NETGEAR JGS524FNA Manuel utilisateur

ProSafe 24-Port Gigabit Switch JGS524F

Step 2. Connect power Step 3. Check statusStep 1. Connect equipment

JGS524F

Optional router

Computer Server

Optional

modem

Internet

Installation Guide

Step 1. Connect equipment

Off

Power LED

Activity (blinking)

No link (off)

Link

Port Link/ACT LEDs

1000 Mbps

100 Mbps

Port Speed LEDs

JGS524F_IG_20Sept2012.fm Page 1 Thursday, September 20, 2012 10:28 AM

September 2012

This symbol appears in accordance with the European Union Directive 2002/96 on the Waste

Electrical and Electronic Equipment (the WEEE directive). If you dispose of this product in the

European Union, treat and recycle it in accordance with your jurisdiction’s laws that implement the

WEEE directive.

NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of

NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to

change without notice. Other brand and product names are registered trademarks or trademarks of their

For indoor use only in all EU countries and Switzerland.

For the complete EU Declaration of Conformity, visit

http://support.netgear.com/app/answers/detail/a_id/11621/.

Statement of Conditions: In the interest of improving internal design, operational function, and/or reliability,

NETGEAR reserves the right to make changes to the products described in this document without notice.

NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit

layout(s) described herein.

Specifications

Specification Description

Network interface RJ-45 connector for 10BASE-T, 100BASE-TX, or 1000BASE-T

Network cable Category 5e (Cat 5e) or better Ethernet cable

Ports 24

Power adapter 100-240V @ 1.0A AC, 50/60 Hz internal universal power

supply

Power consumption 18.2W max

Weight 1.688 Kg (3.721 lbs)

Dimensions

(W x D x H)

328 mm x 169 mm x 43.2 mm

12.91 in. x6.65 in. x1.70in.

Operating

temperature

0–50° C (32–122° F)

Operating humidity 10%–90% relative humidity, noncondensing

Electromagnetic

compliance

CE Class A, FCC Class A, VCCI Class A,

C-Tick Class A, CCC

Safety agency

approvals

CE, Commercial UL listed (UL 60950-1), CB, KC, CCC

Technical Support

After installing your device, locate the serial number on the label of your product and

use it to register your product at https://my.netgear.com.

You must register your product before you can use NETGEAR telephone support.

NETGEAR recommends registering your product through the NETGEAR web site.

For product updates and web support, visit http://support.netgear.com.

JGS524F_IG_20Sept2012.fm Page 2 Thursday, September 20, 2012 10:28 AM
