTION

Risque de choc electrique!

NE PAS OUVRIR!

This symbol indicates that dangerous voltages constituting a risk of electric shock are

present within this unit.

This symbol on the product or in the instructions means that your electrical and

electronic equipment should be disposed at the end of life separately from your

household waste. There are separate collection systems for recycling.

For more information, please contact the local authority or your retailer where you

purchased the product.

This symbol indicates that this product incorporates double insulation between

hazardous mains voltage and user - accessible parts. When servicing use only identical

replacement parts.

This symbol indicates that there are important operating and maintenance

instructions in the literature accompanying this unit.

* NOTE: this Tuner is supporting the reception of Free To Air

programs only

FRONT AND REAR PANELS AND CONNECTIONS DIAGRAM

Front panel and controls

Rear panel

and connection diagrams:

1 POWER – Switches between working and Standby mode

2 CH- switches TV program up the list

3 CH+ switches TV program down the list

4 IR (Infrared remote control) window

5 USB -- connector for an external USB memory device (USB 2.0 support) located on the right

side

1 2 3 4

1 RF IN: This socket connects to your external Aerial.

2 HDMI: High definition audio and video output used to connect to the TV HDMI socket

3 TV SCART – analog Audio/video output for connection to TV set

1 2 3

HIGH DEFINITION DIGITAL TERRESTRIAL

DVB-T2/T TUNER WITH H264 SUPPORT

CONTENTS OF THE PACKAGE

Tuner Unit, Remote Control Unit, 2 pcs AAA type Batteries,

User Manual

HDMI cable

SCART

cable

1. POWER: Turns the receiver On/Standby.

2. REC: Record button.

3. ASPECT: Change aspect ratio 4:3/16:9.

4. SUB: Display subtitle options (availability depends on the channel).

5. AUDIO: Change the Audio Language Track in Audio Menu.

6. MENU: Opens the main menu, in the menu you will get one step back.

7. Press to move the cursor when the menu window is on. When menu window

is off - use arrow buttons Up/Down for switching the channels; Left/Right buttons

to control the Volume.

8. BACK: Go back to the previously viewed channel.

9. STOP: Stop playback.

10. VOL+/ VOL-: Adjust the volume +/-.

11. TTX: Switch on Teletext, if the current channel has this option, and use EXIT key

to quit Teletext. REW: Fast backward.

12. MUTE: Mutes audio output of the receiver.

13. TIMER: Access to the timer.

14. V-FORMAT: Switch the HDMI 720P and 1080i.

15. USB: Direct access to Media files when an external USB memory device is connected.

16. PRGM: PROGRAM Shows program timetable.

17. INFO: Shows the current channel information. Press twice for program

and technical information.

18. OK: Confirmation of Menu Items. Menu Off: Displays the current channel list

Confirmation of Menu Items.

19. EXIT: Exits from the menu or sub-menu.

20. CH+/CH-: Menu off: Change Channel +/-. Menu on: Move the up/down menu cursor.

21. PLAY/PAUSE: Start playback from the selected file.

TIMESHIFT: If the unit has an attached an USB device, goes to Timeshift mode.

Requires external USB memory device

22. TV/RADIO: Switch between Digital Radio and TV modes.

Dubbed function FF: Fast forward in Media player mode

1. MUTE: Mutes audio output of the receiver.

2. FAV: Displays your favorite channels list.

3. SUBTITLE: Display subtitle options (availability depends on the channel).

4. <0>-<9>: Numeric keys.

5. MENU: Display the main menu on the TV screen, and press again to close the menu.

6. OK: To confirm the current setting, or display all programs in no-menu mode.

7. EPG: Shows the Electronic Program Guide.

8. Pg Dn/Pg Up (PAGE+/PAGE -): To browse pages inside the program list.

9. VOL- /VOL+: To decrease/increase volume.

10. REV/FWD: Fast backward/Fast forward.

11. PREV/NEXT: Skip backward/Fast forward.

12. PLAY

13. PAUSE

14. REC: Record button. Requires external USB memory device.

15. TIMESHIFT: If the USB memory device is connected to the receiver,

goes to Timeshift mode.

