NEC Installation Projectors MT Series

MT1075 and MT1065

An essential element of your communication infrastructure.

The MT Series installation projectors include innovative features and technologies

from NEC’s renowned design labs.

Smart design makes set-up and use second nature.

°Automatic intelligence. The built in image sensor automatically focuses, adjusts color

tones, keystone corrects, and squares the image with the touch of a button.

°Plenty of power. AutosenseTM intuitively syncs the projector with most computer

signals and features one-touch image optimization.

°USB flexibility. Play back presentations or display images stored as .jpgs from

standard USB keys.

°Adapts for special needs. ADA508 compliant for hearing-impaired and colorblind

users supporting closed caption display and black & white menu options.

°Anything’s a screen. Project on spheres, cylinders, corner angles and more.

Multi-talented and able.

°Multiple lenses. Quickly install optional lenses that allow multiple room use

from one projector.

°Break the ANSI barrier. 4200 ANSI (MT1075) and 3400 ANSI (MT1065).

°Advanced AccuBlendTM.Ensures detailed images even when non-native

resolution sources are connected to the projector.

°Network connectivity. Communicate with the projector with or without wires

through an existing infrastructure or an on-the-fly peer-to-peer connection.

Economical and cost effective.

°Advanced power management. Meets Executive Order 13221 for efficient

operation supporting standby power consumption of <1 watt and a hard power

switch to completely shut down the projector.

°Extended lamp life. Eco-modeTM technology increases lamp life by up to 50%. An

optional long life lamp is available that doubles normal lamp life.

°Free asset management tools. Networking tools come standard.

°Security features. Enhanced multi-level security features protect your investment.

smart.

powerful.

efficient.

3D Reform

keystone control

direct source

selections

lens controls

The MT Series:

smart, powerful and efficient.

intuitive design.

The MT Series combines brains and brawn

with modern efficiency to get the job done.

°Flexible networking. Wireless or wired, the

MT Series is all about connecting.

°Monitor output. Easily connect to an external

monitor for use with a desktop computer.

Variable audio out. Control external

amplified audio through the projector.

°Input/Output panel. Connect with multiple

sources and get the kind of functionality

usually found in standard switchers.

°Quiet operation. Nearly silent at <29dB in

Super Eco-Mode.

Product/Accessories/Services

Order Code Description

MT1075 MT1075, XGA, 4200 ANSI lumens projector

MT1065 MT1065, XGA, 3400 ANSI lumens projector

MT60-10RL 1:1 Short throw lens, MT1075, MT60 Series

MT60-26ZL 2.7-4.2:1 power zoom and power focus lens,

MT1075, MT60 series

MT70LP Replacement lamp for MT1075

MT60LP Replacement lamp for MT60 series

MT60LPS Optional Extended life lamp for MT1075, MT60 Series

MT60CM Ceiling mount kit MT1075, MT60 Series

MT60TC Local transport/storage case w/wheels for MT1075,

MT60 Series

MT60ATA ATA shipping case for MT1075, MT60 Series

SWL-2100N Wireless network card

VLMPL-01 1 year limited parts and labor extension

VLMIC-01 2nd year limited InstaCare coverage

VLMIC-02 3rd year limited extended warranty plus 2nd and 3rd

year limited InstaCare coverage

VLMTC-02 For duration of the standard warranty (2 years), loaner

or repair services are available in EU countries, Japan,

and Australia (for U.S. and Canadian residents

traveling abroad).

aspect ratio

control

laser pointer °

DVI-D

with audio

15-pin

computer

with audio

speaker °

5BNC

w/audio

s-video

with RCA

audio

USB A/B

PC card

slots

video with

RCA audio

RCA

audio out

monitor

out w/audio

control

remote

3D ReformTM –enhanced keystone correction allows for

horizontal, vertical and diagonal image correction for aligned

images even when the projector is set up at an angle to the

screen. 3D Reform allows you to correct for distortions not

obtainable with ordinary horizontal and vertical keystone

correction which increases your projector placement options.

