NETGEAR ProSafe WNAP320 Manuel utilisateur

350 East Plumeria Drive

San Jose, CA 95134

USA

September 2010

202-10724-01

v1.0

ProSafe Wireless-N Access

Point WNAP320

Reference Manual

FOR CERTIFICATION ONLY

ProSafe Wireless-N Access Point WNAP320 Reference Manual

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated

into any language in any form or by any means without the written permission of NETGEAR, Inc.

Technical Support

Thank you for choosing NETGEAR. To register your product, get the latest product updates, or get support online,

visit us at http://support.netgear.com.

Phone (US & Canada only): 1-888-NETGEAR

Phone (Other Countries): See Support information card.

Trademarks

NETGEAR, the NETGEAR logo, ReadyNAS, ProSafe, Smart Wizard, Auto Uplink, X-RAID2, and NeoTV are

trademarks or registered trademarks of NETGEAR, Inc. Microsoft, Windows, Windows NT, and Vista are

registered trademarks of Microsoft Corporation. Other brand and product names are registered trademarks or

trademarks of their respective holders.

Statement of Conditions

To improve internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes

to the products described in this document without notice. NETGEAR does not assume any liability that may occur

due to the use, or application of, the product(s) or circuit layout(s) described herein.

Revision History

Publication Part Number Version Publish Date Comments

202-10724-01 v1.0 September 2010 First publication

Contents |3

Contents

Chapter 1 Introduction

About the ProSafe Wireless Access Point . . . . . . . . . . . . . . . . . . . . . . . . . .7

What Is In the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Key Features and Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Supported Standards and Conventions . . . . . . . . . . . . . . . . . . . . . . . . . .9

Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

802.11b/g/n Standards–based Wireless Networking . . . . . . . . . . . . . . .11

Autosensing Ethernet Connections with Auto Uplink . . . . . . . . . . . . . . .11

Hardware Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Chapter 2 Installation and Configuration

Wireless Equipment Placement and Range Guidelines. . . . . . . . . . . . . . .15

Understanding WNAP320 Wireless Security Options . . . . . . . . . . . . . . . .16

Setting Up the Wireless ProSafe Wireless Access Point . . . . . . . . . . . .17

Configuring Lan and Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . .17

Configuring Your Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Deploying the ProSafe Wireless Access Point. . . . . . . . . . . . . . . . . . . . . .23

Verifying Wireless Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Logging In Using the Default IP Address . . . . . . . . . . . . . . . . . . . . . . . .24

Mounting the ProSafe Wireless Access Point Using the Wall Mount Kit ) .25

Configuring and Testing Your PCs for Wireless Connectivity . . . . . . . .26

Logging In to the ProSafe Wireless Access Point . . . . . . . . . . . . . . . . .26

Setting Basic IP Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Configuring 802.11b/g/n Wireless Settings . . . . . . . . . . . . . . . . . . . . . .29

Configuring QoS Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Setting Up and Testing Basic Wireless Connectivity . . . . . . . . . . . . . . . . .32

Understanding Security Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

SSID and WEP/WPA Settings Setup Form . . . . . . . . . . . . . . . . . . . . . .36

Configuring the RADIUS Server Settings . . . . . . . . . . . . . . . . . . . . . . . . 37

Setting Up a Security Profile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Restricting Wireless Access by MAC Address . . . . . . . . . . . . . . . . . . . . 48

Chapter 3 Management

Remote Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Remote Console. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

4|Contents

ProSafe Wireless-N Access Point WNAP320 Reference Manual

Management Using Telnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Upgrading the Wireless Access Point Software . . . . . . . . . . . . . . . . . . . . . 54

Managing the Configuration File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Saving the Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Restoring the Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Restoring the WNAP320 to the Factory Default Settings. . . . . . . . . . . . . . 57

Changing the Administrator Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Enabling the Syslog Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Using Activity Log Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

Viewing General Summary Information . . . . . . . . . . . . . . . . . . . . . . . . . . .61

Viewing Network Traffic Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

Viewing Available Wireless Station Statistics. . . . . . . . . . . . . . . . . . . . . . . 65

Enabling Rogue AP Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Importing a Rogue AP List from a File . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Viewing and Saving AP Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Viewing AP Lists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Creating AP Lists Manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Chapter 4 Advanced Configuration

802.1Q VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Hotspot Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Configuring Advanced Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Configuring Advanced QoS Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Enabling Wireless Bridging and Repeating . . . . . . . . . . . . . . . . . . . . . . . . 77

Configuring a WNAP320 as a Point-to-Point Bridge . . . . . . . . . . . . . . . 79

Configuring a Point-to-Multi-Point Wireless Bridge . . . . . . . . . . . . . . . . 80

Configuring the WNAP320 as a Wireless Repeater. . . . . . . . . . . . . . . . 81

Configuring the WNAP320 for Client Mode . . . . . . . . . . . . . . . . . . . . . . 83

Chapter 5 Troubleshooting and Debugging

No lights are lit on the product family. . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

The Wireless LAN LED does not light up. . . . . . . . . . . . . . . . . . . . . . . . . . 85

The Ethernet LAN LED is not lit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

I cannot access the Internet or the LAN with a wireless-capable computer. 86

I cannot connect to the WNAP320 to configure it. . . . . . . . . . . . . . . . . . . . 86

When I enter a URL or IP address, I get a time-out error. . . . . . . . . . . . . . 86

Using the Restore Factory Settings Button to Restore Default Settings . .87

Appendix A Supplemental Information

Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Appendix B Compliance Notification

Index

Chapter 1. Introduction |6

1. Introduction

This chapter introduces the NETGEAR ProSafe Wireless-N Access Point WNAP320 and

describes some of the key features.

This chapter includes the following:

• minimum prerequisites for installation

• package contents (What Is In the Box? on page 8),

• description of the front and back panels of the WNAP320

Chapter 1. Introduction |7

ProSafe Wireless-N Access Point WNAP320 Reference Manual

About the ProSafe™ Wireless-N Access Point WNAP320

The NETGEAR ProSafe Wireless-N Access Point WNAP320 is the basic building block of a

wireless LAN infrastructure. It provides connectivity between Ethernet wired networks and

radio-equipped wireless notebook systems, desktop systems, print servers, and other

devices.

The access point provides wireless connectivity to multiple wireless network devices within a

fixed range or area of coverage—interacting with a wireless network interface card (NIC)

through an antenna. Typically, an individual in-building access point provides a maximum

connectivity area of about a 500 foot radius. Consequently, the NETGEAR ProSafe

Wireless-N Access Point WNAP320 can support a small group of users in a range of several

hundred feet. Most access points can handle between 10 to 30 users simultaneously.

The NETGEAR ProSafe Wireless-N Access Point WNAP320 acts as a bridge between the

wired LAN and wireless clients. Connecting multiple ProSafe Wireless Access Points through

a wired Ethernet backbone can further increase the wireless network coverage. As a mobile

computing device moves out of the range of one access point, it moves into the range of

another. As a result, wireless clients can freely roam from one access point to another and

still maintain seamless connection to the network.

The auto-sensing capability of the NETGEAR ProSafe Wireless-N Access Point WNAP320

allows packet transmission at up to 300 Mbps, or at reduced speeds to compensate for

distance or electromagnetic interference.

8|Chapter 1. Introduction

ProSafe Wireless-N Access Point WNAP320 Reference Manual

What Is In the Box?

The product package should contain the following items:

• NETGEAR ProSafe Wireless-N Access Point WNAP320

• Power adapter and cord (12Vdc, 1.0A)

• Straight-through Category 5 Ethernet cable

• NETGEAR WNAP320 Wireless-N Access Point Installation Guide

• Resource CD, which includes this manual

• Vertical stand feet (2)

• Wall mount kit made up of brackets (2) and hardware

Contact your reseller or customer support in your area if there are any missing or damaged

parts.

