NEC NP09CM Mode d’emploi

Portable Projector

NP09CM Ceiling Mount Unit

Installation and Adjustment Manual

Thank you for your purchase of the NEC portable projector ceiling mount unit.

Please read this installation and adjustment manual carefully to ensure proper use.

Special skills are required for the installation of the portable projector.

This work should never be performed by the customer.

To the Dealer and the Installer

For the safety of the customer, we ask that the installation work be started

after careful attention is paid to the strength of the mounting location to be

sure it will withstand the weight of the portable projector and mounting

hardware.

Printed in Japan

NP09CM-0801K-01

CONTENTS

Heed the Following ....................................................................................2

Preparation ..................................................................................................4

List of Packaged Parts ......................................................................................4

Required Tools...................................................................................................4

Names of the Parts ............................................................................................4

Dimensions ........................................................................................................5

Guide to Screen Size and Projector Mounting Position..........................6

Screen Size and Projection Distance (NP200/NP100) ....................................6

Screen Size Conversion Table (NP200/NP100) ...............................................7

Mounting the Projector...............................................................................8

Replacing the Lamp ..................................................................................11

Adjustment of the Projection Angle ........................................................12

Distortion Adjustment .....................................................................................12

Fine Adjustment...............................................................................................14

Specifications............................................................................................14

PRINTED WITH

SOY INK

Printed on recycled paper.

NP09CME08.2.155:37PMページ1

Heed the Following

•When installing the projector, be sure to

do so as explained in this manual. The

projector may fall and cause injury if it is

installed improperly.

•To prevent the projector from falling, install

it in a place and fasten it in a way with

sufficient strength to support the combined

weight (3.6 kg) of the projector (2.1 kg)

and the ceiling mount unit (1.5 kg) for an

extended period of time as well as to

withstand earthquakes. Insufficient

strength or fastening may result in the

projector falling and causing injury.

•To ensure safety, be sure to tighten the

bolts and screws securely. Also be sure to

use the included units and other metal

fittings. Failure to do so may result in the

projector falling and causing injury.

•When sliding the opening of the mounting

adapter over the pin of the ceiling

attachment unit, check that the pin of the

ceiling attachment unit is fully seated in

the opening. If not, the projector may fall

and cause injury.

•Do not modify any parts. Doing so may

result in the projector falling and causing

injury.

WARNING

•Do not use broken parts. Doing so may

result in the projector falling and causing

injury. If a part should be broken, consult

your dealer.

•Do not look into the lens when the

projector is turned on. Doing so could

damage your eyesight.

•Make adjustments as described in this

manual.

Incorrect adjustments may result in the

projector falling and causing injury.

This symbol alerts the user that important information concerning the

operation and maintenance of this unit has been provided. The

information should be read carefully to avoid problems.

NP09CME08.2.155:37PMページ2

CAUTION

•Do not obstruct the projector's ventilation

holes. Doing so will prevent the dissipation

of heat and may result in fires. In

particular, do not use the projector in the

following ways:

Do not install the projector in a wall or in a

tight place where ventilation is poor, place

a cover it, etc.

•Do not install the projector in front of the

outlets of an air conditioner or heater or in

a place where vibrations are strong.

Doing so may result in fires.

•Do not install the projector in humid or

dusty places or exposed to smoke or

steam (such as near cooking equipment or

humidifiers). Doing so may result in fires.

•When installing the projector, leave

sufficient space between it and

surrounding objects. Failure to leave

sufficient space will prevent the dissipation

of heat and may result in fires.

•When removing the screws on left and

right on the mounting adapter, be sure to

support the projector while doing so.

Failing to do so may result in the projector

swinging back abruptly and causing injury.

•for PLUGGABLE EQUIPMENT, the

socket-outlet shall be installed near the

equipment and shall be easily accessible.

Installation Precautions

•Special techniques are required for the

installation work of the projector and

installation work should only be

undertaken by qualified and licenced

installers.

•NEC Display Solutions will not accept any

responsibility related to any accidents or

incidents due to insufficient or inferior

mounting techniques.

Installation Location

Avoid places of high temperature or low

temperature.

(For ambient operating temperature, see the

user's manual included with the projector.)

Avoid places exposed to direct sunlight and

the vicinity of ventilation holes of room air

conditioning and heating.

Avoid rooms with a lot of dust, humidity,

greasy smoke, or tobacco smoke.

Dirt will adhere to optical parts such as

lenses and mirrors and this will cause a

deterioration of image quality.

Avoid places in which the screen is exposed

to direct sunlight or illumination light.

When surrounding light directly hits the

screen, the image appears washed out and

is difficult to view.

Heed the Following

NP09CME08.2.155:37PMページ3

Preparation

Required Tools

Phillips screwdriver

●

●●

●

Inclination axis screws

Left-right angle

adjustment screws

Inclination adjustment screws Up-down angle adjustment screws

List of Packaged Parts

Names of the Parts

Installation and adjustment manual ..........1

Up-down angle adjustment screws (M5 ) ...4

Projector mounting screws (M 3)...3

Projector mounting adapter ...1

Fixed ceiling part ...1

Projector mounting

adapter

Fixed ceiling part

NP09CME08.2.155:37PMページ4

Preparation

Dimensions

(Unit: mm)

Fixed Ceiling Part Bolt Hole Position Dimensions

Fixed Ceiling Part and Lens Center Dimensions Diagram

Center line of fixed ceiling part

Lens center/Center line of fixed ceiling part

138.9

42.2

180

85.5

210

271.8

90.4

120

150

104

Distance to lens end

Lens center

NP09CME08.2.155:37PMページ5

Zoom adjustment range

012345678910 12(m)

100

120

150

180

200

240

300

Wide angle (Maximum)

Telephoto (Maximum)

Guide to Screen Size and Projector Mounting Position

Screen Size and Projection Distance··· (NP200/NP100)

Use this guide when considering the distance to the screen and the screen size.

