NETWEEN C140T Manuel utilisateur
Netween Router User Manual
Table of Contents
Product & Explainations
3
Product Feature
1. Front of the Netween
3
2. Back of the Netween
5
Netween Default Connection
1. General Internet Network
6
2. Environment using a Modem
7
Netween Default Set
1. Internet Connection Settings
7
1) Auto IP set
8
2) Static IP set
8
3) PPPoE set
9
Components
Firmware Upgrade 12
Load Default Setting 13
Installation Precautions 4
2
10
2. Wireless Default Setting and security setting 11
1) How to setting wireless security 11
2) How to setting wireless check 11
3
Netween Router
Product Features
Specification
Wireless Interface
CPU
WAN Interface
LAN Interface
Status LED
DRAM
FLASH
Power
Operating Temp.
Tx Power
Rx Sensitivity
Antenna
IEEE802.11b/g/n (Draft 2.0)
384Mhz MIPS 34bit
1 x 10/100Base-Tx, Auto MDI/MDIX
4 x 10/100Base-Tx, Auto MDI/MDIX
Power, WLAN, WAN, LAN x 4, WPS
16Mbytes
4Mbytes
Input : 100~240VAC, 50~60Hz
Output : 5VDC, 2A
14dBm 2dBm
-65dBm @130Mbps
-68dBm @54Mbps
-84dBm @11Mbps
3 dBi x 2 antenna
C140T
Wireless
-. 802.11n(draft 2.0), 802.11b/g
-. 1T1R
-. Up to 300Mbps
-. Multiple SSID
-. SSID broadcast
-. Auto transmission speed
-. WDS Wireless bridge
-. Wi-Fi Multi Media
-. Auto Channel Select
-. WPS
-. OFDM, DSSS, MIMO
-. 2.4 Ghz
Security
-. 64/128/WEP
-. WPA/WPA2, WPA-PSK/
WPA2-PSK(TKIP/AES)
-. Hidden SSID
-. Access Control List
-. Packet Filtering
-. Web Contents/URL filter
-. Parent Control
Network Protocol
-. PPPoE
-. DHCP
-. MAC cloning
-. Port forwarding
-. QoS for MAC and IP
-. IGMP Proxy
-. DDNS
-. UPnP
-. VPN Server
-. DMZ, Special DMZ
-. NAT
Others
-. Login(ID/PW)
-. Auto-Firmware upgrade
-. Remote Web management
-. System log
-. WOL
Netween Router
Components
Netween Router 1M LAN cable User Manual
Power Adapter
Installation Precautions
Read the notes below before installing
The power adapter must be a standard adapter
that is supplied with Netween adapter products.
Must seek professional help when product is damaged, please
avoid further deteriorating or opening the case of the product.
Be careful not to drop or apply strong collision to the product.
Please avoid setting in places with direct sunlight, dust,
excessive vibration or unstable places before and after you
install the product.
If the exterior adapter devices of the Netween are cleaned with
alcohol, benzene, acetone, etc. or any flammable liquids, this
alteration to the surface will cause chemical changes. In case of
contact with other material please wipe the area with a dry cloth.
The power being supplied must be stable. In the case of the
power supply develops sparks or noises, a power control device
must be installed.
Never touch the power supply area when the power cord is
connected due to risks of electric shocks. When installing or
moving the product, power switch must be turned off and all the
connected cables must be unplugged.
Pay attention not to overload wiring connections when connected
the power source.
The information contained in this manuscript can be changed without
agreement or separate notice of individual users.
regulations, some environmental constrains of the product
performance and feature limitations may be encountered.
We will not take responsibility of any line disability issues during
usage of this product.
4
Product & Explaination
Power / ON
WLAN / Flicker
WPS / only flickers when activated
WAN / Flicker
LAN /Flicker
* WPS (Wifi Protected Setup)
A feature to set up easily without complex security
settings between adaptor and WPS function supported
terminals.
Shows the power supply is normal
Shows wireless is in operating conditions
WPS supported devices and confirmation
process is in progress
Shows external internet cable is connected
and data communication is in progress
PC and cable is connected and shows data
communication is in progress
5
Front of the Netween
Reset
Power
ON/OFF
Switch
WAN
LAN
WPS
6
Back of the Netween
Netween Default Connection
7
General internet environment
Environment using a Modem
Netween default set
1. Dynamic IP(DHCP)
How to install
2. With modem methods, disconnect the LAN cable that is
connected to the modem connected to the PC and
have an optical LAN, separate the socket of the terminal
from the PC and connect it to the router (WAN port). Make sure
the LED of the (WAN) is working normally.
3. After turning on the PC, connect the LAN cable that is
enclosed with the product to the PC and into 1 2 3 4,
one of the LAN ports of the router. Make sure the LED
of 1 2 3 4 are functioning.
4. Reboot the PC and see if the internet working
- If internet is automatically connected, internet can be used without
additional connection settings
Netween router is set to automatically receive IP method in default.
Enter address http://192.168.1.1- Expert Setting- WAN Interface Setting
8
Internet connection set
2. Static IP
Set when router is connected
1) After accessing to 192.168.1.1 on the internet
address bar, change the internet to (Static IP)
from (Expert Setting) (Network Setting)
(WAN Interface Setting) and enter the given Static
IP and click SAVE
2) Savings are completed when the screen turns white
and back to its original form.
9
3. PPPoE (ADSL User)
Set when router is connected
1) After inserting internet access address 192.168.1.1
go to [Expert Setting] [Network Sertting]
[WAN Interface Setting] and change the
internet connection form to [PPPoE] and insert
the user ID and password of the telecommunication
company that you have signed up, click SAVE
2) Savings are completed when the screen turns white
and back to its original form.
3) After saving, confirm if the wired and
wireless internet is working
10
