NEC Express5800/A1160



The NEC Express5800/A1160 enterprise server is developed from

a long heritage in both supercomputer- and mainframe-class

computing. Specically created from the ground up around the new

7400 family of Intel multi-core (Dunnington) Xeon processors, NEC’s

Express5800/A1160 unleashes exceptional performance within a

very compact, modular, power efcient, and scalable design.

Leveraging a rich heritage in mission

critical computing, NEC delivers a new

product line specically tuned for new

6-core Intel® Xeon® processors.

Page 2

Features



» Intel 7400 Series Xeon® CPUs

» Integrated Scalability Port

» Expandable PCIe Hot-swap I/O



» Hardware Error Logging

» Integrated RAS Memory

» Internal RAID Storage



» Front & Rear Access Design

» Advanced Monitoring

» Hot Replaceable Sub-systems

Benets



» Excellent System & Virtual Machine Performance per Watt

» Incremental Growth

» State-of-the-art I/O



» Proactive Service Alerts

» Memory Integrity

» Internal Storage Resilience



» Convenient Serviceability

» Quick Problem Resolution

» Investment Protection

Available in 4-core and 6-core per processor socket options,

Intel’s 7400 Series CPUs deliver superior performance compared

to previous generation quad-core Xeon processors. In addition,

reduced power consumption per CPU core provides added benets

for energy-conscious IT managers.

NEC’s A1160, aka Monster Xeon® Server, system architecture features

an efciently scalable, highly reliable, and easily serviceable solution

perfect for system consolidation, virtualization deployments, and

enterprise database applications. Each complete A1160 system

can scale from 1-node, 4-sockets, 16-cores, and 4 GB memory, to

4-nodes, 16-sockets, and 96-cores and 1TB memory*1.



1,5685800/A1160



2008

$1,180.01

4



2008

2008



3-10



World Class SQL Server® Platform Performance

NEC Corporation announced that it is the rst computer company to publish and exceed 1,500 tpsE (transaction per second)

benchmark performance results as measured the industry standard TPC-E benchmark.*2

Page 3

Power Efcient Consolidation

NEC A1160 Enterprise Servers are designed to support

advanced virtualization environments such as Microsoft’s®

newly released Hyper-V, VMware’s® ESX Server and Citrix

virtualization software. Compared to existing quad-core

Intel 7350 CPUs, new 7400 series CPUs provide up to 38% faster

Virtual Machine (VM) response, up to 40% more VM workload

capacity, and up to 50% better VM performance per watt*5. As a

result, NEC Expess5800/A1160 servers are an excellent platform to

implement virtualization driven system consolidation strategies.

Easy Scalability

In combination with its monster-sized congurability, whether

one node or four nodes, the entire conguration can appear as

one large system to system applications. For additional exibility,

each node can be logically partitioned in order to support

efcient application stacking with the benet of a single system

management umbrella.

Extreme Modularity

For convenient in-rack serviceability, NEC Express5800/A1160

Enterprise Server sub-system components (e.g., CPU, memory,

and I/O) are front and rear accessible. Additionally, all subsystem

components utilize quick insertion connectors — no tools required.

This advanced modular design allows for fast system service

without removal of the base chassis from the rack and without

heavy lifting. 4-Sockets

24-Cores

8-Sockets

48-Cores

12-Sockets

72-Cores



(1) 1 TB memory feature available Q1 2009.

(2) TPC-E is a new-generation industry-standard benchmark that is designed to

be broadly representative of modern OLTP systems. The benchmark simulates a

brokerage rm with customers, accounts and holdings, where customers trade

stocks and monitor their accounts and the market.

(3) Benchmarked system model available in North America. A three node, 12 socket

conguration was used for this benchmark.

(4) Source: Transaction Processing Performance Council (TPC). http://www.tpc.org.

As reported March 18, 2009, NEC Express 5800/A1160, 1,568.22 tpsE @ $1180.01 USD/

tpsE. System availability date is immediate, March 18, 2009 and is for North American

market only.

(5) Relative virtual machine performance data provided by Intel Corp..

CPU Boards

FRONT

Memory

DIMMS

Fans LCD Panel

BACK

Scalablity Ports

Redundant

Power Supplies

PCle Slots

Disk Drive Bays

16-Sockets

96-Cores

NEC Corporation of America

2880 Scott Blvd.

Santa Clara, CA 95050

Enterprise@necam.com

1 866 632-3226 (International +1 408 844-1299)

www.necam.com/Servers/Enterprise

subjected to change without notice. NEC and Empowered by Innovation are

registered trademarks of NEC Corporation. All other trademarks are the property

of their respective owners. (BR123-2 _0409)

Specications

Standard Express5800/A1160 features enable enterprise-class reliability, availability, and serviceability.

Description Specications

CPU Processor Intel Xeon X7460 Intel Xeon E7440

Frequency 2.66 GHz 2.40 GHz

Core Count 6 Cores 4 Cores

L2 Cache 3 MB per core pair (9 MB) 3 MB per core pair (6 MB)

L3 Cache 16 MB 16 MB

Memory DIMM Type FB-DIMM 667 MHz

Min./Max. 4 GB / 1 TB1

Slots per node 32 slots per node

Slots per 4 node system 128 slots maximum

I/O PCI Type PCI Express x8

Slots per node 6 (Hot-plug capable)

Slots per 4 node system 24 (Hot-plug capable)

Storage Internal HDD type SAS SFF 2.5 HDD (Hot-swap)

Drive options 73 GB 15,000 RPM / 146 GB 10,000 RPM

Slots per node 6

Slots per 4 node system 24

RAID options RAID levels 0 / 1 / 5 / 10 / 50 (excl. Linux); RAID Level 1 (w/Linux)

System Scalability Integrated scalability port included standard with base system. Please note, high-speed interconnect cable not included with

base system.

Integrated Network Interface 2 port 1000BASE-T

Peripheral Devices DVD-R/W standard (Optional external USB Floppy Disk Drive)

External Interfaces VGA, USB x 4, Serial x 1, 1000BASE-T x 2

Service Processors 1 Integrated into each module / 10 / 100BASE-T Connection xv

Hotswap Components Power supplies, fans, memory (w/memory mirroring), HDDs (w/RAID 1 or higher) and PCI-Express (w/Windows only)

Power Supply Rating Max 1,425 W - 220V (redundant power supplies)

Form Factor 4U Rack mount per node

Weight Min./Max. 81.9 lbs (37.22 kg) / 97 lbs (44kg) per node

System Management NEC ESMPro System Manager, NEC Utility CD

Operating Systems Windows Server 2003 R2, Enterprise Edition (x86 & x64, SP2 or later)

Windows Server 2003 R2, Datacenter Edition (x86 & x64 SP2 or later)

Windows Server 2008 Enterprise (x64)

Windows Server 2008 Datacenter (x64)

Red Hat Enterprise Linux 5 (EM64T), Citrix Xen Server 5.02

VMware ESX Server 3.5, Microsoft Windows Server 2008 Hyper-V*

Warranty 3-Year Limited Warranty

1 1 TB memory feature available Q1 2009.

2 Citrix Xen Server certication pending.

* Available 1H 2009.
