1. Introduction and Hardware

Description

The NETGEAR® ProSAFE® 24-Port 10/100 Smart Switch with 2 Gigabit Ports FS726Tv2 is a

state-of-the-art, high-performance, IEEE-compliant network solution for users who require the

flexibility of a small form-factor pluggable (SFP) GBIC slot. To simplify installation, the switch is

shipped ready for use out of the box.

The chapter covers the following topics:

•Overview

•Switch Features

•Package Contents

•Front Panel

•Back Panel

•LEDs

•Product Label

•RJ-45 Ports

•SFP GBIC Module

•Factory Defaults Button and Reset Button

Note: For more information about the topics covered in this manual, visit

the support website at support.netgear.com.

Note: Firmware updates with new features and bug fixes are made

available from time to time on downloadcenter.netgear.com. Some

products can regularly check the site and download new firmware,

or you can check for and download new firmware manually. If the

features or behavior of your product do not match what is described

in this guide, you might need to update your firmware.

Introduction and Hardware Description

ProSAFE 24-Port 10/100 Smart Switch with 2 Gigabit Ports FS726Tv2

Overview

This hardware installation guide is for the NETGEAR ProSAFE 24-Port 10/100 Smart Switch

with 2 Gigabit Ports FS726Tv2. The switch provides twenty-four 10/100BASE-T ports, two

10/100/1000BASE-T ports, one of which functions as a combo port, and one small

form-factor pluggable (SFP) GBIC slot that functions as a combo port.

You can make high-speed connections using the Gigabit Ethernet ports. For example:

•Connecting switches to each other with high-speed links

•Connecting to a network backbone

•Linking to high-speed servers

•Providing 10/100/1000 Mbps copper and 100/1000 Mbps fiber connectivity

Note: In this guide, the NETGEAR ProSAFE 24-Port 10/100 Smart Switch

with 2 Gigabit Ports FS726Tv2 is referred as the switch.

The switch also provides the benefit of administrative management with a complete package

of features to monitor, configure, and control the network. With the web management

interface, you can view the switch’s many features and use them in a simple and intuitive

manner. The switch’s management features include configuration for port and switch

information, VLAN for traffic control, port trunking for increased bandwidth, and Class of

Service (CoS) for traffic prioritization. Initial discovery of the switch on the network requires

the Smart Control Center, a utility that runs on a computer.

You can use the switch freestanding or rack-mounted in a wiring closet or equipment room.

The switch is IEEE-compliant and provides low latency for high-speed networking. All ports

can automatically negotiate to the highest speed. This capability makes the switch well suited

for environments that have a mix of Ethernet, Fast Ethernet, and Gigabit Ethernet devices. In

addition, all RJ-45 ports operate in half- or full-duplex mode. The maximum segment length is

328 feet (100 meters) over a Category 5 twisted-pair cable.

You can use the switch as a desktop to build a small network that enables you to have

1000 Mbps access to a file server. With full duplex enabled, the switch port connected to the

server or computer can provide 2000 Mbps throughput.

Introduction and Hardware Description

ProSAFE 24-Port 10/100 Smart Switch with 2 Gigabit Ports FS726Tv2

Figure 1. Example of a network configuration

Switch Features

The following list identifies the key features of the switch:

•Twenty-four RJ-45 10/100 Fast Ethernet switching ports.

•Two RJ-45 10/100/1000 Gigabit Ethernet switch ports, one of which (26T) functions as a

combo port.

•One small form-factor pluggable (SFP) GBIC slot (26F) that functions as a combo port.

A combo port is a single port with two physical connections, SFP fiber and RJ-45 copper.

The RJ-45 copper port corresponding to the combo port is the 10/100/1000 autosensing

Gigabit Ethernet switch combo port. The SFP fiber port corresponding to the combo port

is the SFP GBIC slot. If both the RJ-45 copper combo port and the SFP fiber combo port

have devices connected, the device that was connected first takes precedence. In other

words, the combo port functions on a first-come, first-served basis.