16. ZOOM: Increases the size of the image.

17. ASPECT: Change aspect ratio 4:3/16:9.

18. POWER: Switch the receiver in and out of Standby mode.

19. TTX: Switch on Teletext, if the current channel has this option, and use EXIT key to quit Teletext.

20. INFO: Display information about the current channel.

21. RECALL: Go back to the previously viewed channel.

22. LIST: List of channels.

23. EXIT: Use this key to quit the current menu.

24. Press to move the cursor when the menu window is on. When the menu window

is off - use arrow Up/Down buttons for switching the channels; Left/Right buttons

to control the Volume.

25. GOTO: Select time in Media player mode.

26. CH-/CH+: Program changing keys.

27. LANG: Change the Audio Language Track in Audio Menu

(availability depends on the channel).

28. STOP

29. REPEAT: Repeat play.

30. TV/RADIO: Switch between Digital Radio and DVB-T modes.

31. TIMER: Access to the timer.

32. V-FORMAT: Switch the HDMI 720p and 1080i.

DESCRIPTION OF THE REMOTE CONTROL UNIT (RCU)

Remote control unit Version 1

DESCRIPTION OF THE REMOTE CONTROL UNIT (RCU)

Remote control unit Version 2

Please insert the batteries into the Remote control unit, arrange the necessary connections

and plug in the unit to mains. The installed TV Antenna should guarantee the minimum signal

strength not less than 60% and the signal quality not less than 80% according to the device

indicator. Please check the Manual search section below. If you are using the unit for the first

time or after restoring the factory settings, the installation guide will appear on the TV screen

if the device is connected properly.

Follow these steps using the Remote Control Unit:

Select the language, select the country of residence, further select OK for channel search.

The unit will start searching for available TV programs and will save the list in the memory,

once found. Please use Password 000000 for restoring the factory settings.

FIRST TIME INSTALLATION

How to use the Remote Control Unit keys when browsing the Welcome Menu:

1. Press [Up/Down] key to move the highlight.

2. Press [Left/Right] key to select region, language.

3. Move the highlight to [Channel Search] item and press [OK] key to begin the auto scan.

4. Press [Exit] key to exit the welcome page and enter into the main menu.

Please use the same principles when browsing, selecting, and exiting the other Menu Sections.

MAIN OSD (ON-SCREEN DISPLAY) MENU

Press the [Menu] key to enter the main menu list, it includes the list:

1. Program settings

2. Picture settings

3. Search settings

4. Time settings

5. Options settings

6. System settings

7. USB Media Menu

To access the menu, press the MENU button and select [Menu Item]. using the RIGHT/

LEFT keys to navigate through the menu. Use Up/Down keys to navigate into the Submenus.

Program Management Settings

The menu provides options for the Program Management Settings. Select an option

and press OK or RIGHT to adjust that setting. Press the EXIT button to exit the menu.

(a) Program edit Menu.

(b) Program Guide Menu.

(recommended default setting).

(d) LCN (Logical channel numbering) enabling/disabling LCN according to

country requirements.

To Edit TV Program list:

Enter program Edit Menu (use PIN code 000000 to access)

The edit functions are listed in the lower part of the Edit Menu.

Use Color buttons or Back/Fav buttons to perform Move, Skip, Lock, Delete,

Rename the programs.

Select the TV program you would like to edit

Select one of the Edit functions (Lock; Skip; Move; Delete, Rename) by pressing

the edit buttons accordingly.

Perform editing, press the Edit button a second time to disable function after editing is finished.

NOTE: the edited program lists are deleted automatically when using

Automatic Program Search, or Factory Reset functions.

NOTE: some Tuners may not have the FAV button available on the RCU,

therefore the FAV function is not available to use.

