NETGEAR Nighthawk M1 Manuel utilisateur
QUICK START
KURZANLEITUNG
DEMARRAGE RAPIDE
GUIDA INTRODUTTIVA
INICIO RÁPIDO
КРАТКОЕ РУКОВОДСТВО
NETGEAR Nighthawk M1
4GX Gigabit LTE Mobile Router/Mobiler 4GX-Gigabit-LTE-Router
Routeur mobile 4GX Gigabit LTE/Router 4GX Gigabit LTE Mobile
Router móvil 4GX LTE Gigabit/Гигабитный мобильный роутер LTE 4GX
2
Package Contents
• Nighthawk M1 Mobile Router and battery
• Quick start guide
• Type-C USB cable
• AC power adapter
1. Check the SIM card and insert the battery.
a. Make sure that power to the mobile router is o.
b. Remove the cover on the bottom of the mobile router.
Place your thumbs on the arrows on the cover and press down
while sliding the cover up.
c. Check to see if a micro SIM card was inserted into the SIM card
slot.
If a micro SIM card was inserted, skip to Step e. If a micro SIM
card was not inserted, locate the micro SIM card and continue
with Step d.
To get a valid and provisioned SIM card, contact your mobile
provider.
English
3
d. Carefully slide the micro SIM card into the slot.
e. Align the battery connectors and insert the battery.
f. If you purchased a micro SD card, insert the card
into the micro SD slot.
g. Replace the mobile router cover.
Reset
SIM card
Micro SD slo
t
4
2. Download the NETGEAR Mobile app.
Use the NETGEAR Mobile app to change your WiFi network name
and password. You can also use it to play and share media, and enable
the travel router feature.
a. Connect your mobile device to the Internet.
b. Download the NETGEAR Mobile app from
netgear.com/mobileapps.
3. Power on your mobile router.
Press and hold the Power button on the mobile router for three
seconds.
Power button
5
To view the WiFi name and password, press and release the Power
button to toggle through Nighthawk M1 router LCD displays.
6
4. Connect your devices.
a. Check to make sure that WiFi is enabled on your computer or
mobile device and search for WiFi networks. Refer to the following
table or the manual for your WiFi-enabled device for further details
on searching for WiFi networks.
b. To view the WiFi name and password, press and release the Power
button to toggle through Nighthawk M1 router LCD displays.
Windows Click the Internet Access icon, which is usually found on
the bottom right side of your screen.
Mac Select WiFi > Network.
Mobile
devices Tap Settings > WiFi.
c. Select the WiFi name displayed on your Nighthawk M1 screen.
d. Enter the WiFi password exactly as shown on the Nighthawk M1 screen.
NOTE: Your password is case-sensitive. We strongly recommend that
you change the default admin password.
7
e. To use the router as an internet gateway, connect an Ethernet
device to the Nighthawk M1 router Ethernet port.
5. Set up the device.
a. Use the NETGEAR Mobile app or visit http://m1login.net or
http://192.168.1.1 from a device that is connected to the
Nighthawk M1 router.
b. Follow the on screen instructions.
Advanced Configuration and Features
¾To log in to the Nighthawk M1 router home page:
1. Launch a web browser from a device that is connected to the
Nighthawk M1 router.
2. In the address field of the web browser, enter
http://m1login.net or http://192.168.1.1.
3. In the Sign In field, enter the default password and click the
Sign In button. See the modem label for the default password.
While the password that you enter is unique to your device and is
secure, we recommend that you change it to a password that you
want to use.
8
Upload Media Files to the Nighthawk M1 Router
You can upload media files to either a micro SD card or a USB drive
connected to the Nighthawk M1 router. Micro SD cards and USB
drives are sold separately. To enable media and Ethernet support, you
must first select the Charge Only option (Settings > Router Setup
> Use USB port for).
¾To upload media files to the Nighthawk M1 router with a
computer:
1. Log in to the Nighthawk M1 router home page.
2. Click the MyMedia tab.
3. Drag and drop your files onto the page.
Use the Nighthawk M1 Router to Charge Other Devices
If the battery power is low on your smartphone or other device, you
can give it a boost by connecting it to the M1’s USB port A connector.
Jump boost begins automatically once the devices are connected.
9
LED Status
Slow blue blink The Nighthawk M1 router is ready.
Fast blue blink The Nighthawk M1 router is transferring data.
Slow amber blink The Nighthawk M1 router is not ready.
USB (type A) USB (type C) Ethernet
TS-9
Port 1
TS-9
Por
t 2
Power
10
Power Button
Turn on the router. Press and hold the Power button for three
seconds.
Turn o the router. Press and hold the Power button for five seconds.
Wake the router. Press and quickly release the Power button.
Switch between screens. Press and quickly release the Power button.
Support
For additional information, visit netgear.com/support to access the full user
manual and to download firmware updates.
Compliance
For the current EU Declaration of Conformity, visit
http://kb.netgear.com/app/answers/detail/a_id/11621.
For regulatory compliance information, visit: http://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