• The ceiling mount unit can be adjusted up and down a maximum of +/-10˚, but if too much

of an angle is taken the image will show some distortion. Therefore, it is recommended that

an adjustment is made in conjunction with the screen projection angle.

•Recommended screen sizes for projectors are from 30 inches to 300 inches. (Screen sizes

represent the diagonal dimension.)

(*1) Distance from center of fixed ceiling part to end of main unit lens.

(*2) Distance of lens center from ceiling mount surface of fixed ceiling part.

(*3) The angle is 12.8˚using a telephoto setting for distances from lens center (horizontal) to screen center.

(*4) The angle is 14˚using a wide angle setting for distances from lens center (horizontal) to screen center.

Using the Diagrams

Referring to the diagram, screen sizes that can be used at a projection distance of 3 m will range from 69

inches to 77 inches.

To project to a screen size of 200 inches, the projection distance will range from 7.9 m to 8.7 according

to the diagram.

See Page 8 for the vertical and horizontal dimensions of the screen size.

The projection distance is a calculated value and as such,

there is a tolerance of +/- 5%.

Projection Distance

Diagonal Screen Size (Inches)

Projection Height from Lens Center

(*1)

(*2)

138.9mm

90.4mm

012345678910 11 12(m)

(*4) (*3)

Wide angle

Telephoto

NP09CME08.2.155:37PMページ6

Guide to Screen Size and Projector Mounting Position

(Inches)

(m)

0.5

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0m

100

120

150

180

200

240

270

300

Screen Size Conversion Table··· (NP200/NP100)

Using the Table

The dimensions of a 100 inch screen size according to the table will be approximately 2.03 m

horizontally and approximately 1.52 m vertically.

NP09CME08.2.155:37PMページ7

Mounting the Projector

Attach the Fixed Ceiling Part to the Ceiling

First, partially tighten the four screws, then tighten the screws

firmly after positioning.

Use M8 bolts for the fixed ceiling part.

Use of types other than M8 could

cause the projector to fall.

WARNING!

Fixed ceiling part

2Attach the Projector Mounting

Adapter to the Projector

Use three M3 screws to mount the

projector mounting adapter.

Be careful not to catch your fingers

when opening or closing the

projector mounting adapter.

Please use the specified screws;

use of screws other than those

specified may damage the projector.

WARNING!

NP09CME08.2.155:37PMページ8

Mounting the Projector

Suspend the Projector from the Fixed Ceiling Part

Slide the slotted part of the projector mounting adapter over the pin of the fixed ceiling

part and push all the way to the back.

The projector is temporarily suspended in this condition and attention must be paid so

that the unit does not fall since it is not fixed in place.

Slotted part of mounting adapter

Pin of fixed ceiling part

Temporarily Fasten the Projector Mounting Adapter

Temporarily fasten by partially tightening the four supplied (M5) screws.

Tighten firmly after completing the screen projection angle adjustment.

Temporarily fasten the other side too.

NP09CME08.2.155:37PMページ9

Mounting the Projector

NOTE : Mounting boards, M8-type anchor nuts, bolts, nuts and washers are commercially

available.

Mounting board

(Strong enough to support the weight of the whole unit.)

Nut and washer

Beam

Nut and washer

Bolt (M8)

Anchor nut (Purchase commercially-available M8-type anchor nuts

that are strong enough to endure the weight of the whole unit.)

Ceiling

Bolt (M8)

Nut and washer

■When the Ceiling is Wood Construction:

■When the Ceiling is Concrete Construction:

Installation Examples

NP09CME08.2.155:37PMページ10

Table des matières

Autres manuels NEC Projecteur

NEC

NEC NC900C Manuel utilisateur

NEC

NEC M311W Manuel utilisateur

NEC

NEC MT1065 - MultiSync XGA LCD Projector Manuel utilisateur

NEC

NEC VT800 Series Manuel utilisateur

NEC

NEC DLP CINEMA NC1600C Manuel utilisateur

NEC

NEC NP600 Series Manuel utilisateur

NEC

NEC NP500WS Manuel utilisateur

NEC

NEC M230X Manuel utilisateur

NEC

NEC M332XS Manuel utilisateur

NEC

NEC NP600S XGA Manuel utilisateur

NEC

NEC VT48 Series Manuel utilisateur

NEC

NEC NP4001 Manuel utilisateur

NEC

NEC LT380 - MultiSync XGA LCD Projector Manuel utilisateur

NEC

NEC DLP Cinema NP-NC1402L Manuel utilisateur

NEC

NEC UM383WL Manuel utilisateur

NEC

NEC GT950 - MultiSync XGA LCD Projector Manuel utilisateur

NEC

NEC MT1065 - MultiSync XGA LCD Projector Manuel utilisateur

NEC

NEC MultiSync XG-1352 Manuel utilisateur

NEC

NEC MultiSync MT1055 Guide d'installation et d'utilisation

NEC

NEC NC1700L Manuel utilisateur

NEC

NEC GT1150 Series Manuel utilisateur

NEC

NEC VT490 Manuel utilisateur

NEC

NEC V230X Manuel utilisateur

NEC

NEC NP-UM330X Series Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur
