NETGEAR MS108TUP Manuel

Hardware Installation Guide

8-port Ultra60 PoE++ Multi-Gigabit (2.5G)

Ethernet Smart Switch

Model MS108TUP

NETGEAR, Inc.

350 E. Plumeria DriveOctober 2023

San Jose, CA 95134, USA202-12663-01

Support and Community

Visit netgear.com/support to get your questions answered and access the latest

downloads.

You can also check out our NETGEAR Community for helpful advice at

community.netgear.com.

Regulatory and Legal

Si ce produit est vendu au Canada, vous pouvez accéder à ce document en français

canadien à https://www.netgear.com/support/download/.

(If this product is sold in Canada, you can access this document in Canadian French at

https://www.netgear.com/support/download/.)

For regulatory compliance information including the EU Declaration of Conformity, visit

https://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

For NETGEAR’s Privacy Policy, visit https://www.netgear.com/about/privacy-policy.

By using this device, you are agreeing to NETGEAR’s Terms and Conditions at

https://www.netgear.com/about/terms-and-conditions. If you do not agree, return the

device to your place of purchase within your return period.

Do not use this device outdoors. The PoE source is intended for intra building connection

only.

Applicable to 6 GHz devices only: Only use the device indoors. The operation of 6 GHz

devices is prohibited on oil platforms, cars, trains, boats, and aircraft, except that

operation of this device is permitted in large aircraft while flying above 10,000 feet.

Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or

communications with unmanned aircraft systems.

Trademarks

Any non-NETGEAR trademarks are used for reference purposes only.

Revision History

CommentsPublish DatePublication Part

Number

Initial publication.October 2023202-12663-01

8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Smart Switch Hardware Installation Guide

Contents

Chapter 1 Introduction

Overview................................................................................................6

Features.................................................................................................6

Safety instructions and warnings........................................................7

Chapter 2 Hardware Overview

Front panel with ports and LEDs......................................................12

LEDs......................................................................................................13

Back panel...........................................................................................14

RJ-45 ports for 100/1000/2.5GBASE-T Ethernet connectivity......14

Multi-function Reset/Factory Defaults button.................................15

Restart (power-cycle) the switch...................................................15

Reset the switch to factory default settings but maintain the

registration status...........................................................................15

Reset the switch to factory default settings and erase the

registration status...........................................................................16

Chapter 3 Applications

PoE++ and PoE+ overview................................................................18

PoE++ and high-speed desktop switching.....................................19

Chapter 4 Installation

Step 1: Prepare the site......................................................................21

Step 2: Protect against electrostatic discharge..............................21

Step 3: Unpack the switch.................................................................22

Step 4: Install the switch....................................................................23

Install the switch on a flat surface.................................................23

Wall-mount the switch horizontally..............................................23

Wall-mount the switch vertically...................................................25

Mount the switch to a pole or another surface..........................25

Step 5: Connect devices to the switch.............................................26

Step 6: Check the installation...........................................................26

Step 7: Apply power and check the LEDs.......................................27

Step 8: Manage the switch................................................................27

Chapter 5 Troubleshooting

Troubleshooting chart.......................................................................31

PoE troubleshooting suggestions....................................................32

Additional troubleshooting suggestions.........................................33

8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Smart Switch Hardware Installation Guide

Introduction

This hardware installation guide complements the installation guide that came with your

switch and applies to the NETGEAR 8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet

Smart Switch Model MS108TUP.

The switch provides eight Multi-Gigabit Ethernet copper ports that each can support

2.5 Gbps, 1 Gbps, and 100 Mbps speed.

Ports 1–4 support Ultra60 PoE++ (802.3bt) so that each port can deliver power of up to

60W PoE++ to devices such as WiFi 6 access points, security cameras, PoE speakers,

and LED lighting.

Ports 5–8 each can deliver power of up to 30W PoE+ (802.3at) to devices that do not

require high power. The maximum PoE power budget of the switch across all active

PoE+ and PoE++ ports is 230W.

This chapter serves as an introduction to the switch and includes the following sections:

• Overview

• Features

• Safety instructions and warnings

Note: For more information about the topics that are covered in this manual, visit the

support website at netgear.com/support.

Note: For technical specifications, see the data sheet at

https://www.netgear.com/business/wired/switches/plus. For switch documentation,

including the installation guide and user manual, visit netgear.com/support/download.

Overview

The switch provides eight Multi-Gigabit Ethernet copper ports that support 2.5 Gbps,

1 Gbps, and 100 Mbps speed:

•Ports 1–4: Support Ultra60 PoE++ (802.3bt), allowing each port to deliver power

up to 60W PoE++.