Program Guide Menu (can be accessed directly using PRGM button)

The program guide window allows to viewing the TV program schedule (main window) and see

the Program description on the right side window. The TV programs can be selected

by using Left / Right arrow buttons. The pages on the program description are chosen

using color buttons (page UP/page DOWN).

The Book function allows programming the Tuner to turn ON / OFF at selected times

(Schedule the Timer function).

Confirm

EXIT OK

EXIT

Picture Setting Menu

To access the menu, press MENU then select [Picture] using the RIGHT/LEFT key.

The menu provides options to adjust the video settings. Press UP/DOWN to

select an option and press RIGHT/LEFT to adjust that setting. Press EXIT to exit

the menu.

(a) Aspect Ratio– allows choosing the 16:9 or 4:3 aspect ratios to fit the

picture into the TV screens accordingly.

(b) Resolution (HDMI output resolution) – allows choosing the best picture

quality for the TV screen.

recommended to use.

NOTE: When using the Tuner with 16:9 LCD/LED TV sets it is recommended to

use Video resolutions of 1080i or 1080p to achieve the best picture quality via

HDMI port. The AUTO Aspect Mode is recommended to use.

When using the Tuner with 4:3 TV (old CRT) sets it is recommended to use AUTO

Aspect mode or 4:3 Letterbox aspect mode to achieve the best picture fitting

for the 4:3 screen.

(a) Auto Search - allows searching for TV channels automatically on all

frequency ranges. Select this mode and press OK to launch.

When launched – Automatic search deletes all listed earlier programs and

creates a new list from the programs found.

The Channel search window will appear with the list of Channels found.

Before launching the automatic search it is recommended to check the signal

level using Manual Search Menu, in order to ensure the received signal level

and quality are enough to find and watch the broadcasted TV programs. When

search is launched - the program Channel search window will appear with the

list of Channels found. The new programs will be saved in ALL program List.

Channel Search

To access the menu, press MENU and select [Search Channel] using the

RIGHT/LEFT keys.

This menu provides options to adjust the search channel settings.

Press UP/DOWN to select an option and press RIGHT/LEFT to adjust the setting.

Press EXIT to exit the menu.

(a) Auto search – launches Automatic search.

(b) Manual search- Manual search Menu allows setting program search on

selected frequency.

before launching the search.

(d) Antenna power – allows enabling/disabling of the +5V power on RF IN for

active antenna.

(b) Manual search:

Select the channel Number of the Broadcasted TV Package

Check the Signal Strength and Quality is high enough to receive the broadcasted

program Package.

NOTE: to ensure good reception conditions it is highly recommended to install the

Antenna to ensure Signal strength (level) is not less than 80% and Signal quality not less

than 80%. The levels must be stable during all times. Lower signal Intensity and quality

levels may result in poor Video/Audio quality of received programs.

To select Search- press OK for channel search.

The program Channel search window will appear with the list of Channels found.

The new programs will be saved in ALL program List.

NOTE: selection of the country of Residence is strongly recommended before

launching the search, as it will impact the Program Numbering.

For the Countries with LCN on requirement – the programs found will be listed according

to their LCN number. For the countries without LCN on – the programs

found will be listed according to Frequency, from lower to higher.

with standard 5V powering. The use of an additional Antenna power adapter is not

necessary in this case.

NOTE: the maximum supported current on this port is 50mA

Time Settings Menu

(a) Time offset – allows setting time offset Automatically (recommended) and

Manually (in case the Automatic time setting does not match the local time).

(b) Time Zone – allows setting time zone (used in Manual Time offset mode).

after a certain viewing time (selectable from 1 to 12 Hours).

(d) Power On/Off – ON-OFF timer function – allows setting a timer for automatic

powering ON or powering OFF.

Option settings Menu

To access the menu, press MENU, select [Option] using the RIGHT/LEFT keys.

The menu provides options to adjust the OSD Language. Subtitle Language and Audio

Language. Audio coaxial output options are also available.

