NETGEAR Powerline PLP2000 Manuel utilisateur

Quick Start

Powerline 2000 + Extra Outlet

Model PLP2000 (2 x PLP2000)

Package Contents

In some regions, a resource CD is included with your product.

Getting Started

Powerline adapters give you an alternative way to extend your network

using your existing electrical wiring. Plug two or more Powerline adapters

into electrical outlets to create a wired network connection. You can add

up to 16 adapters to extend your network.

Meet Your Adapter

Before you install your adapter, familiarize yourself with its LEDs, buttons,

and port.

Ethernet ports

Security/Factory Reset button

Power LED

Ethernet LED

Pick A Plug LED

Power LED Solid green. The electrical power is on.

Slow blinking green (blink every three seconds). The

adapter is in power saving mode.

Blinking green (blink every second). The adapter is in the

process of setting up security.

O. The adapter is not receiving electrical power.

Ethernet LED Solid green. The Ethernet port is linked.

O. No Ethernet connection is detected.

Pick A Plug LED The Pick A Plug feature lets you pick the electrical outlet with

the strongest performance, indicated by the color displayed

by the LED:

Red. Link rate < 50 Mbps (good).

Amber. Link rate > 50 and < 80 Mbps (better).

Green. Link rate > 80 Mbps (best).

O. The adapter did not ﬁnd any other compatible Powerline

devices using the same encryption key.

Security/Factory

Reset button

Press and hold the Security/Factory Reset button for 1 to

3 seconds and then release it to create a secure Powerline

network.

Press and hold the Security/Factory Reset button for 8

to 10 seconds, and then release it to return the Powerline

adapter to its factory default settings.

Ethernet ports Two GbE ports. Use Ethernet cables to connect your wired

devices, including computers, WiFi routers, or game consoles,

to your Powerline network.

For information about the standards your adapter meets, see the user

manual.

Install Your Adapters

Room 1 Room 2

Secure Your Network

Setting security is optional, but highly recommended.

¾To create a secure network:

1. Plug in your new adapters.

2. Wait until the Pick A Plug LEDs are lit.

3. Press the Security/Factory Reset button on one of the adapters for

two seconds, and then press the Security/Factory Reset button on

one of the other adapters in your existing network for two seconds.

You must press both buttons within two minutes.

Once secure pairing completes successfully, the power LEDs and Pick

A Plug LEDs are lit and the adapter can access the internet.

4. If you are installing additional adapters, repeat Step 3 with one of the

secure adapters and one of the adapters that is not yet secured.

Note: The Security/Factory Reset button does not work in power

saving mode (see Troubleshooting Tips on page 10).

Warning: Do not press the

Security/Factory Reset

button on the

Powerline adapter until installation is complete and the adapters are

communicating with each other (indicated by the blinking Power

LED). Pressing this button too soon can temporarily disable Powerline

communication. If this occurs, press and hold the Security/Factory

Reset button for 8 to 10 seconds to return the Powerline adapter to its

factory default settings.

Add Adapters

To add adapters before you conﬁgure the Security Reset feature, just plug

them in and connect the adapters to your equipment.

¾To add adapters to a Powerline network with security set:

1. Plug in and connect the new adapters.

2. On any of the adapters that are already a part of the secure network,

press and hold the Security/Factory Reset button for two seconds.

3. On the new adapter, press and hold the Security/Factory Reset

button for two seconds.

You must press both buttons within two minutes.

Troubleshooting Tips

Power LED is o. Make sure that power is supplied to the electrical

outlet, and that the Powerline devices are not plugged

into an extension cord, power strip, or surge protector.

Power LED is slowly

blinking green.

Power saving mode occurs when the Ethernet LED is

o. This can occur in the following circumstances:

• The Ethernet cable is unplugged.

• The device connected through the Ethernet cable

is turned o.

• The adapter is idle for 10 minutes.

It returns to normal mode within two seconds

aer the Ethernet link is up.

Pick A Plug LED is o. • If you already set network security, make sure

that all Powerline devices are using the same

encryption key. See the online user manual for

details.

• Press and hold the Security/Factory Reset

button for 8 to 10 seconds on each device to

return the Powerline adapter to its factory default

settings.
