ANPR LUMO | QUICK REFERENCE GUIDE
2/6
SAFETY PRECAUTIONS
The following safety precautions must be observed during normal use, service and repair.
The ANPR shall be connected to safety ground.
Disconnect the power supply before removing any parts.
The ANPR shall only be installed and serviced by qualified and trained personnel.
To be sure of safety, do not modify or add anything other than mentioned in this manual or indicated by
NEDAP N.V.
CAUTION: for continued protection against risk of fire, replace fuses only with the same type and rating.
The ANPR can be powered from a low power, Class 2 power supply, in compliance with local regulations
or through POE.
The product is to be connected only to PoE networks without routing to the outside plant.
The ANPR is equipped with an InfraRed illuminator. The human eye will not or slightly see this light
coming from the illuminator. Do not look into the ANPR lens directly from close range or for more than
100 seconds. Eyes can be damaged by not taking these precautions. During normal use of the ANPR at a
vehicle gate, reading plates, there is no risk to the public.
MOUNTING THE ANPR
Determine how to mount the ANPR, onto a pole or behind the barrier. Mount behind the barrier to ensure
recognition right in front of the barrier. Important mounting instructions are:
Best operating distance is between 2 to 8 meters.
Angle between ANPR and number plate should be smaller than 25 degrees.
Pole mounting
The ANPR is positioned directly behind or in front of
the actual barrier onto a pole. Recommended
installation height is 2m20. In this position license
plates directly in front of the barrier cannot be read.
When overhead installation is an option, the ANPR can
at best be installed in the center of the lane, above
the lane.
Behind barrier mounting
The ANPR is positioned behind the barrier at bumper
height.
If there is space behind the barrier and the sight is not
blocked, then the best place for the ANPR is at bumper
height (0.5m height) about 1 to 2 meters behind the
barrier. A vehicle just in front of the barrier is still
recognized in that case.