Select an option and press RIGHT/LEFT to adjust the setting.

Press EXIT to exit the menu.

(a) OSD (On-Screen Display) Language – allows selecting the Language for Main and

additional menu items

(b) Subtitle Language –allows selecting the preferred language for subtitling services

(d) Digital Audio – allows selecting the Digital Audio Modes for the

Coaxial Digital Audio (SPDIF) and HDMI Outputs or turn it off.

System Settings Menu

To access the menu, press MENU and select [System] using the RIGHT/LEFT keys.

The menu provides options to adjust the system settings.

Press the UP/DOWN key to select an option and press RIGHT/LEFT to adjust the

setting.

Press EXIT to exit the menu.

(a) Parental Guidance (PG) – allows setting PG age rating to block the viewing of certain

programs (upon availability from Broadcaster)

(b) Set Password – allows changing the default password (000000). The master password

in case the new password is forgotten

is 888888.

(Initial installation). Requires PIN code to

proceed, clears all saved programs and program lists.

(d) Information – allows viewing System information of the tuner, the HW/SW versions.

(e) Software update – allows updating system SW via external USB port. Requires special

dedicated SW file available only from Manufacturer.

This function is used exclusively in cases recommended by Manufacturer and following the

instructions provided by the Manufacturer.

(f) Recall list – allows to turn on/off the Recall function for the list of last viewed programs.

When enabled – works together with “Back” button.

USB

To access the menu, press the MENU button and select [USB] using the RIGHT/LEFT

keys. The menu provides options to playback Multimedia files.

*NOTE: The unit will only support USB devices with FAT32 | NTFS file system.

The supported file formats are:

.mp3 – for music files

.jpeg – for picture

.avi; .mkv; .ts – for video files

Some files of these formats may be unsupported due to different

compression methods and codecs used.

(a) Multimedia – allows to entering Media player Menu

(this Menu is accessible directly via USB button).

Multimedia Menu allows to choosing the Multimedia file format

(music, picture, video) to be reproduced.

(b) Photo configure – allows configuring the Picture viewing format and Slide show

*NOTE: Not all subtitle formats and language fonts may be supported.

(d) PVR configure – allows to enter settings for Personal Video recording configuration.

RECORD (PVR) function

(works only with external USB memory device connected)

*NOTE: To achieve the quality recording the USB memory device must support at least CAT10

writing/reading speed.

Press REC button during TV viewing mode, the Record mode will be activated and the

program will be recorded.

The Recording process is marked with the yellow dot in the left upper side of the screen:

To stop recording press Stop button, the OSD pop-up will appear asking if you want to stop

recording, press OK to stop.

Or choose cancel to continue recording.

The records can be found in PVR Menu of the Multimedia player, they are stored in HBPVR

folder on USB device.

Timeshift mode

(works only with external USB memory device connected)

To enter Timeshift mode press “Pause” button on the RCU.

The picture will freeze and the Pause sign will appear on the screen. Further Timeshift mode can

be managed using Play, FF, and REW buttons.

After pressing Play button the Video will play and the Timeshift line will appear on the screen,

showing the played part (red) and recorded part ( blue)

To stop the Timeshift mode press STOP button, the device will return to normal TV viewing

mode.

*NOTE: The Timeshift mode records are not saved.

Other useful functions

Program Information bar:

Current/next event and signal quality information:

Press INFO control button two times to display the Current/next event description and

Signal Quality Information of the viewed program.

Now/next event and signal quality information:

Press INFO control button two times to display Current/next event description and

Signal Quality Information of the viewed program:

Audio language Menu (Accessible via Audio button).

Language availability depends on Broadcaster.

Subtitle language Menu (Accessible via Subtitle button)

Language availability depends on Broadcaster.

