Neilsen CT2213 Guide de planification
250LB TOW BEHIND SPREADER CT2213
ASSEMBLY AND OPERATING INSTRUCTION
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety and
health requirements of the EC Directive based on its design and type, as brought
into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration will
lose its validity.
Product description: TWO-BEHIND SPREADER
Model: CT2213
Applicable EC Directives:
EC Machinery Directive 2006/42/EC
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2016-01-18
3
2. Remove and identify loose parts from carton and bag.
1. SAFETY RULES
READ THE DIRECTIONS BEFORE ASSEMBLY
zRead the towing vehicle owners manual and towing vehicle safety rules. Know how to
operate your tractor before using the tow-behind spreader.
zRead the chemical label instructions and cautions for handling and applying the
chemicals purchased for spreading.
zWear eye and hand protection when handling and when applying lawn or garden
chemicals.
zNever operate tractor and spreader attachment without wearing substantial footwear,
and do not allow anyone to ride or sit on spreader attachment frame.
zNever allow children to operate the tractor or spreader attachment, and do not allow
adults to operate without proper instructions.
zAlways begin with the transmission in first (low) gear and with the engine at low speed,
and gradually increase speed as conditions permit.
zWhen towing spreader do not drive too close to a creek or ditch and be alert for holes
and other hazards which could cause you to loose control of the spreader and tractor.
zBefore operating vehicle on any grade (hill) refer to the safety rules in the vehicle
owner’s manual concerning safe operation on slopes. Stay off steep slopes!
4
ASSEMBLY INSTRUCTION
STEP 1: Attach the first Flat Washer Ø20, Bushing, the second Flat Washer Ø20,the third Flat Washer
Ø20 onto the end of wheel axle of Mounting Tube in turn. Then insert the Cotter Pin Ø4x40 into the small
hole on the wheel axle and bend to fix it.
5
STEP 2: Assembly the another wheel to the other side of Wheel Axle, operation same as step 1. Rotating
the wheel so that the hole on the inside of wheel align with the hole on the end of axle, then insert the
Drive Pin Ø6x45 and lock it.
STEP 3: Insert Hex Bolt M6x50 after aligning the hole at the flat end of Hitch Tongue (stay on top) with the
one at the middle of crossover tube. Connect it by using Big Flat Washer Ø6 and Nylon Lock Nut M6 and
don’t screw it up moderately.
6
STEP 4: Attach two Braces (each at one side) to the middle of Hitch Tongue by using Hex Bolt M6x45 and
Nylon Lock Nut M6, don't screw them up temporarily.
STEP 5: Attach the Gauge & Lever Ass’y to the middle of Hitch Tongue using 2pcs Hex Bolts M8x45 and
Nylon Lock Nuts M8.
7
STEP 6: 1. Attach two Braces (each at one side) to the middle of Support Rod by using Hex Bolt M6x45
and Nylon Lock Nut M6, don't screw them up temporarily.
2. Connect another end of two Braces at each side of Hitch Tongue with the hole in horizontal direction at the
round part of Mounting Tube by using Hex Bolt M6x35 and Nylon Lock Nut M6.
3. Now tighten all bolts and nuts.
STEP 7: 1. Insert the head of Axle on Frame Tube Assembly into the Swivel Bushing at the bottom of
Hopper Assembly.
2. Aligning all the six holes around Hopper Assembly and the six holes on the Frame by using six Hex Bolts
M6x50, Big Flat Washer Ø 6 on the top and six Nylon Lock Nuts M6. Adjust parts of the Hoper Assembly to
make the axle to be able to twirl freely and then screw all the Nylon Nut M6.
3. Insert the R Pin Ø3x75 into the hole on top of Swivel Axle.
8
STEP 8: Install one Flat Washer Ø8 at one end of Adjust Connection Rod and then insert into the hole of Rod
Base, connect them by using a Nylon Lock Nut M8.
STEP 9: Attach the support rod into the hole on the Hopper by using Hex Bolts M6x20, Big Flat Washers Ø6
and Nylon Lock Nuts M6.
STEP 10: Attach the Hopper Screen to the bottom of Hopper.
9
STEP 11: Connect Hitch Bracket to Hitch Tongue, the hole on the Hitch Bracket align at the hole on the
Hitch Tongue, using the Drive Pin Ø9x60. The Length of Hitch Tongue can be adjustable.
Your Spreader is now fully assembled and ready for use.
10
PARTS DRAWING
