NETGEAR WN804 Manuel utilisateur

350 East Plumeria Drive

San Jose, CA 95134

USA

June 2013

202-11236-01

WN804 Access Point

User Manual

WN804Access Point

Support

Thank you for selecting NETGEAR products.

After installing your device, locate the serial number on the label of your product and use it to register your product

at https://my.netgear.com. You must register your product before you can use NETGEAR telephone support.

NETGEAR recommends registering your product through the NETGEAR website. For product updates and web

support, visit http://support.netgear.com.

Phone (US & Canada only): 1-888-NETGEAR.

Phone (Other Countries): Check the list of phone numbers at

http://support.netgear.com/general/contact/default.aspx.

Trademarks

NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of

NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change

Contents

Chapter 1 Getting Started

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Hardware Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Product Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Attach the Feet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Position the Access Point. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Connect to the WiFi Network with WPS. . . . . . . . . . . . . . . . . . . . . . . . . . .11

Chapter 2 Basic Configuration

Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Specify IP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Specify Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Wireless Settings Screen Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Change the Wireless Security Option. . . . . . . . . . . . . . . . . . . . . . . . . . .17

WPS Wizard for WiFi Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Set Up a Guest Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

View Attached Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Chapter 3 System Settings

View Logs of Web Access or Attempted Web Access . . . . . . . . . . . . . . . .23

Manage the Configuration File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Back Up Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Restore Configuration Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Erase the Current Configuration Settings. . . . . . . . . . . . . . . . . . . . . . . .25

Change the Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Password Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Wireless AP Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Reboot the Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Chapter 4 Advanced Configuration

Advanced Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Control the Wireless Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Set Up a Wireless Schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Enable or Disable 20/40 GHz Coexistence . . . . . . . . . . . . . . . . . . . . . .31

View or Change WPS Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

WN804Access Point

Set Up a Wireless Access List by MAC Address . . . . . . . . . . . . . . . . . .33

Wireless Distribution System (WDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Set Up the Base Station. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Set Up a Repeater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Chapter 5 Troubleshooting

Troubleshoot with the LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

No LEDs Are Lt on the Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . .39

The WiFi LED Is Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

No WiFi Access to the Internet or LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Time-Out Error for a URL or IP Address . . . . . . . . . . . . . . . . . . . . . . . . . .40

Appendix A Supplemental Information

Factory Default Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Appendix B Notification of Compliance

1. Getting Started

This chapter covers the following topics:

•Package Contents

•Hardware Features

•Attach the Feet

•Log In to the Access Point

•Position the Access Point

•Connect to the WiFi Network with WPS

Getting Started

WN804Access Point

Package Contents

Open the box and remove the access point, cables, and installation guide.

WN804 Access Point

Ethernet cable Power adapter

Installation guide

Feet

Figure 1. Check the package contents

Your box contains the following items:

•WN804 Access Point

•AC power adapter (plug varies by region)

•Category 5 (Cat 5) Ethernet cable

•Installation guide with cabling and access point setup instructions

If any parts are incorrect, missing, or damaged, contact your NETGEAR dealer. Keep the

carton and original packing materials, in case you return the product for repair.

Hardware Features

Before you cable your access point, take a moment to become familiar with the front, side,

and back panels and the label. Pay particular attention to the LEDs on the front panel.

Getting Started

WN804Access Point

Front Panel

The access point front panel has the status LEDs shown in the following figure.

Figure 2. Access point front panel

Table 1. Front panel LED descriptions

LED Description

Power •Solid amber. The access point is starting up.

•Blinking amber. The firmware is upgrading, or the Reset button was pressed.

•Solid green. The access point is ready.

•Blinking green. The firmware is corrupted. Visit www.netgear.com/support.

•Off. Power is not supplied to the access point.

WiFi •Solid green. The wireless radio is operating.

•Off. The wireless radio is off.

Internet •Solid green. The Internet connection is ready.

•Solid amber. The Ethernet cable connection to the modem has been detected.

•Off. No Ethernet cable is connected to the modem.

WPS • Slow blinking. The LED lights for 5 seconds if WPS setup fails.

•Blinking: WPS activity is in process.

•Off. No WPS activity or no WPS failure was detected.

The WiFi and WPS buttons on the side of the access point toggle the WiFi and WPS

functions on and off.

•WiFi On/Off button.Pressing and holding this button for 2 seconds turns the wireless

radio on and off. If the WiFi LED is lit, the wireless radios is on. If this LED is off, the

wireless radio is turned off and you cannot connect wirelessly to the access point.

•WPS button. You can use this button to use WPS to add a wireless device or computer

to your wireless network. The WiFi LED blinks blue when the access point is trying to add

Getting Started

WN804Access Point

the wireless device or computer. The LED stays solid blue when wireless security is

enabled in the access point.

Rear Panel

The rear panel has the connections and buttons shown in the following figure.

Ethernet

Power

Reset

button port connetor

On/Of

Figure 3. Access point rear panel

Pressing the Reset button restores the factory settings. See Factory Default Settings on

page 42.

Product Label

The label on the bottom of the access point shows the login information, MAC address, and

serial number.

Serial number

Preset WiFi

Default access information

password

MAC address

SSID

Getting Started

WN804Access Point

Attach the Feet

Attach the feet to the access point as shown so that you can place it in a vertical position.

Figure 4. Attach the feet to the access point

To log in, you need to use a computer with a fixed IP address.

To log in to the access point:

1. Prepare a computer with an Ethernet adapter.

If this computer is already part of your network, record its TCP/IP configuration settings.

Configure the computer with a static IP address of 192.168.0.210 and 255.255.255.0 as

the subnet mask.

Getting Started

WN804Access Point

2. Use an Ethernet cable to connect the computer to the access point.

3. Launch a browser and enter http://192.168.0.233 in the address field.

4. When prompted to log in, enter admin for the user name and password for the password,

both in lowercase letters.

The web management interface of the access point displays.

Note: When you have finished changing the access point settings, you can

reconfigure this computer back to its original TCP/IP settings.

Position the Access Point

The access point lets you access your network from anywhere within the operating range of

your wireless network. However, the operating distance or range of your wireless connection

can vary significantly depending on the physical placement of your access point. For

example, the thickness and number of walls the wireless signal passes through can limit the

range. For best results, place your access point:

•Near the center of the area where your computers and other devices operate, and

preferably within line of sight to your wireless devices.

•So it is accessible to an AC power outlet and near Ethernet cables for wired computers.

•In an elevated location such as a high shelf, keeping the number of walls and ceilings

between the access point and your other devices to a minimum.