Teletext Function:

Press TTX button on the Remote control Unit to activate TTX service window

(if available from Broadcaster)

*NOTE: when browsing Teletext services allow some time, up to 20-30 s for the

requested page to be loaded

THE MANUFACTURER RESERVES THE RIGHT TO CHANGE THE CONFIGURATION,

TECHNICAL OR ANY OTHER PARAMETERS WITHOUT PRIOR NOTICE

TUNER&CHANNEL

DECODER

TRANSPORT STREAM

PROFILE LEVEL

VIDEO PROFILE

AND LEVEL

INPUT RATE

VIDEO FORMATS

AUDIO FORMAT

VIDEO OUTPUT

MEDIA PLAYER

CONNECTION

MAIN POWER CABLE

TUNER

POWER SUPPLY

HDMI x 1; SCART x 1

USB 2.0 FULL SPEED x 1

ANTENNA INPUT x l

FIXED TYPE

MP3/JPEG/BMP

SCART, HDMI

MPEG Layer l & ll, Dolby Digital Plus (E-AC3)

4:3/16:9 SWITCH ABLE

Max. 80Mbit/S @ MPEG2

MPEG-4 AVC/H.264

MPEG-1 MPEG-2 MP@ML

MPEG-2 ISO/IEC 13818-1

SIGNAL LEVEL: - 10 - 70 dbm

(UHF)

174MHz 230MHz(VHF) 470MHz-862MHz

FREQUENCY RANGE

RF INPUT CONNECTOR xl

USB

HDMI; SCART

INPUT VOLTAGE

STANDBY CONSUMPTION

POWER CONSUMPTION MAX. 6W (USB Max Load: DC 5V, 300mA)

MAX. 0.5W

220 -240v 50/60HZ

PROBLEM Potential reasons What to do

No picture

Screen shows

No Signal

No sound from

speaker

Only sound, no

image on the screen

Remote Control

is not responding

Picture is breaking up

Power isn’t connected

The power switch is not on

Aerial cable is faulty

No or incorrect connection with audio cable

Sound on mute

No or incorrect connection with AV cable

The program is a radio program

The battery is exhausted

Remote Control is not facing or close enough

to the Set Top Box

The signal is too weak

Connect the power.

Switch on the power

Check aerial cable and connections

Connect the audio cable correctly

Turn off mute function

Make sure cables are connected correctly

Press <TV/RADIO> key to shift into TV mode

Change battery

Adjust the position of the Remote Control

and move closer to the unit

Check aerial cable and

connections

TROUBLESHOOTING

www.newdigital.lt

Este símbolo no produto significa que o seu equipamento se destina apenas

a ser usado em espaços interiores.

INSTRUÇÕES IMPORTANTES DE SEGURANÇA

CAUTION

Risk of electric shock!

DO NOT OPEN!

ATTENTION

Risque de choc electrique!

NE PAS OUVRIR!

Este símbolo indica que estão presentes nesta unidade voltagens perigosas,

que representam risco de choque elétrico

Este símbolo no produto ou nas instruções significa que o seu equipamento

elétrico e eletrónico deverá ser descartado quando chegar ao fim da sua vida útil,

separando-o do restante lixo doméstico. Existem sistemas de recolha seletiva para

reciclagem. Para mais informações, contacte as autoridades locais ou o revendedor

onde comprou o produto

Este símbolo indica que este produto incorpora isolamento duplo entre a alta tensão

e as peças que estão ao alcance do utilizador. Ao fazer a manutenção, use apenas

peças de reposição idênticas

Este símbolo indica que existem instruções importantes de utilização e manutenção na

literatura que acompanha esta unidade.