Refer to the for the the NETGEAR, Inc., website at http://kbserver.netgear.com/main.asp for the

telephone number of customer support in your area. You should keep the Installation Guide,

along with the original packing materials, and use the packing materials to repack the access

point if you need to return it for repair.

To qualify for product updates and product warranty, NETGEAR encourages you to register

on the NETGEAR Web site at http://my.netgear.com/registration/login.aspx.

Chapter 1. Introduction |9

ProSafe Wireless-N Access Point WNAP320 Reference Manual

System Requirements

Before installing the access point, make sure that your system meets these requirements:

• A 10/100/1000 Mbps local area network device such as a hub or switch

• The Category 5 UTP straight-through Ethernet cable with RJ-45 connector included in the

package, or one like it

• A 100–120 V, 50–60 Hz AC power source

• A Web browser for configuration such as Microsoft Internet Explorer 5.0 or later, or

Mozilla 3.0 or later

• At least one computer with the TCP/IP protocol installed

• 802.11b/g- or 802.11b/g-compliant devices, such as the NETGEAR WG511 Wireless

Adapter

10 |Chapter 1. Introduction

ProSafe Wireless-N Access Point WNAP320 Reference Manual

Key Features and Standards

The ProSafe Wireless Access Point is easy to use and provides solid wireless and

networking support. It also offers a wide range of security options.

Supported Standards and Conventions

The following standards and conventions are supported:

• Standards Compliance.The wireless access point complies with the IEEE 802.11 b/g

standards for wireless LANs, and is WiFi certified for 802.11n draft 2.0 standard.

• Full WPA and WPA2 support. The wireless access point provides WPA and WPA2

enterprise-class strong security with RADIUS and certificate authentication as well as

dynamic encryption key generation. The WPA-PSK and WPA2-PSK preshared key

authentication is without the overhead of RADIUS servers but with all of the strong

security of WPA.

• Multiple BSSIDs. The access point supports multiple BSSIDs. When a product family is

connected to a wired network and a set of wireless stations, it is called a Basic Service

Set (BSS). The Basic Service Set Identifier (BSSID) is a unique identifier attached to the

header of packets sent over a WLAN that differentiates one WLAN from another when a

mobile device tries to connect to the network.

The multiple BSSID feature allows you to configure up to eight SSIDs per radio mode on

your access point and assign different configuration settings to each SSID. All the

configured SSIDs are active, and the network devices can connect to the access point by

using any of these SSIDs.

• DHCP client support.DHCP provides a dynamic IP address to PCs and other devices

upon request. The access point can act as a client and obtain information from your

DHCP server; it can also act as a DHCP server and provide network information for

wireless clients.

• SNMP Support.Support for Simple Network Management Protocol (SNMP)

Management Information Base (MIB) management.

• 802.1Q VLAN (virtual LAN) support. A network of computers that behave as if they are

connected to the same network even though they might actually be physically located on

different segments of a LAN. VLANs are configured through software rather than

hardware, which makes them extremely flexible. VLANs are very useful for user and host

management, bandwidth allocation, and resource optimization.

Chapter 1. Introduction |11

ProSafe Wireless-N Access Point WNAP320 Reference Manual

Key Features

The WNAP320 Access Point provides solid functionality, including the following features:

• Multiple operating modes:

-Wireless Access Point. Operates as a standard 802.11b/g/n access point.

-Point-to-Point Bridge. In this mode, the access point communicates only with another

bridge-mode wireless station or access point. Network authentication should be used

to protect this communication.

-Point-to-Multi-Point Bridge. Select this only if this access point is the “master” for a

group of bridge-mode wireless stations. The other bridge-mode wireless stations

send all traffic to this master, and do not communicate directly with each other.

Network authentication should be used to protect this traffic.

-Wireless Repeater. In this mode, the access point does not function as an access

point. It communicates only with Repeater mode, Point-to-Point Bridge mode, and

Point-to-Multi-point-bridge-mode wireless stations. Network authentication should be

used to protect this communication.

