Ness 104-464 NIP200 Manuel utilisateur

REV1.5

Full HD Anti-Vandal Dome IP Camera

104-464 NIP200

USER’S MANUAL

www.ness.com.au

electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Ness.

Ness reserves the right to make changes to features and specifications at any time without prior notification in the interest of ongoing

product development and improvement.

HEAD OFFICE:

Ness Corporation Pty Ltd

ABN 28 069 984 372

Ph +61 2 8825 9222 Fax +61 2 9674 2520

[email protected]

SYDNEY

Ph 02 8825 9222 Fax 02 9674 2520

[email protected]

MELBOURNE

Ph 03 9875 6400 Fax 03 9875 6422

[email protected]

BRISBANE

Ph 07 3399 4910 Fax 07 3217 9711

[email protected]

PERTH

Ph 08 9328 2511 Fax 08 9227 7073

[email protected]

ADELAIDE

Ph 08 8152 0000 Fax 08 8152 0100

[email protected]

www.ness.com.au

Table of Contents

1. Overview ................................................................................................................................ 2

1.1 Features ...................................................................................................................... 2

1.2 Package Contents ....................................................................................................... 3

1.3 Dimensions .................................................................................................................. 5

1.4 Connectors .................................................................................................................. 6

2. Camera Cabling ..................................................................................................................... 7

2.1 Connect Power ............................................................................................................ 7

2.2 Connect Ethernet Cable............................................................................................... 7

2.3 Connect Alarm I/O ....................................................................................................... 7

3. System Requirements........................................................................................................... 8

4. Access Camera ..................................................................................................................... 9

5. Setup Video Resolution ...................................................................................................... 13

6. Configuration Files Export/ Import .................................................................................... 14

Appendix A: Technical Specifications....................................................................................... 15

Appendix B: Delete the Existing DC Viewer .............................................................................. 19

Appendix C: Setup Internet Security ......................................................................................... 20

Appendix D: Video Resolution ................................................................................................... 21

2M- Quad Streams ................................................................................................................ 21

2M- Triple Streams................................................................................................................ 25

2M- Dual Streams ................................................................................................................. 27

2M- Single Stream ................................................................................................................ 27

2M Real time / 3M / 5M- Quad Streams ................................................................................ 28

2M Real time / 3M / 5M- Triple Streams ................................................................................ 33

2M Real time / 3M / 5M- Dual Streams .................................................................................. 36

2M Real time / 3M / 5M- Single Stream ................................................................................. 37

1. Overview

The IP Camera features decent low light performance, high resolution up to 5

Megapixel, various video resolution combination, multiple video compression

formats, etc. It also supports true day / night and 3DNR function, which display

clear images in low light conditions. Moreover, the proprietary SPQ (Smart

Picture Quality) function allows delivering quality images especially under

intensive motion and low light conditions. With the built-in IR LED module, it

makes visibility in nearly total darkness.

With H.264 High / Main / Baseline profile and MJPEG video compression

formats support, it is beneficial for optimization of bandwidth and network

resources. Video quad-stream support allows various surveillance applications

and facilitates working with other back-end devices.

1.1 Features

 Progressive Scan CMOS Sensor

 Quad Streams Compression: H.264 Baseline/ Main/ High Profile + MJPEG

 Multi-language Support

 Tampering Alarm

 Remote Zoom & Focus (Motorized Lens)*

 Wide Dynamic Range

 Motion Detection

 Privacy Masks

 Smart Picture Quality/ 3D Noise Reduction

 Vertical View Mode (Image rotation by 90 degrees)

 Smart IR Mode

 Network Failure Detection

 Day/Night (ICR)

 IR LED Module (working distance up to 25m)*

 Micro SD support

 BNC analog output

 Weatherproof (IP66 International)

 Sunshield & Pendent Mount Housing*

 ONVIF Support

(*) Optional

1.2 Package Contents

Please check the package contains the following items listed below.

Indoor Camera Package Contents

Vandal Proof

Fixed Dome IP Camera

DC Jack Cable & Power Terminal Block

Rubber Washers (×6)

Security Torx

Self Tapping Screws

(×4)

Plastic Screw Anchors

(×4)

Quick Guide

(bundled software and documentation)

Outdoor Camera Package Contents

Vandal Proof Fixed Dome IP

Camera

DC Jack Cable & Power Terminal Block

Security Torx

Hexagon Screw-M8*16 (x1)

Spring Washer (×1)

Pendant Tube Washer (×1)

Rubber Washer (×1)

(bundled software and documentation)

Quick Guide

1.3 Dimensions

The IP Dome Camera’s dimensions are shown below.

Indoor

Top View Side View

Outdoor

Top View Side View

1.4 Connectors

The diagram below shows the IP Camera’s reset button and various connectors.

Definition for each connector will be given as follows.

No.

Connector Pin

Definition Remarks

1 Reset Button - Restore to factory default

2 BNC - Analog Video Output

3 Alarm I/O

1 GND (Input－)

Alarm connection

2 Input＋

3 Output－

4 Output＋

4 Audio I/O

1 Output (L)

Two-way audio transmission

2 Output (R)

3 GND

4 Input

5 Power

DC 12V

1 Power

Power connection

2 Reserved

3 GND

AC 24V

1 Power-1

2 Earth GND

3 Power-2

6 RJ-45 - 10/100 Mbps Ethernet / PoE

2. Camera Cabling

Please follow the instructions below to complete IP Camera connection.

2.1 Connect Power

Please refer to Section: Connectors. Alternatively, connect the Ethernet cable to

the camera’s PoE port and plug the other end of the cable into a PoE switch.

NOTE: If using PoE, make sure Power Sourcing Equipment (PSE) is in

use in the network.

2.2 Connect Ethernet Cable

Use of Category 5 Ethernet cable is recommended for network connection; to

have best transmission quality, cable length shall not exceed 100 meters.

Connect one end of the Ethernet cable to the RJ-45 connector of the IP Dome

Camera, and the other end of the cable to the network switch or PC.

NOTE: In some cases, you may need use an Ethernet crossover cable

when connecting the IP Dome Camera directly to the PC.

Check the status of the link indicator and activity indicator LEDs; if the LEDs are

unlit, please check LAN connection.

Green Link Light indicates good network connection.

Orange Activity Light flashes for network activity indication.

2.3 Connect Alarm I/O

The camera equips one alarm input and one relay output for alarm application.

Refer to alarm pin definition below to connect alarm devices to the IP Camera if

needed.

PIN 1: GND (Input-)

PIN 2: Input+

PIN 3: Output-

PIN 4: Output+

3. System Requirements

To perform the IP Camera via web browser, please ensure your PC is in good

network connection, and meet system requirements as described below.

Items System Requirement

Personal Computer

1. Intel® Pentium® M, 2.16 GHz or

Intel® CoreTM2 Duo, 2.0 GHz

2. 2 GB RAM or more

Operating System Windows VISTA / Windows XP / Windows 7

Web Browser Microsoft Internet Explorer 6.0 or later

Firefox

Chrome

Safari

Network Card 10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation

Viewer ActiveX control plug-in for Microsoft IE