*NOTA: este sintonizador capta apenas programas

de acesso livre

PAINÉIS DIANTEIRO E TRASEIRO E DIAGRAMA DE LIGAÇÕES

Painel frontal e controlos

Painel traseiro e diagramas

de ligação:

1 POWER – Alterna entre os modos de funcionamento e suspensão

2 CH- – Muda para um programa de TV acima na lista

3 CH+ – Muda para um programa de TV abaixo na lista

4 IR – Janela de controlo remoto por infravermelhos

5 USB - Conetor para um dispositivo USB de memória externo (USB 2.0),

localizado do lado direito

1 2 3 4

1 RF IN: esta entrada serve para ligar a sua antena externa

2 HDMI: saída de áudio e vídeo de alta definição, utilizada para ligar a tomada HDMI

3 TV SCART – saída analógica de áudio/vídeo para ligar o aparelho de TV

1 2 3

SINTONIZADOR DIGITAL TERRESTRE DE ALTA

DEFINIÇÃO DVB-T2/T COM H264

CONTEÚDO DA EMBALAGEM

Unidade do sintonizador, unidade de controlo remoto,

2 pilhas de tipo AAA, manual do utilizador

HDMI cable

SCART

cable

1. Leia e siga estas instruções.

2. Não use este aparelho perto de água, fontes de calor, não o exponha à luz solar direta

nem a temperaturas superiores às de uma casa normal. Deve ser usado apenas

em espaços interiores!

3. Limpe-o com um pano seco, proteja-o da humidade e da sujidade, não tape

a grelha de ventilação.

4. Utilize este produto apenas com o tipo de fonte de alimentação indicado no rótulo.

Proteja o dispositivo e o cabo de alimentação da humidade e de danos físicos.

5. Desligue-o da tomada durante trovoadas elétricas ou quando não for utilizado

durante um longo período de tempo.

6. Não desmonte a unidade nem tente inserir-lhe peças que não lhe pertençam.

7. A manutenção deve ser feita apenas por técnicos qualificados. Terá de reparar

o aparelho se ele sofrer algum tipo de danos, incluindo danos ao cabo de alimentação

ou ficha, se a unidade tiver sido exposta a líquidos ou à humidade, se tiver caído ou se não

estiver a funcionar corretamente.

DESCRIÇÃO DA UNIDADE DE CONTROLO REMOTO (UCR)

Unidade de controlo remoto Versão 1

DESCRIÇÃO DA UNIDADE DE CONTROLO REMOTO (UCR)

Unidade de controlo remoto Versão 2

1. MUTE: silencia a saída de áudio do recetor.

2. FAV: apresenta a sua lista de canais preferidos.

3. SUBTITLE: oferece opções de legenda (a disponibilidade depende do canal).

4. <0>-<9>: teclas numéricas.

5. MENU: exibe o menu principal no ecrã de TV; prima de novo para fechar o menu.

6. OK: para confirmar as definições escolhidas ou para exibir todos os programas

no modo sem menu.

7. EPG: mostra o guia eletrónico de programação.

8. Pg Dn/Pg Up (PAGE+/PAGE -): para percorrer as páginas da lista de programas.

9. VOL- /VOL+: para aumentar/diminuir o volume.

10. REV/FWD: recuo/avanço rápido.

11. PREV/NEXT: retroceder/avançar.

12. PLAY

13. PAUSE

14. REC: botão de gravação. Requer um dispositivo de memória USB externo.

15. TIMESHIFT: se o dispositivo de memória USB estiver ligado ao recetor,

ele vai para o modo “Timeshift”.

16. ZOOM: aumenta o tamanho da imagem.

17. ASPECT: muda a proporção entre 4:3 e 16:9.

18. POWER: liga e desliga o modo de suspensão.

19. TTX: liga o teletexto, se o canal tiver essa opção; prima a tecla EXIT

para sair do teletexto.

20. INFO: apresenta informações sobre o canal que está a ver.

21. RECALL: volta ao canal que viu anteriormente.

22. LIST: apresenta uma lista de canais.

23. EXIT: use esta tecla para sair do menu atual.

24. Prima para mover o cursor quando a janela do menu estiver aberta. Quando

a janela estiver fechada, use os botões com as setas para cima/baixo para mudar de canal;

os botões para a esquerda/direita permitem- lhe controlar o volume.