• Hotspot settings. You can allow all HTTP (TCP, port 80) requests to be captured and

redirected to the URL you specify.

• Upgradeable firmware. Firmware is stored in a flash memory, you can upgrade it easily,

using only your Web browser, and you can upgrade it remotely. You can also use the

command-line interface.

• Rogue AP detection.The Rogue AP filtering feature ensures that unknown APs are not

given access to any part of the LAN.

• Access Control.The Access Control MAC address filtering feature can ensure that only

trusted wireless stations can use the access point to gain access to your LAN.

• Security profiles.When using multiple BSSIDs, you can configure unique security

settings (encryption, SSID, and so on) for each BSSID.

• Hidden mode. The SSID is not broadcast, assuring only clients configured with the

correct SSID can connect.

• Configuration backup. Configuration settings can be backed up to a file and restored.

• Secure and economical operation. Adjustable power output allows more secure or

economical operation.

• Power over Ethernet. Power can be supplied to the access point over the Ethernet port

from any 802.3af-compliant mid-span or end-span source.

• Autosensing Ethernet connection with Auto Uplink™ interface. Connects to

10/100/1000 Mbps IEEE 802.3 Ethernet networks.

• LED indicators. Power, Test, LAN speed, LAN activity, and wireless activity for each

radio mode are easily identified.

• Wireless Multimedia (WMM) support. WMM is a subset of the 802.11e standard. WMM

allows wireless traffic to have a range of priorities, depending on the kind of data.

Time-dependent information, like video or audio, has a higher priority than normal traffic.

For WMM to function correctly, wireless clients must also support WMM.

Autres manuels pour ProSafe WNAP320

Table des matières

Autres manuels NETGEAR Point d'accès sans fil

NETGEAR

NETGEAR ProSafe WG102-500 Manuel utilisateur

NETGEAR

NETGEAR WAG102NA Manuel utilisateur

NETGEAR

NETGEAR ProSafe WNAP320 Manuel utilisateur

NETGEAR

NETGEAR WG602 - 54 Mbps Wireless Access Point Manuel utilisateur

NETGEAR

NETGEAR WAX618-111NAS Manuel utilisateur

NETGEAR

NETGEAR FWG114Pv2 - Wireless Firewall With USB Print... Manuel utilisateur

NETGEAR

NETGEAR WAC124 Manuel utilisateur

NETGEAR

NETGEAR WG302 - 802.11g ProSafe Wireless Access... Manuel utilisateur

NETGEAR

NETGEAR WG602v3 - Wireless Access Point Manuel utilisateur

NETGEAR

NETGEAR ProSafe WNAP320 Manuel utilisateur

NETGEAR

NETGEAR ProSafe WNDAP330 Manuel utilisateur

NETGEAR

NETGEAR ProSAFE WNDAP380R Manuel utilisateur

NETGEAR

NETGEAR WN203 Manuel utilisateur

NETGEAR

NETGEAR PowerLine XWNB5602 Manuel utilisateur

NETGEAR

NETGEAR WG602v3 - Wireless Access Point Manuel utilisateur

NETGEAR

NETGEAR WG602v4 - Wireless Access Point Manuel

NETGEAR

NETGEAR WG102 - ProSafe Wireless Access Point Manuel utilisateur

NETGEAR

NETGEAR PowerLine XWNB5602 Manuel utilisateur

NETGEAR

NETGEAR WAX630E Manuel utilisateur

NETGEAR

NETGEAR WG302 - 802.11g ProSafe Wireless Access... Manuel utilisateur

NETGEAR

NETGEAR WG602v2 - Wireless Access Point Manuel utilisateur

NETGEAR

NETGEAR WG602v4 - Wireless Access Point Manuel utilisateur

NETGEAR

NETGEAR ProSAFE WN203-200PES Manuel utilisateur

NETGEAR

NETGEAR WG103 ProSafe Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur
