NETGEAR EA101 Guide d'installation

NETGEAR’s EA101 USB Ethernet Adapter allows you to connect

Windows 98 PCs to standard Ethernet networks without opening your

computer.You just attach the adapter to an open USB port on either your

computer or a USB hub. No internal cards need to be installed, yet you're

instantly connected at 10 Mbps. Using the latest technology available,

NETGEAR once again simplifies networking for small and

home-based businesses.

SIMPLE TO USE

You can share files, play games, or share the Internet through a router with ease.

PORTABLE

Compact design lets you connect to either your desktop PC or take it on the road and

connect to your laptop.

COMPATIBLE

The EA101 is a standard Ethernet adapter and allows your computer to access any

Ethernet network through a USB port.

READABLE

Power, Link, and collision LEDs keep you informed of network activity.

EASY TO INSTALL

You don't even need to open up your PC—installation couldn't be simpler.

Connect to Ethernet

in a snap!

EA101

USB Ethernet Adapter

Help is there when you need it!

NETGEAR provides free, 24x7

telephone and e mail technical

support in English, with selected

local language support during

office hours.

www.NETGEAR.com

10 Mbps

NETGEAR Inc.

4500 Great America Parkway

Santa Clara, CA 95054

USA

Phone: 1-888-NETGEAR

E-mail: [email protected]

www.NETGEAR.com

In-Country Phone Support

(24x7 phone support in English, local language support during ofﬁce hours.) NETGEAR™is a trademark of

NETGEAR, Inc.Windows®is

a registered trademark of

Microsoft Corporation. Other

brand and product names are

trademarks or registered

trademarks of their respective

holders. Information is subject

to change without notice.

www.NETGEAR.com

TECHNICAL SPECIFICATIONS

Standards Compatibility

Microsoft Windows 98 compatible

IEEE 802. 3i, 10BASE-T Ethernet

Interface Options

RJ-45 connector

IRQ Options

Assigned by Plug and Play system

Power Consumption

2.0 W

Dimensions

Unit: 9.5 x 4.5 x 26 cm (3.7 x 1.8 x 1 in)

Cable: 50.8 cm (20 in)

Weight

0.14 lb (63 g)

Environmental Specifications

Operating temperature: 0 to 45ºC

Operating humidity: 10 to 90% noncondensing

Agency Compliance

CE mark, commercial

FCC, Part 15, Class B

EN 55 022 (CISPR 22), Class B

Canada ICES-003, Class B

VCCI Class B

PACKAGE CONTENTS

USB Ethernet adapter

Quick Installation Guide

10-foot Category 5 Ethernet cable

Warranty card

Support card

Power adapter

PC with network

card installed

Category 5 10/100 Mbps UTP cables*

*Use the cables provided or any Category 5 UTP cable.

Maximum length = 100 meters (300 feet)

PC with USB ports

Model EA101 USB

Ethernet Adapter

Hub

Korea 00308-11-0319

Netherlands 0800-023-0981

New Zealand 00800-1233-4566

Norway 800-12041

Singapore 001-800-1233-4566

Sweden 0200-298-298

Switzerland 00800-0638-4327

(00800-0-NETGEAR)

United Kingdom 020-7216-0014

United States 1-888-NETGEAR

All Other Countries +1 801-236-8499

Australia 1800-787-638

Austria 00800-06384327

(00800-0-NETGEAR)

Denmark 808-82179

Canada 1-888-NETGEAR

Finland 0800-111-036

France 0800-77-17-53

Germany 00800-06384327

(00800-0-NETGEAR)

Hong Kong 001-800-1233-4566

Japan 0120-66-5402

D-EA101-001

•

ISO-9001

REGISTERED

QUALITY

LISTED

ITE

E151382

4C93