25. GOTO: selecione a hora no modo de reprodutor multimédia.

26. CH-/CH+: teclas para mudar de programa.

27. LANG: muda a faixa de idioma de áudio no menu de áudio

(a disponibilidade depende do canal).

28. STOP

29. REPEAT: repete a reprodução.

30. TV/RADIO: alterna entre os modos de rádio digital e DVB-T.

31. TIMER: acesso ao temporizador.

32. V-FORMAT: alterna entre o formato HDMI 720p e 1080i.

1. POWER: liga o recetor ou põe-no em suspensão.

2. REC: botão de gravação.

3. ASPECT: alterna entre as proporções 4:3/16:9.

4. SUB: apresenta opções de legendas (a disponibilidade depende do canal).

5. AUDIO: muda a faixa do idioma de áudio no menu de áudio.

6. MENU: abre o menu principal; no menu, recuará um passo.

7. Prima para mover o cursor quando a janela do menu estiver aberta.

Quando estiver fechada, use os botões com as setas para cima/baixo para

mudar de canal; os botões para a esquerda/direita permitem-lhe controlar o volume.

8. BACK: volte ao canal que viu anteriormente.

9. STOP: interrompe a reprodução.

10. VOL+/ VOL-: ajusta o volume +/-.

11. TTX: liga o teletexto, se o canal tiver essa opção; prima a tecla EXIT para sair

do teletexto. REW: recuo rápido.

12. MUTE: silencia a saída de áudio do recetor.

13. TIMER: dá acesso ao temporizador.

14. V-FORMAT: alterna entre os formatos HDMI 720P e 1080i.

15. USB: dá acesso direto aos ficheiros multimédia ao ligar um dispositivo

de memória USB externo.

16. PRGM: mostra o horário do programa.

17. INFO: mostra informações sobre o canal. Prima duas vezes para

ver informações sobre o programa e as informações técnicas.

18. OK: confirmação de itens do menu. Menu Off: apresenta a lista atual de canais.

19. EXIT: sai do menu ou do submenu.

20. CH+/CH-: Menu off: muda de canal +/-. Menu on: move o cursor

para cima/baixo no menu.

21. PLAY/PAUSE: começa a reproduzir o ficheiro selecionado.

TIMESHIFT: se a unidade tiver um dispositivo USB ligado, assume o modo “Timeshift”.

É necessário um dispositivo de memória USB externo.

22. TV/RADIO: alterna entre os modos de rádio digital e TV.

Função FF: avanço rápido no modo de reprodutor multimédia.

Table des matières

Langues :

Autres manuels New Digital Tuner TV

New Digital

New Digital T2 265 HD Manuel utilisateur

Manuels Tuner TV populaires d'autres marques

KWorld

KWorld PE310SE Manuel utilisateur

COMPRO

COMPRO M505 - STARTUP Manuel utilisateur

Genius

Genius TVGo DVB-T31 Manuel utilisateur

Zinwell

Zinwell ZAT-332 Manuel utilisateur

RGBlink

RGBlink TAO 1mini-HN Manuel utilisateur

TViX

TViX PVR R-2200 Manuel utilisateur

Xavix

Xavix Xavixport Manuel utilisateur

Peak

Peak NET-TV Manuel utilisateur

Fracarro

Fracarro SAF-HD 10 Manuel utilisateur

Eonon

Eonon E0770 Manuel utilisateur

Hauppauge

Hauppauge WinTV-NOVA-T-Stick Manuel utilisateur

Digital Devices

Digital Devices Octopus Net Manuel utilisateur

Gericom

Gericom USB 2.0 DVB-T Tuner Manuel utilisateur

ADS Technologies

ADS Technologies PTV-334 Manuel utilisateur

Manta

Manta DVBT013T2 Manuel utilisateur

Kenwood

Kenwood KTC-D500E Manuel utilisateur

AVIWEST

AVIWEST DMNG PRO 100 Manuel utilisateur

Abode

Abode IP Streaming Camera Manuel utilisateur
