Installation Guide
PS111W Wireless Ready Print Server
NETGEAR, INC.
4500 Great America Parkway
Santa Clara, CA 95054
USA
Phone: 1-888-N TG AR
-mail: support@N TG AR.com
www.N TG AR.com
Technical Support
YOU MUST R GIST R TO OBTAIN T CHNICAL SUPPORT. PL AS R TAIN
PROOF OF PURCHAS AND TH WARRANTY INFORMATION.
To register your product, get product support or obtain product information and product
documentation, go to http://www.N TG AR.com/register.
You will find technical support information at http://www.N TG AR.com/ through the
Customer Service area. If you want to contact technical support by telephone, see the support
information card for the correct telephone number for your country.
©2002 by N TG AR, Inc. All rights reserved.
N TG AR and Auto Uplink are trademarks or registered trademarks of N TG AR, Inc. in the United States and/or
other countries.
Other brand and product names are trademarks or registered trademarks of their respective holders.
Information is subject to change without notice.
Start Here
Instructions in this guide are for users with the following:
• Microsoft®Windows®95,Windows®98,Windows®M , Windows®2000, Windows XP®,
or Windows NT®
• An thernet network card with the TCP/IP protocol enabled
• A N TG AR®MA401 802.11b Wireless PCMCIA PC Card*
• An optional 802.11b wireless capable network
*PC Card not included, sold separately
All other users must refer to Installation and Reference for the N TG AR®Printer Server on
the PS100 Series Print Server Resource CD for complete hardware and software installation
instructions.
N TG AR provides an excellent family of wireless products. The M 102 802.11b wireless
access point bridges between a 802.11b wireless network and an thernet. The MA401
802.11b wireless PC card brings mobile networking capability to your notebook computer.
Using an MA101 802.11b Wireless USB Adapter on a desktop PC gives your PC access to a
802.11b wireless local area network (WLAN).
1
Package Contents
Verify that your package contains the following:
• PS111W Wireless Ready Print Server
• 12V, 800mA Power Adapter
• PS100 Series Print Server
Resource CD
• Installation Guide
• Warranty & Owner
Registration Card
• Support Information Card
Note: If the supplied power adapter
does not meet your country
requirements, make sure you use
the appropriate power adapter as
required by your national electrical
codes and ordinances.
Call your reseller or N TG AR Customer Support in your area if there are any wrong,
missing, or damaged parts. Keep the carton, including the original packing materials. Use them
to repack the print server if you need to return it for repair.
2
PS111W Print Server Resource CD,
installation guide, support information
card & warranty/registration card
PS111W
Print Server
Power adapter
LEDs
The following table describes the activity of the L Ds on the PS111W
Wireless Ready Print Server
Label Color Activity Description
PWR Green On Power is supplied to the print server.
(Power)
AL RT Amber Off Normal Operation
On Hardware error
Blinking Upgrading BIOS flash ROM
LAN Green Off No LAN connection
On Normal Operation – Idle
(No data is being transmitted or
received from the LAN.)
Blinking Normal Operation – Active
(Data is being transmitted or
received from the LAN.)
WLAN Green Off No wireless PC card detected
On Normal Operation – Idle
(No data is being transmitted or
received from the wireless network.)
Blinking Normal Operation – Active
(Data is being transmitted or
received from the wireless network.)
3
Wireless Ready Print Server PS111W
Model
WLANLANALERTPWR
Wireless PC Card Slot
To take advantage of the optional wireless capability, you must remove the rubber slot cover
before you can put in a N TG AR MA401 802.11b Wireless PC Card.
Insert the PC card very carefully to avoid damaging to the PC card or the print server slot.
Apply only enough force to push the PC card firmly and slowly into the print server.
4
Rear Panel
Label Function Description
PRINT R Parallel Accepts an I 1284 printer cable that connects
Printer Port to the printer.
N TWORK 10/100 Auto-sensing 10/100 Mbps thernet port for direct
BAS -T connection to a 10 Mbps or 100 Mbps port on a switch
Network Port or hub.
A small Diagnostic Briefly pressing the button has no effect. Pressing the
button and Restore- button for two seconds will print the status of the print
with no to-default server, including wired and wireless information, on the
label Button attached printer.
Note: This is the best way to obtain the IP address
of the print ser er, since the default setting for the
PS111W is DHCP.
Turn the power off, hold the Reset Button.
Powering on the print server and holding this button for
more than 10 seconds will restore the print server to the
factory default settings.
Warning: You will lose the current configuration in
the PS111W, so use this function with care.
12V DC Power Supply Accepts the 12V 800mA power supply.
Inlet Note: NETGEAR ad ises that you use genuine
NETGEAR accessories to a oid damaging the unit.
For part re-ordering, please refer to the Replacement
Power Adapter section at the end of this guide.
5
NETWORKPRINTER
12V DC
Typical applications
You can use only one of the following applications.
Wired LAN only
Use this configuration if no wireless card is installed in the PS111W Print Server
6
PS111W Printer Server
DS108 Hub
NETWORKPRINTER
12V DC
Printer
Wired LAN (Infrastructure Mode)
Requires that a NETGEAR MA401 02.11b Wireless PC card be installed in the PS111W Print Server.
In Infrastructure mode, the Wired LAN connection on the PS W CANNOT be used.
Note that configuration must be performed via a Wired connection, which can be disconnected
once the Wireless configuration is completed.
7
PS111W Printer Server
NETWORKPRINTER
12V DC
MA401 Card
Desktop PC
Notebook PC Notebook PC
Printer
Access Point
Wired LAN (Ad-hoc Mode)
Requires that a NETGEAR MA401 02.11b Wireless PC card be installed in the PS111W Print Server.
Note that configuration must be performed via a Wired connection, which can be disconnected
once the Wireless configuration is completed.
8
PS111W Printer Server
NETWORKPRINTER
12V DC
MA401 Card
Printer
Notebook PC
Desktop
