NETGEAR GC510P Manuel

Insight Managed 8-Port

Gigabit Ethernet PoE+ Smart

Cloud Switch with 2 SFP Fiber

Ports

Hardware Installation Guide

Models GC510P and GC510PP

September 2017

202-11780-02

350 E. Plumeria Drive

San Jose, CA 95134

USA

Support

Thank you for purchasing this NETGEAR product.You can visit www.netgear.com/support to register your

product, get help, access the latest downloads and user manuals, and join our community.We recommend that

you use only official NETGEAR support resources.

Conformity

For the current EU Declaration of Conformity, visit http://kb.netgear.com/app/answers/detail/a_id/11621.

Compliance

For regulatory compliance information, visit http://www.netgear.com/about/regulatory.

See the regulatory compliance document before connecting the power supply.

Trademarks

©NETGEAR, Inc., NETGEAR, and the NETGEAR Logo are trademarks of NETGEAR, Inc.Any non-NETGEAR

trademarks are used for reference purposes only.

Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports

Contents

Chapter 1 Introduction

Overview................................................................................................................6

Features.................................................................................................................7

Safety Instructions and Warnings..........................................................................8

Chapter 2 Hardware Overview

Hardware Description..........................................................................................12

Front Panel......................................................................................................12

Back Panel......................................................................................................12

LEDs...............................................................................................................13

Switch Hardware Interfaces.................................................................................14

RJ-45 Ports for 10/100/1000M BASE-T Ethernet Connectivity.......................14

SFP Ports for Fiber Connectivity.....................................................................15

Multi-Function Reset Button............................................................................15

Chapter 3 Applications

PoE Applications..................................................................................................18

PoE Overview..................................................................................................18

Connect PoE Equipment in a Business Environment......................................19

Connect PoE Equipment for Surveillance and Security..................................20

Desktop Switching...............................................................................................21

Chapter 4 Installation

Step 1: Prepare the Site.......................................................................................23

Step 2: Protect Against Electrostatic Discharge...................................................23

Step 3: Unpack the Switch...................................................................................24

Step 4: Install the Switch......................................................................................25

Install the Switch on a Flat Surface.................................................................25

Wall-Mount the Switch.....................................................................................25

Wall-Mount the Switch Horizontally With the Back Panel Facing Down.....26

Wall-Mount the Switch Horizontally With the Back Panel Facing Up..........27

Wall-Mount the Switch Vertically With the Back Panel Facing Left.............29

Poor Wall-Mounting Position.......................................................................30

Mount the Switch to a Pole or Another Surface...............................................31

Install the Switch in a Rack.............................................................................31

Optional Step 5: Install SFP Transceiver Modules...............................................31

Step 6: Connect Devices to the Switch................................................................32

Step 7: Check the Installation..............................................................................32

Step 8: Apply Power and Check the LEDs...........................................................33

Step 9: Manage the Switch..................................................................................33

Chapter 5Troubleshooting

Troubleshooting Chart..........................................................................................35

PoE Troubleshooting Suggestions.......................................................................36

Additional Troubleshooting Suggestions..............................................................36

Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports

Introduction

This hardware installation guide is for the following NETGEAR Insight managed switch models:

•8-Port Gigabit Ethernet PoE+ Insight Managed Smart Cloud Switch with 2 SFP Fiber Ports, Model GC510P

•8-Port Gigabit Ethernet High-Power PoE+ Insight Managed Smart Cloud Switch with 2 SFP Fiber Ports,

Model GC510PP

The switch provides eight Gigabit Ethernet RJ-45 copper ports and two dedicated Gigabit SFP fiber ports.

Both models support Power over Ethernet Plus (PoE+) on all eight RJ-45 copper ports so that you can let the

switch provide power to devices that are PoE and PoE+ capable, such as WiFi access points, VoIP phones,

and IP security cameras.The switches differ in their maximum PoE power budget:

•Model GC510P.This model can supply up to 30W PoE (IEEE 802.3at) to each port, with a maximum PoE

power budget of 134W across all active PoE+ ports.

•Model GC510PP.This model can supply up to 30W PoE (IEEE 802.3at) to each port, with a maximum PoE

power budget of 195W across all active PoE+ ports.

The hardware installation guide complements the installation guide that came with your switch.

This chapter serves as an introduction to the switch and includes the following sections:

•Overview

•Features

•Safety Instructions and Warnings

For more information about the topics that are covered in this manual, visit the support website

at support.netgear.com.

Note

For technical specifications, see the data sheet at

netgear.com/business/products/switches/app-managed-smart-cloud/gigabit-switch.aspx#tab-resources.

For switch documentation, visit downloadcenter.netgear.com.

Note

Overview

The switch provides eight Gigabit Ethernet copper ports and two dedicated Gigabit SFP fiber ports. All

copper ports use RJ-45 connectors.The SFP ports require a standard small form-factor pluggable (SFP)

gigabit interface converter (GBIC, also referred to as transceiver module), which is sold separately from the

switch.The switch integrates full-duplex, nonblocking switch fabric that provides full-wire speed for all packet

sizes.

The switch supports PoE+ on all copper ports with a maximum PoE power budget of 134W (model GC510P)

or 195W (model GC510PP) across all active PoE+ ports.

For information about application examples, see Applications on page 17.Note

The switch provides management options that let you discover the switch on the network and configure,

monitor, and control the switch:

•NETGEAR Insight app. Using the NETGEAR Insight app, you can discover the switch on the network

and add the switch to the NETGEAR Insight app so that you can perform basic management and

monitoring tasks from your smartphone.You can choose from four methods to add the switch to the

NETGEAR Insight app:You can scan the serial number bar code of the switch, add the switch from the

Day Zero window, add the switch from the Network window, or add the switch from the Device List

window. For more information, see the NETGEAR knowledge base articles at support.netgear.com.

•Local browser–based management interface.Using thelocal browser–basedmanagementinterface,

in this guide referred to as the local browser interface, you can perform very advanced configurations

and, if needed, debugging.For more information, see the user manual, which you can download from

downloadcenter.netgear.com.

The switch is designed to be managed using the NETGEAR Insight app. By default,

the local browser interface is disabled and you cannot use it to manage the switch

while the NETGEAR Insight app is enabled to manage the switch.

Note

You can install the switch freestanding (on a desktop), wall-mounted, using the VESA-standard mounting

holes and supplied wall-mount kit, or rack-mounted in a standard 19-inch rack, using the supplied rack-mount

kit.The switch is IEEE compliant and offers low latency. All ports can automatically negotiate to the highest

speed, which makes the switch very suitable for a mixed environment with Gigabit Ethernet and Fast Ethernet.

For Gigabit Ethernet connections, use Category 5 (Cat 5) or higher-rated Ethernet cables terminated with

RJ-45 connectors.

Introduction

Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports

Features

The switch includes the following key hardware features:

•Eight Gigabit Ethernet ports.

•Two dedicated Gigabit SFP fiber ports.

•PoE and PoE+ on copper ports:

-Eight ports PoE+ supporting both IEEE 802.3af and IEEE 802.3at

-Total PoE power budget of 134W (model GC510P) or 195W (model GC510PP)

•MAC table size of 16K entries.

•Switch fabric full duplex nonblocking.

•Includes the following mounting hardware:

-Four rubber footpads for tabletop installation

-Wall-mount screw kit for wall installation

-Rack-mount brackets and screw kit for rack-mount installation in a standard 19-inch rack

•Full compatibility with IEEE standards:

-IEEE 802.3 Ethernet

-IEEE 802.3u 100BASE-T

-IEEE 802.3ab 1000BASE-T

-IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX

-IEEE 802.1Q VLAN tagging

-IEEE 802.3x Full-duplex flow control

-IEEE 802.3ad Link aggregation (LAG with LACP)

-IEEE 802.1ab LLDP

-IEEE 802.1p Class of Service (QoS)

-IEEE 802.1D Spanning Tree Protocol (STP)

-IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)

-IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)

-IEEE 802.1x RADIUS network access control

-IEEE 802.3az Energy Efficient Ethernet (EEE)

-IEEE 802.3af (PoE)

-IEEE 802.3at (PoE+)

Introduction

Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports

•AutoSensing and autonegotiating capabilities for all ports.

•Auto Uplink™technology is supported on all ports.

•Automatic address learning function to build the packet-forwarding information table.The table contains

up to 16K Media Access Control (MAC) addresses.

•Store-and-forward transmission to remove bad packets from the network.

•Active flow control to minimize packet loss and frame drops.

•Half-duplex backpressure control.

•Per-port status LEDs and system status LEDs:

-System Power LED (front and back panels)

-Cloud Connection LED (front and back panels)

-Fan LED (model GC510PP only)

-PoE Max or Fault LED

-Per-port link, speed, and activity LED for copper ports

-Per-port PoE status LED for copper ports

-Per-port link and activity LED for SFP fiber ports

•NETGEAR green power-saving features:

-Energy efficiency mode that fully conforms to the IEEE 802.3az standard

-Per-port automatic change to a lower power mode when the port link is down

Safety Instructions andWarnings

Use the following safety guidelines to ensure your own personal safety and to help protect your system from

potential damage.

To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment, observe the following

precautions:

•This product is designed for indoor use only in a temperature-controlled (0–50°C) and humidity-controlled

(90 percent maximum relative humidity, noncondensing) environment.

Any device that is located outdoors and connected to this product must be properly grounded and surge

protected.

To the extent permissible by applicable law, failure to follow these guidelines can result in damage to

your NETGEAR product, which might not be covered by NETGEAR’s warranty.

•Observe and follow service markings:

-Do not service any product except as explained in your system documentation.

-Opening or removing covers that are marked with the triangular symbol with a lightning bolt can

expose you to electrical shock.We recommend that only a trained technician services components

inside these compartments.

