Neoway N1 Manuel utilisateur
N1 Developer Suite User Guide
Version 1.1
N1 Developer Suite User Guide
Copyright © Neoway Technology Co., Ltd
i
Copyright © Neoway Technology Co., Ltd 2018. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without
prior written consent of Neoway Technology Co., Ltd.
is the trademark of Neoway Technology Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their
respective holders.
Notice
This document provides guide for users to use N1.
This document is intended for system engineers (SEs), development engineers, and test
engineers.
The information in this document is subject to change without notice due to product version
update or other reasons.
Every effort has been made in preparation of this document to ensure accuracy of the contents,
but all statements, information, and recommendations in this document do not constitute a
warranty of any kind, express or implied.
Neoway provides customers complete technical support. If you have any question, please
contact your account manager or email to the following email addresses:
Website: http://www.neoway.com
N1 Developer Suite User Guide
Copyright © Neoway Technology Co., Ltd
ii
Revision Record
Issue
Changes
Date
V1.0
Initial draft
2016-06
V1.1
Modified the test command to *#11*#
2018-03
N1 Developer Suite User Guide
Copyright © Neoway Technology Co., Ltd
iii
Contents
1 About N1 Developer Suite................................................................................................1
2 N1 Developer Suite Hardware .........................................................................................2
2.1 Front View and Interfaces .................................................................................................................... 2
2.2 Rear View............................................................................................................................................. 3
3 Testing N1 Developer Suite..............................................................................................4
3.1 Buttons and Functions.......................................................................................................................... 4
3.2 Power Supply/Power On/Power Off .................................................................................................... 5
3.2.1 Power Supply.............................................................................................................................. 5
3.2.2 Power On/Off.............................................................................................................................. 7
3.3 Function Test........................................................................................................................................ 8
3.3.1 Testing All Items ......................................................................................................................... 8
3.3.2 Testing Single Item ..................................................................................................................... 9
3.4 SIM Card............................................................................................................................................ 10
3.5 Audio Interface and Volume+/- .......................................................................................................... 11
3.6 USB/OTG Interface ........................................................................................................................... 11
3.7 Testing Interfaces ............................................................................................................................... 12
4 Material List .......................................................................................................................14
N1 Developer Suite User Guide
Copyright © Neoway Technology Co., Ltd
1
1 About N1 Developer Suite
N1 developer suite contains a series of peripheral interfaces, including main power interface, USB
interface to download programs, commissioning interface, GPIO, TF-card interface, SIM card interface,
etc. You can commission the module after connecting to the power supply and USB cable. For information
about how to update the module, refer to the module upgrade guide.
N1 Developer Suite User Guide
Copyright © Neoway Technology Co., Ltd
2
2 N1 Developer Suite Hardware
2.1 Front View and Interfaces
1
2
3
4
5
6
7
8
9
10
12
13
14
11
18
19
20
21
15
16
17
22
23
24
25
26
27
28
29
N1 Developer Suite User Guide
Copyright © Neoway Technology Co., Ltd
3
1. N1 module
2. DC power supply interface
3. Battery interface
4. Power supply switch
5. USB interface
6. SIM_2
7. SIM_1
8. TF connector
9. MIC
10. LCD screen
11. Three-axis accelerometer
12. Three-axis magnetometer
13. Six-axis gyroscope
14. Proximity sensor
15. Front camera
16. Main camera
17. Flash
18. Wi-Fi/BT antenna
connector
19. Main antenna connector
20. GPS antenna connector
21. Sub antenna connector
22. UART2
23. UART1
24. Headset interface
25. SPEAKER interface
26. Receiver interface
27. Motor
28. Button
29. Power indicator
2.2 Rear View
1. LCD screen interface
2. TP panel interface
3. Front camera interface
1
2
3
N1 Developer Suite User Guide
Copyright © Neoway Technology Co., Ltd
4
3 Testing N1 Developer Suite
3.1 Buttons and Functions
Figure 3-1 Buttons
The functions of these buttons are described as follows:
Menu button
After the N1 developer suite is powered up, press this button to display the menu.
Home button
After the N1 developer suite is powered up, press this button to return to home screen.
Return button
After the N1 developer suite is powered up, press this button to return to upper directory.
Fastboot button
Power up the N1 developer suite, hold this button, and then connect the suite to a computer through a
USB cable. The module enters forcible download mode.
If this button is pressed after the suite is powered up and started, the N1 module will not enter forcible
download mode.
PWRKEY
After powering up the N1 developer suite, hold this button for 2 seconds, and the N1 module will be
started.
Hold this button for 2 seconds after the N1 developer suite is started, and the N1 module will display
the power off screen. Tap power off to switch off the module.
Reset
Hold this button for 2 seconds, and the N1 module will restart.
1
2
3
4
5
6
7
8
N1 Developer Suite User Guide
Copyright © Neoway Technology Co., Ltd
5
Vol+
After the N1 developer suite is powered up, press this button to increase the volume.
Vol-
After the N1 developer suite is powered up, press this button to decrease the volume.
3.2 Power Supply/Power On/Power Off
3.2.1 Power Supply
The module can be powered by external DC power or battery.
External DC Power Supply
Step 1 Connect the power supply to "2. DC power supply interface."
Step 2 Switch "4. Power supply switch" to DC.
The LED indicator will be on after the power supply is given to the module properly.
Battery
3.5 V to 4.2 V li-ion battery is recommended.
The demo board reserves 4 pins: ID, THERM, GND, and VBATT respectively from the top to the bottom.
N1 Developer Suite User Guide
Copyright © Neoway Technology Co., Ltd
6
Step 1 Connect the battery to "3. Battery interface".
Do not connect the battery to UART1 or UART2. Otherwise, the module will be damaged.
Step 2 Switch "4. Power supply switch" to BATT.
The LED indicator will turn on after the battery connected properly.
