NEC Univerge SV8100 Manuel utilisateur

Notice

Note that when converting this document from its original format to a

.pdf file, some minor font and format changes may occur. When

viewing and printing this document, we cannot guarantee that your

specific PC or printer will support all of the fonts or graphics.

Therefore, when you view the document, fonts may be substituted and

your individual printer may not have the capability to print the

document correctly.

User’s Guide

INT-2084

Issue 1.0

License Manager Server

NEC Unified Solutions, Inc. reserves the right to change the specifications, functions, or features at

any time without notice.

NEC Unified Solutions, Inc. has prepared this document for use by its employees and customers. The

information contained herein is the property of NEC Unified Solutions, Inc. and shall not be reproduced

without prior written approval of NEC Unified Solutions, Inc.

UNIVERGE®is a trademark of NEC Corporation. Pentium®is a trademark or registered trademark of

Intel Corporation or its subsidiaries in the United States and other countries. Windows®is a registered

trademark of Microsoft Corporation.

NEC Infrontia, Inc.

6535 N. State Highway 161

Irving, TX 75039-2402

Technology Development

User Guide i

___________________________________________________________________________________

TABLE OF CONTENTS

Section 1.0 Introduction ..........................................................................................1

Section 2.0 60 Day Trial .......................................................................................... 1

Section 3.0 Licensable Items .................................................................................. 2

3.1 System Port Licenses and MEMDB Rules ....................................................... 2

3.2 VOIP Licenses .................................................................................................. 3

3.3 SMDR License .................................................................................................. 4

3.4 CTI License ...................................................................................................... 4

3.5 ACD License ..................................................................................................... 4

3.6 Hotel / Motel / LMS License .............................................................................. 4

3.7 InMail Voicemail License .................................................................................. 5

3.8 Networking License .......................................................................................... 5

Section 4.0 Using the LMS ...................................................................................... 5

4.1 Dealer/ Associate Admin .................................................................................. 5

4.2 Dealer/ Associate Tech .................................................................................... 6

4.3 Login to the LMS System ................................................................................. 7

4.4 Notification When a License is Generated ....................................................... 9

4.5 Adding a Customer and Hardware Key .......................................................... 10

4.6 License Administration ................................................................................... 13

4.7 Attaching Licenses to Customer Locations .................................................... 14

4.8 Assigning a License Using the License / Administration Menu ...................... 14

4.9 Assigning a License Using the Registration / License Registration Menu ...... 20

Section 5.0 Installing a License ........................................................................... 24

5.1 Using PCPro ................................................................................................... 24

5.2 Using WebPro ................................................................................................ 27

5.3 Using a USB Memory Stick ............................................................................ 30

5.4 By Entering the Code Manually ...................................................................... 30

___________________________________________________________________________________

ii Table of Contents

___________________________________________________________________________________

Issue 1.0 License Manager Server

THIS PAGE INTENTIONALLY LEFT BLANK

User Guide 1 - 1

___________________________________________________________________________________

License Management Server

SECTION 1.0 INTRODUCTION

This manual is intended to give an overview on how the licensing procedure operates

on the SV8100 platform. Some features and hardware require an appropriate license

to be installed on a SV8100 processor to work. Each SV8100 CCPU has a unique

Hardware Key that is generated by NEC Infrontia. Software Key Codes can be

downloaded from the License Manager Server (LMS) and assigned to a hardware

key.

The LMS is a web portal where users can login and download a license that can be

installed on a CCPU. The procedure involves logging the hardware key on to the

LMS, and then assigning a software key to the hardware key. After this is done, a

license file can be downloaded and installed on a CCPU blade using PC Pro or a USB

Stick.

SECTION 2.0 60 DAY TRIAL

The 60 day trial should only be used when it is not possible to install a real license

that would have been downloaded from the LMS. If the 60 day trial expires without a

real license being installed, the SV8100 operates using only unlicensed features. By

default the trial is turned Off and can be turned on or off only by using Telepro. Set

Program 90-55-01 to 1 to enable or 0 to disable the trial.

The 60 day trial gives full access to all PBX features for its duration. External

applications do not operate under the trial license, but some of the applications may

have their own trial license that can be used.

The trial rules for the trial are provided below:

The 60 day demo starts when the system is powered on. The option to enable or disable

this feature is available in Data Program 90-55-01 (1=Enable and 0=Disable).

When the CCPU is powered down and left off, the timer stops, and starts counting

again when it is powered on.

To determine the number of days left for the trial, set Program 90-55-01 to 1 and check

Program 10-52-01.

1 - 2 User Guide

___________________________________________________________________________________

Issue 1.0 License Manager Server

If a license has not been installed on the SV8100, and the trial license is turned on and

then off, the days remaining continues to decrease.

After a license is installed on the SV8100, you should set Program 90-55-01 to 0 to turn

off the trial license. This preserves the remaining days left on the trial license and allows

you to turn it back on if needed at a later date.

Program 90-55-01 is currently only available using keyset programming. PC Programming/

Web Pro cannot be used.

When you turn off the free license, registered license devices (e.g., IP Terminals) that are in

use restart.

This Data Program is supported with SV8100 software version 3.0 or higher.

SECTION 3.0 LICENSABLE ITEMS

All of the licensing options can be broken down into different categories. Some

licenses (e.g., SMDR) have a quantity of 1 to turn them on, while others have a

quantity depending on the number of devices that are used. For example, you may

have a license for 20 IP Terminals, in this scenario a license for 20 IP Terminals

would be issued. If you were to purchase SMDR then 1 license would be issued to

turn on SMDR.

References in this manual are made to the license code. License codes (four digits in

length) are the actual codes that are recognized by the SV8100.

Where NetLink is used, a license should be applied only to the Primary Netlink

system. A license should be purchased for each remote NetLink node. If the NetLink

between a primary system and a secondary system goes down, the secondary

system uses an internal license for a period of seven days. If the NetLink connection

to the primary system is not resumed after seven days, the internal license stops

working and the system becomes unlicensed.

3.1 System Port Licenses and MEMDB Rules

System capacity licenses are required for TDM extensions and trunks. The

capacity of the SV8100 depends on whether or not a MEMDB is installed.

If MEMDB is not installed, the system capacity is 64 TDM extension and

trunks. If Inmail is used, eight ports are assigned as voicemail ports. These

ports are TDM and reduce the number of ports in the system from 64 to 56.

When the SV8100 system is powered on, the 60 day demo trial

starts and will count down 60 contiguous days. Disabling

Program 90-55-01 will not deter the countdown progress