•Port 5–8: Support PoE+ (802.3at), allowing each port to deliver power up to 30W

PoE+.

All copper ports use RJ-45 connectors. The switch supports a maximum PoE power

budget of 230W across all active PoE+ and PoE++ ports.

Note: For information about application examples, see Applications on page 17.

You can install the switch freestanding or mounted to a wall. The switch is IEEE compliant

and offers low latency. All ports can automatically negotiate to the highest speed, which

makes the switch very suitable for a mixed environment with multispeed Gigabit Ethernet,

Gigabit Ethernet, and Fast Ethernet.

For 2.5 Gbps and 1 Gbps Ethernet connections, use Category 5e (Cat 5e) or higher-rated

Ethernet cables terminated with RJ-45 connectors.

Features

The switch supports the following key hardware features:

•Eight multispeed Ethernet ports (1–8), each of which supports 2.5G, 1G, and 100M

•Four Ultra60 PoE++ (802.3bt) ports (1–4)

•Four PoE+ (802.3at) ports (5–8)

•Total PoE power budget of 230W for the switch

•MAC table size of 16K

•40 Gbps line-rate, full-duplex, nonblocking switch fabric

•Full compatibility with IEEE standards:

- IEEE 802.3 Ethernet

- IEEE 802.3u 100BASE-T

- IEEE 802.3ab 1000BASE-T

- IEEE 802.3bz NBASE-T

Hardware Installation Guide6Introduction

8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Smart Switch Hardware Installation Guide

-IEEE 802.3x Full-duplex flow control

- IEEE 802.1Q VLAN tagging

- IEEE 802.3ad Link aggregation (LAG with LACP)

- IEEE 802.1ab LLDP

-IEEE 802.1p Class of Service (QoS)

- IEEE 802.1D Spanning Tree Protocol (STP)

- IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)

- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)

- IEEE 802.1x RADIUS network access control

-IEEE 802.3az Energy Efficient Ethernet (EEE)

-IEEE 802.1af (PoE)

- IEEE 802.1at (PoE+)

- IEEE 802.1bt (PoE++)

•AutoSensing and autonegotiating capabilities for all ports

•Auto Uplink™ technology is supported on all ports

•Automatic address learning function to build the packet-forwarding information

table. The table contains up to 16K Media Access Control (MAC) addresses

•Store-and-forward transmission to remove bad packets from the network

•Active flow control to minimize packet loss and frame drops

•Per-port status LEDs and system status LEDs.

•NETGEAR green power-saving features:

-Energy efficiency mode that fully conforms to the IEEE802.3az standard

- Per-port automatic change to a lower power mode when the port link is down

Safety instructions and warnings

Use the following safety guidelines to ensure your own personal safety and to help

protect your system from potential damage.

Hardware Installation Guide7Introduction

8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Smart Switch Hardware Installation Guide

To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment,

observe the following precautions:

•This product is designed for indoor use only in a temperature-controlled and

humidity-controlled environment.

Note the following:

-For more information about the environment in which this product must operate,

see the environmental specifications in the appendix or the data sheet.

-If you want to connect the product to a device located outdoors, the outdoor

device must be properly grounded and surge protected, and you must install an

Ethernet surge protector inline between the indoor product and the outdoor

device. Failure to do so can damage the product.

WARNING: Before connecting the product to outdoor cables or devices, see

https://kb.netgear.com/000057103 for additional safety and warranty information.

Failure to follow these guidelines can result in damage to your NETGEAR product,

which might not be covered by NETGEAR’s warranty, to the extent permissible by

applicable law.

•Observe and follow service markings:

- Do not service any product except as explained in your product documentation.

Some devices should never be opened.

-If applicable to your product, opening or removing covers that are marked with

the triangular symbol with a lightning bolt can expose you to electrical shock.

We recommend that only a trained technician services components inside these

compartments.

•If any of the following conditions occur, unplug the product from the power outlet,

and then replace the part or contact your trained service provider:

- Depending on your product, the power adapter, power adapter cable, power

cable, extension cable, or plug is damaged.

-An object fell into the product.

- The product was exposed to water.

- The product was dropped or damaged.

-The product does not operate correctly when you follow the operating

instructions.

•Keep the product away from radiators and heat sources. Also, do not block cooling

vents.

Hardware Installation Guide8Introduction

8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Smart Switch Hardware Installation Guide

•Do not spill food or liquids on your product components, and never operate the

product in a wet environment. If the product gets wet, see the appropriate section

in your troubleshooting guide, or contact your trained service provider.

•Do not push any objects into the openings of your product. Doing so can cause fire

or electric shock by shorting out interior components.