Introduction

Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports

•If any of the following conditions occur, unplug the product from the electrical outlet and replace the part

or contact your trained service provider:

-The power cable, extension cable, or plug is damaged.

-An object fell into the product.

-The product was exposed to water.

-The product was dropped or damaged.

-The product does not operate correctly when you follow the operating instructions.

•Keep your system away from radiators and heat sources. Also, do not block cooling vents.

•Do not spill food or liquids on your system components, and never operate the product in a wet

environment.If the system gets wet, see the appropriate section in your troubleshooting guide, or contact

your trained service provider.

•Do not push any objects into the openings of your system.Doing so can cause fire or electric shock by

shorting out interior components.

•Use the product only with approved equipment.

•Allow the product to cool before removing covers or touching internal components.

•Operate the product only from the type of external power source indicated on the electrical ratings label.

If you are not sure of the type of power source required, consult your service provider or local power

company.

•To avoid damaging your system, be sure that the voltage selection switch (if provided) on the power

supply is set to match the power at your location:

-115V, 60 Hz in most of North and South America and some Far Eastern countries such as South

Korea and Taiwan

-100V, 50 Hz in eastern Japan and 100V, 60 Hz in western Japan

-230V, 50 Hz in most of Europe, the Middle East, and the Far East

•Be sure that attached devices are electrically rated to operate with the power available in your location.

•Use only approved power cables. If you were not provided with a power cable for your system or for

any AC-powered option intended for your system, purchase a power cable approved for your country.

The power cable must be rated for the product and for the voltage and current marked on the product

electrical ratings label.The voltage and current rating of the cable must be greater than the ratings

marked on the product.

•To help prevent electric shock, plug the system and peripheral power cables into properly grounded

electrical outlets.

•The peripheral power cables are equipped with three-prong plugs to help ensure proper grounding. Do

not use adapter plugs or remove the grounding prong from a cable.If you must use an extension cable,

use a three-wire cable with properly grounded plugs.

•Observe extension cable and power strip ratings.Make sure that the total ampere rating of all products

plugged into the extension cable or power strip does not exceed 80 percent of the ampere ratings limit

for the extension cable or power strip.

•To help protect your system from sudden, transient increases and decreases in electrical power, use a

surge suppressor, line conditioner, or uninterruptible power supply (UPS).

Introduction

Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports

•Position system cables and power cables carefully. Route cables so that they cannot be stepped on or

tripped over. Be sure that nothing rests on any cables.

•Do not modify power cables or plugs. Consult a licensed electrician or your power company for site

modifications.

•Always follow your local and national wiring rules.

Introduction

Insight Managed 8-Port Gigabit Ethernet PoE+ Smart Cloud Switch with 2 SFP Fiber Ports

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NETGEAR Routeur réseau

NETGEAR

NETGEAR LBR20 Fiche technique

NETGEAR

NETGEAR R6700AX Manuel utilisateur

NETGEAR

NETGEAR C6300 Manuel utilisateur

NETGEAR

NETGEAR Nighthawk CAX80 Manuel utilisateur

NETGEAR

NETGEAR Nighthawk RAX200 Manuel utilisateur

NETGEAR

NETGEAR FVS318G - ProSafe Gigabit VPN Firewall Data Sheet... Manuel utilisateur

NETGEAR

NETGEAR C6300v2 Manuel utilisateur

NETGEAR

NETGEAR FS116P - ProSafe 16 Port 10/100 Desktop... Manuel utilisateur

NETGEAR

NETGEAR Orbi RBW30 Manuel utilisateur

NETGEAR

NETGEAR FVX538v1 - ProSafe VPN Firewall Dual WAN Manuel utilisateur

NETGEAR

NETGEAR XR500 Nighthawk Manuel utilisateur

NETGEAR

NETGEAR FVL328 - Cable/DSL ProSafe VPN Firewall... Manuel utilisateur

NETGEAR

NETGEAR R6300 Manuel utilisateur

NETGEAR

NETGEAR N600 WNDR3400v2 Manuel utilisateur

NETGEAR

NETGEAR Nighthawk X4 Guide de dépannage

NETGEAR

NETGEAR DG632 - ADSL Modem Router Manuel utilisateur

NETGEAR

NETGEAR Nighthawk AC2400 Manuel utilisateur

NETGEAR

NETGEAR JNR3210 Manuel utilisateur

NETGEAR

NETGEAR RM356 RM356 RM356 Manuel utilisateur

NETGEAR

NETGEAR JNR3210 Manuel utilisateur

NETGEAR

NETGEAR DG834G Manuel

NETGEAR

NETGEAR ProSafe JGS516 Manuel utilisateur

NETGEAR

NETGEAR GS908E Manuel utilisateur

NETGEAR

NETGEAR Nighthawk X4S R7800 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité

LevelOne

LevelOne FBR-1416 Manuel utilisateur
