Neotel NeoFlex Data Manuel utilisateur
www.neotel.co.za Call 0800 333 636
NeoFlex Data
Wi-Fi guide
page 2
Table of contents:
1) Security Warning and Disclaimer
2) Connecting the NeoFlex device to your computer
3) Switching the wireless LAN on
4) Enabling your security settings
5) Connecting via Windows XP
6) Connecting via Windows Vista
page 3
WiFi DISCLAIMER
SECURITY WARNING AND DISCLAIMER
WARNING:
The user is hereby notified that the security settings accompanying the device must be enabled/activated in conjunction
with the use of the Wi-Fi feature of the service, to prevent unauthorised usage by any 3rd party.
In the event that the user does not activate or enable the security settings, then the service becomes vulnerable to
security breaches and unauthorised usage, which cannot be controlled by the service provider, thereby placing the
personal information of the user at risk.
In order to avoid or prevent the risk stated above, the user is required to follow the instructions in the NeoFlex Data
Wi-Fi Guide, to successfully enable the use of the secure Wi-Fi feature associated with the service.
DISCLAIMER:
Neotel cannot and does not guarantee the privacy and integrity of the user’s data and communication whilst this
feature is activated. The user accordingly acknowledges the risk of using the feature and accessing the Internet over
the unsecured feature.
Before proceeding with installation, please ensure that your pop-up blocker is switched off in order to allow
for pop-ups.
Next page
Back to contents page
page 4
Connecting the NeoFlex device to your computer
1) Make sure that the device is switched off.
2) Set the selector switch to the right. 4) Connect the other end of the Ethernet cable into your
computer. Switch the Device on.
5) Your computer will now be assigned an address
from the device and you will be able to connect
to the Internet.
3) Connect the Ethernet cable (looks like a big phone jack) to the
front of the device, you should hear it click when in properly.
Back
Back to contents page
Next
page 5
1) Open your Internet browser, e.g. Internet Explorer. 2) Enter the address 192.168.0.1 into the address bar,
the same place you would normally enter any
website address, e.g. www.neotel.co.za
Connecting the NeoFlex device to your computer: Switching the wireless LAN on
Back
Back to contents page
Next
page 6
3) The following dialog box will now appear:
Connecting the NeoFlex device to your computer
Back
Back to contents page
Next
page 7
4) Enter the User name as admin.
5) Enter the Password as admin.
6) Click on the OK Button.
Connecting the NeoFlex device to your computer
Back
Back to contents page
Next
page 8
7) The following page will now be displayed in your web browser.
Connecting the NeoFlex device to your computer
Please turn over the page ☞
Back
Back to contents page
Next
page 9
8) On the left hand side of the screen you will see the following menu:
9) Under the Advanced heading click on wireless settings.
Connecting the NeoFlex device to your computer
Back
Back to contents page
Next
page 10
10) You will now be presented with the following screen:
Connecting the NeoFlex device to your computer
Please turn over the page ☞
Back
Back to contents page
Next
