NeuroSky MindWave Mobile 2 Manuel utilisateur
MindWave Mobile 2: User Guide
May 14, 2018
1
The NeuroSky® product families consist of hardware and
software components for simple integration of this biosensor
technology into consumer and industrial end-applications.
All products are designed and manufactured to meet consumer
thresholds for quality, pricing, and feature sets. NeuroSky
sets itself apart by providing building block component
solutions that offer friendly synergies with related and complementary
technological solutions.
NO WARRANTIES: THE NEUROSKY PRODUCT FAMILIES
AND RELATED DOCUMENTATION IS PROVIDED "AS
IS" WITHOUT ANY EXPRESS OR IMPLIED WARRANTY
OF ANY KIND INCLUDING WARRANTIES OF MERCHANTABILITY,
NONINFRINGEMENT OF INTELLECTUAL PROPERTY,
INCLUDING PATENTS, COPYRIGHTS OR OTHERWISE,
OR FITNESS FOR ANY PARTICULAR PURPOSE. IN NO
EVENT SHALL NEUROSKY OR ITS SUPPLIERS BE LIABLE
FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT
LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS
INTERRUPTION, COST OF REPLACEMENT GOODS OR
LOSS OF OR DAMAGE TO INFORMATION) ARISING OUT
OF THE USE OF OR INABILITY TO USE THE NEUROSKY
PRODUCTS OR DOCUMENTATION PROVIDED, EVEN
IF NEUROSKY HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. , SOME OF THE ABOVE LIMITATIONS
MAY NOT APPLY TO YOU BECAUSE SOME JURISDICTIONS
PROHIBIT THE EXCLUSION OR LIMITATION
OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES.
USAGE OF THE NEUROSKY PRODUCTS IS SUBJECT
TO AN END-USER LICENSE AGREEMENT.
May 14, 2018 | © 2018 NeuroSky, Inc. All Rights Reserved.
2
Contents
Introduction to the MindWave Mobile 2
MindWave Mobile 2 Product Contents
Setting Up Your MindWave Mobile 2
Minimum System Requirements for Windows/Mac
Minimum System Requirements for iOS/Android
Replacing The Battery
Power
LED Light
Bluetooth Pairing
Bluetooth Configuration
Bluetooth Connection
Wireless Connection Troubleshooting
Using Your MindWave Mobile 2
Fitting the MindWave Mobile 2
NeuroSky Technology Overview
ThinkGear
eSense
eSense Meter - General Information
eSense Meter - Technical Description
ATTENTION eSense
MEDITATION eSense
Additional Products
Maintenance
Troubleshooting and Support
Safety and Regulations
Operating Conditions
Safety
ISO/IEC
FCC
May 14, 2018 | © 2018 NeuroSky, Inc. All Rights Reserved.
3
Introduction to the MindWave Mobile 2
Thank you for purchasing NeuroSky's MindWave™ Mobile 2. This innovative headset is
designed for education and entertainment applications which turn your mental state
changes and movements into actions, unlocking new worlds of interactivity. MindWave
Mobile 2 reports the wearer’s mental state in the form of NeuroSky's proprietary
algorithms, including the Attention and Meditation eSense™ algorithms. The NeuroSky
MindWave Mobile 2 can be used with supported video games, education software, and
many other applications.
For any technical information updates and additional support questions not answered by
this document please register at the NeuroSky support website at
http://support.neurosky.com. We also recommend you join our email list by filling out the
form on http://www.neurosky.com to receive general information about NeuroSky, new
products announcements, and any technical information updates.
MindWave Mobile 2 Product Contents
● MindWave Mobile 2 headset
● MindWave Mobile 2 Quick Start Guide
May 14, 2018 | © 2018 NeuroSky, Inc. All Rights Reserved.
4
Setting Up Your MindWave Mobile 2
Minimum System Requirements for Windows/Mac
Windows
Mac
Operating system
7/8/8.1/10
Mac OS X 10.8 or later
Processor
Intel Core Duo or equivalent
Memory
1GB or more
1GB
Video
DirectX 9.0 or greater
Intel GMA900 or greater
Hard disk
2.5GB free disk space
2GB free disk space
Wireless
Bluetooth
Bluetooth
Important: On 32-bit Windows 7 systems, the system must have at least Windows 7
Service Pack 1 (SP1) applied.
Minimum System Requirements for iOS/Android
iOS
Android
Operating system
iOS 8.0 or later
Android 4 or later
Hardware
At least iPhone 5s, iPad 4
Compatible Android phone or tablet
Wireless
BLE
Bluetooth
May 14, 2018 | © 2018 NeuroSky, Inc. All Rights Reserved.
5
Replacing The Battery
The MindWave Mobile 2 headset requires 1 AAA alkaline battery to operate, which
provides 8 hours of run time. To install or replace the battery, slide open the battery
cover. Remove any existing battery within and replace with a new alkaline AAA battery,
making sure the polarity +/- are aligned correctly.
IMPORTANT: ONLY use alkaline batteries, or equivalent batteries that can sustain alkaline
voltage levels under load. Please DO NOT use batteries labeled as “Zinc-Carbon” nor “Heavy
Duty”, as their voltage levels quickly drop below usable levels during usage loads, which will
result in inconsistent behavior, such as disconnects.
Power
To power on the MindWave Mobile 2 headset, slide the switch to the ON position. Then a
blue LED light on the side of the headset will be turned on. If the MindWave Mobile 2 has
a low battery, the LED light will appear red.
