The Telkom Easy Guide to set up your

Netgear N300 DSL Router.

First, unpack

your new

router.

1 DSL ﬁlter

1 DSL splitter

2 telephone cables

1 LAN cable

1 power supply cord

Your Netgear N300 Router

2 external antennae

1 2

Let’s get

started.

Connect the 12vDC power supply into

your router and into a power socket

Plug the short end of

the DSL splitter into

the telephone jack.

Take the dark grey cable and plug the

one end into red socket marked DSL on

the DSL splitter and the other end into

the power supply port marked IN

Take the light grey cable and plug the

one end into the power supply port

marked OUT and the other end into the

back of the router.

Your telephone now plugs

into the green socket marked

Phone of the DSL splitter.

Plug the yellow LAN cable into the yellow

port on the back of the router, and the other

end into the LAN port on your computer.

Switch your router on by pressing the power

button at the back of the router.

Ready

to go.

The power

light will ﬁrst come

on red and then

eventually turn green.

The DSL light must stay

green. If this is ﬂashing it

means that no connection is

synced with exchange.

The LAN 1 light

must be green if

the LAN cable is

plugged in.

The internet light will

also be green if the

account is active.

The Wi-Fi light will

be green if Wi-Fi is

enabled.

5All of these lights can ﬂash as

data is transferred.

Setting up

your Router.

Open your internet browser and

go to http://10.0.0.2 and click

Enter. Type in admin for both the

username and password.

If the router is not online, and has not been

conﬁgured, click Setup, then click Setup Wizard.

Click Next.

1 2 3

From the Internet Connection Mode

dropdown, select Use ADSL connection

ﬁrst and if fail use mobile broadband

connection and click Next.

Select South Africa from the Country dropdown,

then select No I want to conﬁgure the router

myself. Click Next. On the basic settings screen,

enter in the username and password that were

SMS’d to you and click Apply.

The router will save your settings and reboot. It will

also try and connect to the internet so keep an eye

on the green LED lights.

After your settings have been saved, the basic

settings screen will re-appear.

In the left hand navigation menu, click on

Wireless Settings to conﬁgure the Wi-Fi.

4 5 6

Halfway-mark.

In the Wi-Fi Conﬁguration page, under Wireless

Network change Wi-Fi name in Name of SSID

ﬁeld to NETGEAR_1Meg. Under the Security

Options ensure WPA2-PSK (AES) is selected.

Scroll down to the bottom of the page and type

the password of your choice in the Password ﬁeld.

Click Apply.

In the left hand navigation menu, under

Maintenance click on Set Password. Change the

current password of the Router to your preferred

password and click Apply. The router may ask you

to log in again using the new password.

7 8 9

Almost

there...

It is important to log out properly by clicking

Logout, and not just shutting down your

browser window. Activate your internet account

by opening your web browser and go to

www.telkom.co.za/verifyadsl

10 11

Complete the ﬁelds with your telephone number

and order number and click on Submit.

You can now connect your internet-enabled

devices through Wi-Fi.

Use the same name and password you created

when you set up your DSL router.

Last

few steps.

No connection?

Don’t panic...

Plug your dongle into the

back of the router.

Setting up

your Dongle.

Open your internet browser and

go to http://10.0.0.2 and click

Enter. Type in admin for both

the username and password. Click

You will need to have the username and password

that was SMS’d to you handy. A wizard will

launch that will take you through the steps Click

Broadband Settings from the left hand navigation

menu and click Next.

From the Internet Connection Mode dropdown,

select that the internet connection always Use

ADSL connection ﬁrst and if fail use mobile

broadband connection and click Apply.

Wait for the settings to be updated.

Your Router will restart.

1 2 3
