NEUTRIK NAC3MX-W Guide produit

Page 1BDA 380

power TRU 1CON E

ASSEMBLY INSTRUCTION

250

JET

250

NAC3MX-W

Place chuck overthe

the cable.

Prepare cable asthe

shown.

B. ASSEMBLY INSTRUCTION

A. OPERATING INSTRUCTION

Application:

The power TRUE1 system is certified as connector with breaking cap ity according IECCON ac

60320, VDE It is intended for use as It0625. appliance couplers and interconnection couplers.

serves to supply power to appliance and from an appliance to another equipment.an To be installed by

qualified person only.

Connector Assignment:

NAC3PX

NAC3MPX NAC3FPX

NAC3FPX-ST

250

P S

JET

250

JET

250

NAC3MX-W

250

JET

250

NAC3MX-W

250

P S

JET

Power IN

Power OUT

Power IN

Power OUT

[0.32"]

8 mm

[”]0.787

2mm0

[”]0.9

PE 23 mm

NAC3MX-W

(Plug connector)

NAC3FX-W

(Connector)

NAC3FX-W

(Connector)

NAC3MX-W

(Plug connector)

Separate the

housing from the

bushing (cable

remain in bushing)

Insert cable into the

bushing and housing.

Note: “Apply cable

pulling lubricant to

cable jacket.”

250

P S

JET

250

NAC3MX-W

Approval based:

Rating:

Cable Type:

Strain Relief:

Cable O.D.:

VDE

EN 60320-1/EN60320-2-2

250 V ac / 16 A

H05VV-F3G 1.0 mm , Length max. 2 m

H05VV-F3G 1.5 - 2.5 mm2

H07RN-F3G 1.5 mm2

White chuck

6.0 - 12.0 mm

UL 498 / CSA C22.2 No. 182.3

250 V ac / 20 A

SJTOW, SJOOW 3 x 12 AWG

White chuck

6.0 - 12.0 mm

[0.32"]

8 mm

[”]0.787

2mm0

[”]0.9

PE 23 mm

VDE (EN 60320-1/EN60320-2-2) UL (UL 498 / CSA C22.2 No. 182.3)

40 - 50 mm

APPLIANCE INLET APPLIANCE OUTLET APPLIANCE INLET - OUTLET

COMBINATION

II ©® ®

NEUTRIK AG T: F:LI +423 / 237 24 24 +423 232 53 93/

NEUTRIK USA Inc. T: F:USA +1 704 / 972 3050 +1 704 438 9202/

NEUTRIK UK Ltd.

() T: F:UK +44 1983 / 811 441 +44 1983 811 439/

NEUTRIK Vertriebs GmbH T: F:DE/NL/AT/DK +49 8131 / 280 890 +49 8131 280 830/

NEUTRIK France FR T: F:+33 1 4131 6750 +33 1 4131 0511//

NEUTRIK Tokyo Ltd. JP T: F:+81 3 3663 4733 +81 3 3663 4796//

NEUTRIK Hong Kong Ltd. T: F:HK +852 2687 6055 +852 2687 6052//

NEUTRIK India Pvt. Ltd. IND T: F:+ +91 22 26163 54091/982 05 43 424 /

ASSEMBLY INSTRUCTION powerCON TRUE1

250

P S

JET

250

NAC3MX-W

250

P S

JET

250

NAC3MX-W

Torque Value 0.7 Nm

Torque Value 2.0Nm

PRESS FIRMLY

Torx size

Wrench size

13 mm

Important:

Push and turn simultaneously.

FOR DISASSEMBLY - OPEN TWIST LOCK!

1. Press with screw driver to unlock

Turn bushing 360°.2.

Repat step 1 + 2 until bushing is unscrewed.3.

CAUTION

To ensure protection

category, do not expose the

connection to bending forces

(e.g. do not attach loads to

the cable, no free-dangling

cable windings etc.).

LIECHTENSTEIN

250

P S

JET

Important:

Align r keyubber

latch.and

Insert the wires into the terminals and fasten the

screw with Torx size T8.

Wiring VDE UL

blackLbrownÞ

whiteNblueÞ

green / yellow greenÞ

Slide the chuck onto the insert (1) and then both

together into housing (2).

Important: Align the chuck byand insert

positioning the nose into keyway.the

Slide the bushing up the cable tighten itand with

the tool as shown.

Important: Yellow O-ring to hide to achieve IP

protection (6).

(Tool available: Art. No. HTAC)

FORCE

SAFETY WARNING

For safety and certification reasons the connector must be

replaced in case of any broken parts or serious damage.