VORTEX Technology PlusTM–breakthrough image processing

technology improves white balance, color accuracy,

dynamic range and varying levels of black in an image.

Power + Intelligence = Efficiency

3D Reform Technology

auto focus

°auto wall

color

correction

°geometric

correction tool

before auto focus after auto focus

before auto wall

color correction after auto wall

color correction

spherical concave

convex corner

VORTEX color adjustments

original image after VORTEX

Technology Plus

color adjustment

original image after VORTEX

Technology Plus

white balance

correction

VORTEX white balance

Model # MT1075 MT1065

Panel Resolution 1024x768 pixels up to UXGA with Advanced AccuBlend

Lens

Power zoom and Power AUTO focus F=1.74-2.18, f=30.8-41.6mm

Brightness 4200 Normal 3400 Normal

(ANSI lumens) 3400 Eco-Mode 2700 Eco-Mode

2000 Super Eco-Mode 1900 Super Eco-Mode

Lamp life (up to) 3000H Eco-Mode, 2000H normal,

4000H Super Eco-Mode w/optional long life lamp

Image Size (diagonal) 25-500 inches

Projection Distance 2.46-68.9ft, 0.75-21m

Projection Angle TELE: 10.3 – 10.7 degree; WIDE: 13.7 – 14.4 degree

Fan Noise Normal <39; Eco-Mode <34; Super Eco-Mode <29

Inputs 1 DVI-D, 1 5-BNC, 1 RGB, 1 S-Video, 1 Video, 2 PC Card, 2 L/R RCA

Audio, 3 Stereo Mini Audio, 1 USB A, 1 Remote

Outputs 1 RGB, 1 Stereo Mini Audio, 1 L/R RCA Audio, 1 USB B,

1 9-Pin PC Control, 1 Mouse

Video Compatibility NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, PAL-60, SECAM,

HDTV: 1080p, 1080i, 720p, SDTV: 480p, 480i (w/optional cable),

Y/Cb/Cr component (w/optional cable)

Dimensions 13.15x12.72x4.53, 334x323x115mm (Not including protrusions)

Net Weight 13 lbs / 5.9 kg

monitor multiple

projectors from one

computer

transfer data from

multiple computers

via wireless

connection

project data to

multiple projectors

via wireless

connection

networking and source.

Control and monitor your conference room or

classroom. Using NEC's Dynamic Image Utility™

with an optional wireless or wired networking PC

card, asset management is available down the hall

or across the country. With the ImageXpress™

utility, it’s possible to transfer data from the

computer to the screen seamlessly or over the

company network.

NEC’s full line of projectors and plasmas

display crystal clear images every time.

cobranding area

Broadest line of product. NEC offers over 20 large screen

displays to support any application.

Crystal clear images. All NEC displays show crystal clear images

every time. Research says that NEC projectors and plasmas are

known to display the best images and NEC has earned numerous

awards and accolades for image quality and performance.

Works every time. NEC displays are rock solid. A recent market

study* from TFC Info showed NEC projectors and plasmas are

known to have among the highest quality in the industry.

All NEC projectors and plasmas are backed by industry leading

service and support programs. NEC is a leader in product

quality/reliability, after-sales support and return/repair programs

as reported in the 2003 Pacific Media Reseller’s Survey*.

* TFC Info and Pacific Media Associates are high-tech market research firms that specialize in

providing information on large-screen display products, markets, and manufacturers.

The name you trust. The reliability you deserve.

NEC is a global 100 company founded in 1899

with over $40 billion in revenue and 130,000

employees. NEC is also the world’s #3 patent

holder with over 70,000 patents worldwide.

For more information, call 800.632.4636 or visit

www.necvisualsystems.com

NEC is a registered trademark of NEC Corporation. All other

trademarks are the property of their respective owners. All

specifications and programs are subject to change without notice.

NEC Solutions (America), Inc.

Visual Systems Division

1250 Arlington Heights Rd., Suite 400

Itasca, IL 60143-1248 NEC 060408