The following SFP GBICs are supported:

-1000BASE-SX (NETGEAR AGM731F)

-1000BASE-LX (NETGEAR AGM732F)

•The switch provides full compatibility with IEEE standards:

-IEEE 802.3i (10BASE-T)

-IEEE 802.3u (100BASE-TX, 100BASE-FX)

Introduction and Hardware Description

ProSAFE 24-Port 10/100 Smart Switch with 2 Gigabit Ports FS726Tv2

-IEEE 802.3x (full-duplex flow control)

-IEEE 802.3z (1000BASE-X)

-IEEE 802.3ab (1000BASE-T)

-IEEE 802.3az (EEE)

•Autosensing and autonegotiating capabilities for all ports.

•Auto MDI/MIDX technology is supported on all ports.

•Automatic address-learning function to build the packet-forwarding information table. The

table contains up to 8 K Media Access Control (MAC) addresses.

•Full- and half-duplex functions for all 10/100/1000 Mbps ports.

•Store-and-forward transmission to remove corrupt packets from the network.

•Full-duplex IEEE 802.3x pause frame flow control.

•Active flow control to minimize packet loss and frame drops.

•Half-duplex back-pressure control.

•Per-port LEDs and system Power LED.

•Internal power supply.

•Standard 1U high, rack-mountable 19-inch chassis.

Package Contents

The following figure shows the package contents of the switch.

350 East Plumeria Drive

San Jose, CA 95134

USA

Sept 2013

202-11251-01

350 East Plumeria Drive

San Jose, CA 95134

USA

Sept 2013

202-

1251-01

ProSAFE Fast Ethernet PoE Smart

Switch FS726Tv2

Hardware Installation Guide

Figure 2. Package contents

Introduction and Hardware Description

ProSAFE 24-Port 10/100 Smart Switch with 2 Gigabit Ports FS726Tv2

Verify that the package contains the following:

•NETGEAR ProSAFE 24-Port 10/100 Smart Switch with 2 Gigabit Ports FS726Tv2

•Rubber footpads for tabletop installation

•Power cord

•Rack-mount kit for installing the switch in a 19-inch rack

•Smart Switch resource CD with the Smart Control Center utility and a link to the online

Software Administration Manual.

•Installation guide

•Warranty support information card

If any of the parts are incorrect, missing, or damaged, contact your NETGEAR dealer. Keep

the carton, including the original packing materials, in case you need to return the product for

repair.

Front Panel

The switch provides twenty-four 10/100BASE-T ports, two 10/100/1000BASE-T copper ports,

one of which (26T) is a combo port, and one small form-factor pluggable (SFP) GBIC slot

(26F), which functions as a combo port.

1 through 4,

see Figure 4

567

Combo port

[26T and 26F]

Figure 3. Front panel

Figure 4. Close up left side of the front panel

Introduction and Hardware Description

ProSAFE 24-Port 10/100 Smart Switch with 2 Gigabit Ports FS726Tv2

The front panel contains the following components:

1. Power LED

2. Recessed Defaults button to restore the switch to the factory defaults

3. Recessed Reset button to reboot the switch

4. Twenty-four Link/ACT port LEDs

5. Twenty-four RJ-45 10/100BASE-T ports

6. Two RJ-45 Gigabit Ethernet ports with corresponding Link/ACT LEDs

7. One small form-factor pluggable (SFP) GBIC slot with a corresponding Link/ACT LED

Back Panel

The back panel provides a 100–240 VAC/50–60 Hz universal power inlet, which is a standard

AC power receptacle that accommodates the supplied power cord.

Figure 5. Back panel

LEDs

The following table describes the LEDs.

Table 1. LED descriptions

Port LED Designation

(Not applicable, system LED) Power • Off. Power is disconnected.

•Solid green. Power is supplied to the switch and the

switch is operating normally.

Twenty-four 10/100BASE-T

ports (one LED for each port) Link/ACT • Off. No link is established on the port.

•Solid green.A valid link of any speed is established on the

port.

•Blinking green. Packet transmission or reception occurs

at any speed on the port.

Two Gigabit Ethernet ports

(one LED for each port: 25

and 26T)

Link/ACT • Off. No link is established on the port, or the

•Solid green. A valid 1000 Mbps link is established on the

port.