•Use the product only with approved equipment.

•If applicable to your product, allow the product to cool before removing covers or

touching internal components.

•Operate the product only from the type of external power source indicated on the

electrical ratings label. If you are not sure of the type of power source required,

consult your service provider or local power company.

•To avoid damaging your system, if your product uses a power supply with a voltage

selector, be sure that the selector is set to match the power at your location:

-115V, 60 Hz in most of North and South America and some Far Eastern countries

such as South Korea and Taiwan

- 100V, 50 Hz in eastern Japan and 100V, 60 Hz in western Japan

-230V, 50 Hz in most of Europe, the Middle East, and the Far East

•Be sure that attached devices are electrically rated to operate with the power available

in your location.

•Depending on your product, use only a supplied power adapter or approved power

cable:

If your product uses a power adapter:

-If you were not provided with a power adapter, contact your local NETGEAR

reseller.

-The power adapter must be rated for the product and for the voltage and current

marked on the product electrical ratings label.

If your product uses a power cable:

-If you were not provided with a power cable for your system or for any

AC-powered option intended for your system, purchase a power cable approved

for your country.

-The power cable must be rated for the product and for the voltage and current

marked on the product electrical ratings label. The voltage and current rating of

the cable must be greater than the ratings marked on the product.

•To help prevent electric shock, plug the system and peripheral power cables into

properly grounded power outlets.

Hardware Installation Guide9Introduction

8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Smart Switch Hardware Installation Guide

•If applicable to your product, the peripheral power cables are equipped with

three-prong plugs to help ensure proper grounding. Do not use adapter plugs or

remove the grounding prong from a cable. If you must use an extension cable, use

a three-wire cable with properly grounded plugs.

•Observe extension cable and power strip ratings. Make sure that the total ampere

rating of all products plugged into the extension cable or power strip does not

exceed 80 percent of the ampere ratings limit for the extension cable or power strip.

•To help protect your system from sudden, transient increases and decreases in

electrical power, use a surge suppressor, line conditioner, or uninterruptible power

supply (UPS).

•Position system cables, power adapter cables, or power cables carefully. Route

cables so that they cannot be stepped on or tripped over. Be sure that nothing rests

on any cables.

•Do not modify power adapters, power adapter cables, power cables or plugs. Consult

a licensed electrician or your power company for site modifications.

•Always follow your local and national wiring rules.

Hardware Installation Guide10Introduction

8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Smart Switch Hardware Installation Guide

Table des matières

Autres manuels NETGEAR Changer

NETGEAR

NETGEAR FS108 - ProSafe 10/100 Desktop Switch Manuel utilisateur

NETGEAR

NETGEAR FS728TS - ProSafe Smart Switch Manuel utilisateur

NETGEAR

NETGEAR GS108PP Manuel utilisateur

NETGEAR

NETGEAR DS508 - Hub - Stackable Manuel utilisateur

NETGEAR

NETGEAR FSM7326P - ProSafe Managed Switch Mode d’emploi

NETGEAR

NETGEAR GS716T - ProSafe Switch Manuel

NETGEAR

NETGEAR GSM7248R - ProSafe Switch Manuel utilisateur

NETGEAR

NETGEAR ProSAFE GS105Ev2 Manuel utilisateur

NETGEAR

NETGEAR GS108Tv2 - ProSafe Gigabit Smart Switch Coming... Manuel utilisateur

NETGEAR

NETGEAR APM408C Manuel utilisateur

NETGEAR

NETGEAR GS716T - ProSafe Switch Manuel utilisateur

NETGEAR

NETGEAR FS524S - Switch - Stackable Mode d’emploi

NETGEAR

NETGEAR ProSafe Plus GS116E Manuel utilisateur

NETGEAR

NETGEAR EN104TP EN104TP EN104TP Manuel utilisateur

NETGEAR

NETGEAR XS728T ProSAFE Manuel utilisateur

NETGEAR

NETGEAR ProSAFE GS724Tv4 Manuel utilisateur

NETGEAR

NETGEAR FSM726E-100NAS Mode d’emploi

NETGEAR

NETGEAR GS724Tv1 - ProSafe Gigabit Smart Switch Manuel utilisateur

NETGEAR

NETGEAR M4250 Series Manuel utilisateur

NETGEAR

NETGEAR GS110EMX Manuel utilisateur

NETGEAR

NETGEAR GSS108E Manuel utilisateur

NETGEAR

NETGEAR GSM7224 - Switch Manuel utilisateur

NETGEAR

NETGEAR FS728TS - ProSafe Smart Switch Manuel utilisateur

NETGEAR

NETGEAR GS750E Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