To turn the MindWave Mobile 2 off, slide the switch back to the OFF position.
May 14, 2018 | © 2018 NeuroSky, Inc. All Rights Reserved.
6
LED Light
The device’s LED light has two colors: red and blue. Refer to the chart to see what state
the MindWave Mobile 2 is in.
LED Light
MindWave Mobile 2 State
Meaning
Off
Powered off
MindWave Mobile 2 is turned off or has no
battery.
Solid blue
Powered on
MindWave Mobile 2 is turned on or connected
Solid red
Low battery
Need to replace the battery soon.
IMPORTANT: Only use alkaline batteries. Do
not use batteries labeled as “Zinc-Carbon” nor
“Heavy Duty”.
Bluetooth Pairing
"Pairing" is when your computer/tablet/phone remembers your MindWave Mobile 2
headset, and your MindWave Mobile 2 headset allows that computer/tablet/phone to
connect to it. Note that this is different from "connecting", which is when the
computer/tablet/phone is actively sending or receiving data and information.
You must first pair each of your computers/tablets/phones to your MindWave Mobile 2
headset in order for them to connect to each other. To do so:
Turn on the headset, and make sure the Blue LED light is on. Then follow the instructions
below for the device you want to pair to:
Important: There's no “pairing mode” on the MindWave Mobile 2 headset itself; the headset
is ready to pair when turned on. Please DO NOT force the power switch to the edge. It will be
damaged.
● For Windows/Android/Mac platform
Refer to the pairing procedure that came with your Windows, Mac or Android device.
Select "MindWave Mobile" device when it appears on the device list. If you see multiple
devices named MindWave Mobile, please select the one shown with a headset icon.
Enter the "0000" as the Bluetooth authentication key if prompted. For full details about
May 14, 2018 | © 2018 NeuroSky, Inc. All Rights Reserved.
7
how to pair with each platform, refer to the instructions in the MindWave Mobile 2 Quick
Start Guide. You could get it from package or from this link.
● For iOS platform
Visit mwm2.neurosky.com, and follow the on-screen guide to download, install and run
the MindWave Mobile 2 Tutorial app. Then follow the instruction in tutorial app to pair
and configure the headset. No other explicit pairing is needed.
Note: Your MindWave Mobile 2 headset can "pair/remember" up to 3 devices (computers,
tablets, or phones) at the same time. If you are using the MindWave Mobile 2 headset with
more than 3 devices, you may need to remove the previous pairing from the device and
re-pair it again.
Bluetooth Configuration
In order to function properly, the headset must know the electrical grid frequency of your
country or territory. Please visit mwm2.neurosky.com, and follow the on-screen guide to
download, install and run the "MindWave Mobile Tutorial" location in Tutorial Setting Page.
If you travel to another country, please reconfigure the headset accordingly.
Bluetooth Connection
Depending on your computer/tablet/phone, it may automatically connect to the headset
whenever an application needs to use the headset. If your Bluetooth software does not
automatically connect when an app is started, please refer to the Bluetooth connecting
instructions that came with your iOS, Android, Windows, or Mac device to manually
connect to the headset before running your apps.
Serial/COM Port Name or Number
Some games and applications will ask for you to enter the serial COM port name or
number for the game or application to connect to the headset. Use the Bluetooth software
on your computer/tablet/phone to determine the COM port name or number that your
MindWave Mobile 2 has been assigned to.
May 14, 2018 | © 2018 NeuroSky, Inc. All Rights Reserved.
8
Wireless Connection Troubleshooting
Problem
Problem
Solution
Unable to find or
connect to MindWave
Mobile 2 headset, or
headset disconnects
unexpectedly
Low battery
Replace the battery in the
MindWave Mobile 2 with a new
AAA alkaline battery.
MindWave Mobile 2 is not
turned on
Turn the MindWave Mobile 2 on.
MindWave Mobile 2 is not
paired to this computer.
Make sure that you use your
computer/device's Bluetooth
software to pair the headset.
MindWave Mobile 2 headset
is too far from the receiver
device (e.g. your
computer/phone/tablet)
Check that your headset stays
within 10 feet of the receiver
device.
ThinkGear Connector is not
running (only Windows and
Mac).
Make sure the ThinkGear
Connector (TGC) is running and
enabled.
Other
Strong radio interference.
Move the headset closer to the
Bluetooth on your computer/device.
Note: If problems still persist, please visit http://support.neurosky.com or email
May 14, 2018 | © 2018 NeuroSky, Inc. All Rights Reserved.
9
Using Your MindWave Mobile 2
This chapter walks you through fitting the MindWave Mobile 2 and installation of the
included MindWave Mobile 2 software on your computer. Be sure to first connect and pair
the headset as described in the previous chapter first.
Fitting the MindWave Mobile 2
The MindWave Mobile 2 is more than your average headset. It has the ability to use your
mental state for exciting new applications.
IMPORTANT: In order to take full advantage of these functions and features of the MindWave
Mobile 2, you must first wear it properly.
1. Orient the MindWave Mobile 2 with the forehead Sensor Arm on your left hand side.
Rotate the Sensor Arm from its base by about 90 degrees. It can be rotated slightly more
if necessary to get proper fit and comfort.
May 14, 2018 | © 2018 NeuroSky, Inc. All Rights Reserved.