•Blinking green. Packet transmission or reception occurs

at 1000 Mbps on the port.

•Solid yellow. A valid 10 or 100 Mbps link is established on

the port.

•Blinking yellow. Packet transmission or reception occurs

at 10 or 100 Mbps on the port.

Introduction and Hardware Description

ProSAFE 24-Port 10/100 Smart Switch with 2 Gigabit Ports FS726Tv2

Product Label

The product label on the back panel of the switch shows the hardware model number and

version, the software version, the unique MAC address, and the unique serial number. The

following figure shows a generic product label.

Figure 6. Generic product label

RJ-45 Ports

RJ-45 ports are autosensing ports. When you insert a cable into an RJ-45 port, the switch

automatically ascertains the maximum speed (10, 100, or 1000 Mbps) and duplex mode

(half- or full-duplex) of the attached device. All ports support a twisted-pair cable that is

terminated with an 8-pin RJ-45 plug.

To simplify the procedure for attaching devices, all RJ-45 ports support Auto MDI/MIDX. This

technology enables you to attach devices to the RJ-45 ports with either straight-through or

crossover cables. When you insert a cable into the switch’s RJ-45 port, the switch

automatically configures the RJ-45 port to enable communications with the attached device.

With Auto MDI/MIDX technology, you do not need to configure uplink connections, and you

do not need to think about whether to use crossover or straight-through cables when you

attach a device.

One SFP GBIC slot (one LED

for slot 26F) Link/ACT • Off. No link is established on the GBIC in the slot.

•Solid green. A valid 1000 Mbps link is established on the

GBIC in the slot.

•Blinking green. Packet transmission or reception occurs

at 1000 Mbps on the GBIC in the slot.

•Solid yellow. A valid 100 Mbps link is established on the

GBIC in the slot.

•Blinking yellow. Packet transmission or reception occurs

at 100 Mbps on the GBIC in the slot.

Table 1. LED descriptions (continued)

Port LED Designation

Autres manuels pour ProSAFE FS726Tv2

Table des matières

Autres manuels NETGEAR Changer

NETGEAR

NETGEAR FSM7352PS - ProSafe 48 Port 10/100 L3 Managed Stackable... Manuel utilisateur

NETGEAR

NETGEAR GS728TPv2 Manuel utilisateur

NETGEAR

NETGEAR ProSafe FS752TP Manuel utilisateur

NETGEAR

NETGEAR GSM7224v2 - Layer 2 Managed Gigabit Switch Manuel utilisateur

NETGEAR

NETGEAR GSM7224 - Switch Manuel

NETGEAR

NETGEAR FSM726 - ProSafe Managed Switch Manuel utilisateur

NETGEAR

NETGEAR FSM7352S - ProSafe Switch Manuel utilisateur

NETGEAR

NETGEAR FS700TS Manuel utilisateur

NETGEAR

NETGEAR ProSAFE GS108Ev3 Manuel utilisateur

NETGEAR

NETGEAR GSM7248R - ProSafe Switch Manuel utilisateur

NETGEAR

NETGEAR ProSAFE M7100-24X Manuel utilisateur

NETGEAR

NETGEAR ProSafe GS116 Manuel utilisateur

NETGEAR

NETGEAR GSM7352SNA - Prosafe 48 Port Gigabit L3 Managed Stackable... Manuel utilisateur

NETGEAR

NETGEAR 700 Series Guide de sécurité

NETGEAR

NETGEAR GSM7224v2 - Layer 2 Managed Gigabit Switch Manuel utilisateur

NETGEAR

NETGEAR ProSafe JGS524 Manuel

NETGEAR

NETGEAR ProSafe GS104 Manuel utilisateur

NETGEAR

NETGEAR GS748Tv4 Mode d’emploi

NETGEAR

NETGEAR ProSafe JGS524v2 Manuel de la liste des pièces

NETGEAR

NETGEAR ProSafe GS108 Manuel utilisateur

NETGEAR

NETGEAR GS728TPv3 Manuel

NETGEAR

NETGEAR GS108X Manuel utilisateur

NETGEAR

NETGEAR GS105v5 Manuel utilisateur

NETGEAR

NETGEAR GS305P Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
