Scoreboard Operator’s Instructions

MPC Control

Home

Score

Guest

Score

Start

Clear

ConfirmCancel

Blank

Yes

Chronometer

(Time of Day)

Options

Time Out Timer

Time

Alternate Time

Control

Horn

Set

Time

Off

Model Code 431

Volleyball

Home

Games

Won

Guest

Games

Won

Adv.

Game

Number

Serve

Some features on the keyboard overlay may not be included on the particular model being operated.

Since 1934

Retain this manual in your permanent files

These Instructions are for the Following Models:

LED models:

2700- Volleyball

2700-F715,F712- Volleyball

2710- Volleyball

2710- F715,F712- Volleyball

2715- Volleyball

2715- F715,F712- Volleyball

2740- Volleyball

2740- F715,F712- Volleyball

2750- Volleyball

2750- F715,F712- Volleyball

2760- Volleyball

2760- F715,F712- Volleyball

2770- Volleyball

2770- F715,F712- Volleyball

2775- Volleyball

2775- F715,F712- Volleyball

9710

2780

2781

2785

LED models:

2600-Volleyball

2600-F515, F512-Volleyball

2610-Volleyball

2610- F515, F512-Volleyball

2615-Volleyball

2615- F515, F512-Volleyball

2640-Volleyball

2640- F515, F512-Volleyball

2650-Volleyball

2650- F515, F512-Volleyball

2670-Volleyball

2670- F515, F512-Volleyball

2675-Volleyball

2675- F515, F512-Volleyball

9510

9515

LED models:

230 Portable-Volleyball

2500-Volleyball

2500-D-Volleyball

2500-F515, F512-Volleyball

2500-D-F515, F512-Volleyball

2500-A4-Volleyball

2500-A4-D-Volleyball

2500-A4-F15, F12A-

Volleyball

2500-A4-D-F15, F12A-

Volleyball

2550-Volleyball

2550-D-Volleyball

2550-F515, F512-Volleyball

2550-D-F515, F512-Volleyball

2560-Volleyball

2560-F515, F512-Volleyball

Incandescent

models:

2050-Volleyball

2250-Volleyball

2400-Volleyball

2400-F15, F12A-Volleyball

2400-A4-Volleyball

2400-A4-F15, F12A-

Volleyball

2450-Volleyball

2450-F15, F12A-Volleyball

2460-Volleyball

2460-F15, F12A-Volleyball

9410

Thank You

Thank You for choosing NEVCO. We appreciate your business.

The following instructions will help you become familiar with the operation and features of the scoreboard system.

Please take a few minutes to study this manual, and to practice with the control.

If you ever have any questions or comments, please call or email us.

NEVCO, Inc.

301 East Harris Avenue

Greenville, IL 62246-2151 USA

USA TOLL-FREE 800-851-4040

CANADA TOLL-FREE 800-461-8550

International Telephone: +1-618-664-0360

Website: www.nevco.com

Email: [email protected]om

Figure 1 – MPC Control (front view)

A. MPC Control Can operate scoreboards for a wide range of sports and features.

B. Power Supply 9 V DC (included with the control)

C. Overlay Fits on top of control to label the keys (included with system)

D. Hand Held Switch A TCS-5 time control switch is included with each control.

Other switches are included with the accessories they operate.

E. 3 character Model Code location This code sets up the control for your scoreboard model and sport

F. Keypads Left and Right (20 keys each)

G. 16 character display Bright LED for better visibility

H. Power On / Off switch Removes power from the control only (does NOT turn power off to

scoreboard)

I. Jack for hand held switch One on each side of control (use either jack for any Hand Held switch)

F G

Figure 2 – MPC Control (rear view)

A. MPC Control Universal – to change sports, change the Overlay and enter the new Model Code.

B. Power Supply 9 V DC (included with control)

C. Overlay For your scoreboard model (included with system)

J. Coiled Cord Stretches to over 4 ft. (included with switch)

K. Socket for coiled cord Makes it easy to replace the cord

L. LED test indicator Verifies that the Hand Held switch is working

Remote push button switch Function depends on type of Hand Held switch (on TCS-5 – sounds the horn)

N. Remote rocker switch Function depends on type of Hand Held switch (on TCS-5 – controls the time)

O. Output to scoreboard BNC connector for coax cable (use either or both as needed)

P. Jack for power input 9 V DC

C K

P B

TABLE OF CONTENTS

START UP PROCEDURE .............................................................................................................1

START

WHERE

TURNED

OFF

LAST? .........................................................................................1

BOOKMARK?................................................................................................................1

ENTER

YOUR

MODEL

CODE...................................................................................................... 1

QUICK START GUIDE .................................................................................................................3

KEYBOARD FUNCTIONS............................................................................................................ 4

OPTIONS .........................................................................................................................................9

PTIONS

HART

....................................................................................................................9

PTIONS

ENU

............................................................................................................10

TROUBLESHOOTING CHART................................................................................................ 13

GLOSSARY ................................................................................................................................... 14

MY BOOKMARK PROGRAM CHART....................................................................................16

APPENDIX (CHRONOMETER) ................................................................................................ 17

EXAMPLE .................................................................................................................................19

Set The Chronometer.............................................................................................................. 19

APPENDIX (SEGMENT TIMER)...............................................................................................21

EDITING

THE

SEGMENT

TIMER .........................................................................................22

Review the Segment List.........................................................................................................22

Add A Segment to the List ...................................................................................................... 22

Shorten the Segment List........................................................................................................23

Change the Length of a Segment........................................................................................... 23

EXAMPLES ...............................................................................................................................24

Act like an INTERVAL HORN ..............................................................................................24

Practice Drills..........................................................................................................................25

Typical Soccer Application.....................................................................................................26

Pre-Match Protocol for College Volleyball............................................................................ 27

ROUBLESHOOTING

HART

......................................................................................................28

SEGMENT

TIMER

LIST..................................................................................................29

START UP PROCEDURE

When you turn the control on, the traveling display prompts you to “START WHERE TURNED OFF LAST?”, “GO TO A

BOOKMARK?”, or “ENTER YOUR MODEL CODE”. Answer YES, NO, or enter the 3 character model code on the

overlay.

NOTE: Make sure the proper overlay for the scoreboard and sport or special function is in place on the control.

START WHERE TURNED OFF LAST?

If a power failure happens during a game, press YES to resume from the point the power failed. The control can detect

when power is failing and save the current data. (If the time was running when the power failed it will continue running as

soon as power is restored).

NOTE: Intended for recovery from a power failure only. To start a new game, enter the model code or go to a bookmark.

GO TO A BOOKMARK?

A bookmark makes a quick efficient way to start a new game or practice drill. If a bookmark has been saved for this

activity, answer YES to the bookmark question. The control will prompt for the “BOOKMARK #”. Press the number of the

bookmark you want to use (1 to 5). The control will load the configuration and data it had in it at the time the bookmark

was saved.

ENTER YOUR MODEL CODE

To start a new game or procedure, be sure the proper overlay is installed on top of the control. Enter the 3 character model

code located near the top center of the overlay.

NOTE: If your control does not have wireless capability:

The name of the Sport

[ VOLLEYBALL ]

will be displayed briefly, then the time and the direction it

will count

[ 0:00.0 DN ]

will be displayed, and the scoreboard(s) will turn on.

NOTE: If your control does have wireless capability:

The name of the Sport

[ VOLLEYBALL ]

will be displayed briefly.

The control will ask “

DO YOU WANT TO OPERATE WIRELESS?

”

If you answer

The time and the direction it will count

[ 0:00.0 DN ]

will be displayed, and the

scoreboard(s) will turn on.

If you answer

YES

The control will prompt

[ SELECT A GROUP ]

then display the first group that is

set up in the control. To see the next group name, press NO. When the desired group name is

being displayed press YES.

The time and the direction it will count

[ 0:00.0 DN ]

will be displayed, and the

scoreboard(s) will turn on.

NOTE: If the control displays the message “

THERE ARE NO GROUPS

DEFINED IN THIS SYSTEM KEY. TO CREATE A NEW GROUP

USE MODEL CODE 618 WITH THE SYSTEM KEY

MANAGEMENT OVERLAY

”, then, turn the control off and follow the instructions

that came with the System Key Management Overlay with model code 618 to set up the groups as

needed.

QUICK START GUIDE

With the scoreboard on and the control showing the time, you are ready to set the game number.

[ 0:00.0 DN ]

Set the game number

Press

The control will show

[ GAME # ]

Press

The control will show

[ GAME # 1 ]

You are now ready for the game to begin.

To set the serve indicator

Press

The control will show

[ SERVE ]

Press

The control will show

[ H SERVE ]

Press

The control will show

[ SERVE G ]

Please consult the following sections of this manual for more details, functions, and features.

Game

Numbe

Set

Serve

KEYBOARD FUNCTIONS

Use the

YES

key to respond to questions and to confirm data input.

Use the

key to respond to questions and to cancel an operation.

Use the

SET

key ahead of a function key to initiate the direct entry mode or to change the settings in OPTIONS,

CHRONOMETER, and TIME OUT TIMER, or to set the TIME, and other features. (For more details see

the description for the function.)

Press the

HORN

key to sound the scoreboard horn. Release the key to stop the horn.

The horn automatically sounds when the timer counts down to zero. (Auto Horn)

NOTE: The duration of the horn is limited to 4 seconds.

Press SET then HORN to disable or enable the AUTO HORN.

The control will prompt

[ AUTO HORN ? (Y/N) ]

. The default setting is auto horn on.

Press the

OPTIONS

key to see a scrolling report of the current system settings.

Press

SET

then

OPTIONS

to change the system configuration.

NOTE: See the section on OPTIONS for more details.

Options

Horn

Set

Yes

There are 10 TIME OUT Timers available. Timer 0 is preset to 30 seconds with a warning horn at 10

seconds.

Press TIME OUT TIMER START.

The display will prompt.

[_TIMER_#__(0-9)?___]

When you enter the desired number, the preset Time Out Time is displayed on the control, and on

the scoreboard if set to do so, and begins counting down. When only the warning time remains, a

warning horn sounds briefly (if set up). When the timer reaches zero, the horn sounds briefly again

and the time begins counting up on the control. Any time the Main Time is turned on, the Main

Time is restored to the display(s) and the Time Out Timer is canceled.

Press SET, then TIME OUT TIMER START

to set up a TIME OUT TIMER.

The display will prompt

[__TIMER_#__(0-9)?___]

Enter the number of the timer to

set up or overwrite. The control will prompt.

[__SET____MM:SS____]

Enter the total

length for the time out. The control will ask “

DO YOU WANT TO USE TIME

OUT WARNING HORN?

” If you answer YES the control will prompt

[__SET____MM:SS____]

Enter the warning time.

The control will ask “

DO YOU WANT TO DISPLAY TIME OUT ON

SCOREBOARD?

”

Press TIME OUT TIMER CLEAR

to cancel the currently active portion of the Time Out Time.

(If the warning horn has not yet sounded, it will sound and the timer will continue from the

warning time).

Time Out Timer

Start

Time Out Timer

Clear

Table des matières

Autres manuels Nevco Contrôleurs

Nevco

Nevco 134 Caractéristiques techniques

Nevco

Nevco 893 Basketball - 2 Caractéristiques techniques

Nevco

Nevco 728 Caractéristiques techniques

Nevco

Nevco 497 Caractéristiques techniques

Nevco

Nevco 651 Baseball Caractéristiques techniques

Nevco

Nevco 816 Caractéristiques techniques

Nevco

Nevco 398 Caractéristiques techniques

Nevco

Nevco 475 Baseball Caractéristiques techniques

Nevco

Nevco 827 Caractéristiques techniques

Nevco

Nevco Scoreboard MPCX2 Caractéristiques techniques

Nevco

Nevco 376 Caractéristiques techniques

Nevco

Nevco 354 Caractéristiques techniques

Nevco

Nevco 486 Caractéristiques techniques

Nevco

Nevco 453 Soccer Caractéristiques techniques

Nevco

Nevco 805 Caractéristiques techniques

Nevco

Nevco 321 Caractéristiques techniques

Nevco

Nevco 871 Hockey Caractéristiques techniques

Nevco

Nevco 717 Football Caractéristiques techniques

Nevco

Nevco 596 Football Caractéristiques techniques

Nevco

Nevco 541 Caractéristiques techniques

Nevco

Nevco 530 Caractéristiques techniques

Nevco

Nevco 750 Baseball Caractéristiques techniques

Nevco

Nevco MPCX SCD Series Caractéristiques techniques

Nevco

Nevco 761 Soccer Caractéristiques techniques

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
