The Aurora 710 switch
installation guide
The Aurora 710 switch installation guide
iii
Table of Contents
1. Introduction ........................................................................................................................ 1
2. Hardware Installation .......................................................................................................... 2
2.1. Installation Guidelines .............................................................................................. 3
2.2. Installation using the Rubber Feet ............................................................................ 4
2.3. Installation into a Rack ............................................................................................ 5
2.4. Installing Transceivers and cables into the Switch Ports ............................................ 7
2.4.1. SFP+/SFP28 Port Connection (LC Type Connector) ....................................... 7
2.4.2. QSFP+/QSFP28 Port Connection .................................................................. 8
2.5. Fan Modules ........................................................................................................... 9
2.6. Power supply ........................................................................................................ 11
2.6.1. Replacing a PSU ........................................................................................ 11
2.7. Connect the Power Cable ...................................................................................... 13
2.8. Grounding the Switch ............................................................................................ 14
2.9. Rack-mount Safety Precautions ............................................................................. 15
2.10. Console port ........................................................................................................ 16
2.11. Verifying Switch Operation ................................................................................... 18
3. Netberg Aurora 720 switch ............................................................................................... 19
3.1. Specification .......................................................................................................... 21
3.2. Supported Cables and Transceivers ....................................................................... 23
iv
List of Figures
2.1. Rubber standoffs placement ............................................................................................ 4
2.2. Front brackets installation ................................................................................................ 5
2.3. Rack installation .............................................................................................................. 6
2.4. Transceivers and cables .................................................................................................. 7
2.5. Removing the fan module ................................................................................................ 9
2.6. Inserting the fan module ................................................................................................ 10
2.7. Removing the PSU module ............................................................................................ 11
2.8. Inserting the PSU module .............................................................................................. 12
3.1. Aurora 710 front view .................................................................................................... 19
3.2. Aurora 710 rear view ..................................................................................................... 20
3.3. Aurora 710 side view ..................................................................................................... 20
v
List of Tables
2.1. Console cable pin definition ........................................................................................... 16
3.1. Front panel features ...................................................................................................... 19
3.2. Rear panel features ....................................................................................................... 20
3.3. Side panel features ....................................................................................................... 20
1
Chapter 1. Introduction
This guide is to assist the reader with the most basic form of installation and cable connection to
our switches. As there is more than one switch in the Aurora series, the actual port placement
might slightly differ, however, the installation and connection logic are the same for all Netberg
switches.
Package Contents:
• One Netberg Aurora Switch
• Two AC power cords.
• One RS-232-to-RJ45 console cable.
• One pair of frontal rack-mount brackets.
• Four rubber feet with adhesive patches.
• Eight Phillips-head frontal rack-mount bracket screws.
If any of the above mention items was not found inside the package contents of this
switch or are damaged in any way, contact your reseller immediately.
2
Chapter 2. Hardware Installation
Hardware Installation
3
2.1. Installation Guidelines
This section will discuss the hardware installation guidelines that administrators must follow in or-
der to properly and safely install this switch into the appropriate environment.
Hardware Installation
4
2.2. Installation using the Rubber Feet
When installing the switch in an area other than inside a switch rack, like on a desktop, rubber feet
can be attached to the bottom panel of the switch. The rubber feet cushion the switch, protecting
the casing from scratches, preventing it from scratching other surfaces, and preventing it from slip-
ping.
1. Install the switch on a flat surface that can safely support its weight.
2. The adhesive material is included on the rubber feet. Pull away the protective sticker of each
rubber foot and attach them to the switch bottom.
3. Make sure that there is proper heat dissipation from and adequate ventilation around the switch.
Leave at least 15 cm (6 inches) of space at the rear and 5 cm (2 inches) at the front of the
switch for ventilation.
Figure2.1.Rubber standoffs placement
Do not place any heavy objects on the switch.
Hardware Installation
5
2.3. Installation into a Rack
The switch can be mounted in a standard 19"(1U) rack using the provided mounting brackets.
The following section will explain how to install the rack-mount brackets onto the switch and then
mount the switch into a standard 1U rack-mount unit.
1. Use the supplied screws to attach a mounting bracket to each side of the Switch.
2. Align the holes in the mounting bracket with the holes in the rack.
3. Insert and tighten screws through each of the mounting brackets.
Figure2.2.Front brackets installation
1234567891
01
11
21
31
41
51
61
71
81
92
02
52
62
72
82
93
03
13
2
2
12
22
32
4
Aurora 7 10
R
ESET
PS1
PS2
F
A
N
SYS
E1
/33 E2/34
Two individuals are recommended to install the switch. One individual should position
the switch in the rack, while the other secures it using the rack screws.
The switch can be installed directly on the rack without the use of the rail.
1. Align the built-in mounting ear to the rack holes.
2. Tighten the screws to secure the switch.
