Nautilus™T618 Treadmill

Service Manual 8012458.070117.B

Service Manual

Table of Contents

1 Important Safety Instructions 2

1 Safety Warning Labels and Serial Number 3

 1 Specications 4

1 Grounding Instructions 5

1 Emergency Stop Procedure 5

1 Storage and Moving the Machine 6

1 Unfolding the Machine 7

1 Leveling the Machine 8

1 Treadmill Belt (break in period) 8

1 Connectivity 9

1 Maintenance 10

1 Cleaning 10

1 Adjusting the Belt Tension 11

1 Aligning the Walking Belt 11

1 Lubricating the Walking Belt 12

1 Heart Rate Chest Strap Battery Replacement 13

1 Maintenance Parts 14

1 Troubleshooting 16

1 Console Setup Mode 27

1 Console Engineering Mode 28

1 MCB Calibration Procedure 28

1 Demonstration Mode 29

1 Replacement Procedure Skill Level 29

2 Adjust the Walking Belt 30

3 Adjust the Deck Release Assembly 32

4 Replace the Base Frame Weldment 35

5 Replace the Bottom Motor Cover 42

6 Replace the Circuit Breaker 49

7 Replace the Console and Handlebar Assembly 52

8 Replace the Crossbar 56

9 Replace the Crossbar Tray 58

10 Service or Replace the Walking Deck 60

11 Replace the Deck Release Assembly 67

12 Replace the Deck Suspension 71

13 Replace the Deck Wheel and Shroud 74

14 Replace the Drive Belt 77

15 Replace the Front Roller 81

16 Replace the Incline Motor Assembly 86

17 Replace the Incline Weldment 92

18 Replace the Lift Shock 99

19 Replace the Lower I/O Cable 103

20 Replace the Middle I/O Cable 111

21 Replace the Motor 116

22 Replace the Motor Control Board (MCB) 122

23 Replace the Motor Control Board Cover 126

24 Replace the Motor Cover 128

25 Replace the Motor Mount 130

26 Replace the Power Inlet 134

27 Replace the Rear Roller 137

28 Replace the Rear Roller Cover 141

29 Replace the Right Upright 144

30 Replace the Rocker Switch (On/Off) 149

31 Replace the Side Rail 152

32 Replace the Speed Sensor Assembly 156

33 Replace the Transport Wheel 160

34 Replace the Walking Belt 163

Nautilus, Inc., (800) NAUTILUS / (800) 628-8458, www.NautilusInc.com - Customer Service: North America (800) 605-3369, [email protected] | outside U.S. www.nautilusinternational.com | Printed in China | © 2017 Nautilus,

Inc. | ® indicates trademarks registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Nautilus and the Cam logo are trademarks owned by or licensed to Nautilus,

Inc.

8014231.070117.B

Section Code Section Page Number Section Code Section Page Number

Important Safety Instructions and General Troubleshooting Infor-

mation for the Nautilus™T618 Treadmill 8012714.070117.B

Service Procedures

Important Safety Instructions

This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Read and

understand all Warnings on this machine.

Before servicing or using this equipment, obey the following warnings:

Read and understand the Service Manual before working on the machine. Failure to obey the instructions and safety warnings

could cause injury to the service technician or bystanders.

To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the

wall outlet and/or the machine and wait 5 minutes before cleaning, maintaining or repairing the machine. Place the power cord in a

secure location.

• Keep bystanders and children away from the product being serviced at all times.

• Makesurethattherepairisdoneinanappropriateworkspaceawayfromfoottrafcandexposuretobystanders.

• Some components of the equipment can be heavy or awkward. Enlist the service of a second person when you do maintenance steps involving

these components. Do not try to do heavy or awkward steps on your own.

• Use only replacement parts and hardware that are supplied or approved by Nautilus. Failure to use Nautilus-approved replacement parts can

adversely affect the safety and functionality of the equipment creating a risk to users and will void the warranty.

• Be sure that all warning stickers and instructional placards applied to the product stay present and in good condition when doing maintenance or

replacing components. If necessary, request replacement warning stickers or placards from Nautilus customer service.

• Do not try to change the design or functionality of the machine being serviced as this can adversely affect user safety and will void the warranty.

• Donotputthemachinebackinserviceuntilallshrouds,instructions,warninglabelsandcorrectfunctionalityhavebeenveriedandtestedfor

correct performance.

NOTICE: This document provides important safety instructions, adjustments, and general troubleshooting information for the maintenance of the Nautilus™T618 Treadmill.

If you need assistance, please call Nautilus Customer Service at 1-800-605-3369.

This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Read and understand

all Warnings on this machine.

Inc. | ® indicates trademarks registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Nautilus, the Cam logo, Nautilus Trainer and Schwinn are trademarks owned

by or licensed to Nautilus, Inc. Polar®, OwnCode®, iTunes®, GoogleTM, MyFitnessPal®, Under Armour, WD-40®, and Lube-N-Walk®are trademarks of their respective owners. The Bluetooth®word mark and logos are registered

trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Nautilus, Inc. is under license.

SAFETY WARNING LABELS AND SERIAL NUMBER

Serial Number

Product Specication

CAUTION!

Risk of Injury to Persons - To Avoid injury, use

extreme caution when stepping onto or off of

a moving belt. Read instruction manual before

using.

WARNING!

• Injury or death is possible if caution is not

used while using this machine.

• Keep children and pets away.

• Read and follow all warnings on this

machine.

• Refer to the Owner’s Manual for additional

warnings and safety information.

• The heart rate displayed is an

approximation and should be used for

reference only.

• Not intended for use by anyone under 14

years of age.

• The maximum user weight for this

machine is 350 lbs ( 158 kg ).

• This machine is for home use only.

REVISIONS

ECO

REVISION

REV DESCRIPTION

APPROVED

DATE

TITLE.

PART NO.

REV.

SHEET 1 OF 1

SCALE: 1:1

DO NOT SCALE DRAWING

1. ALL ITEMS MUST BE RoHS COMPLIANT

2. ALL DIMENSIONS APPLY BEFORE PLATING OR COATING.

3. REMOVE ALL BURRS, BREAK SHARP EDGES 0.5 MM MAX.

4. ALL MACHINES SURFACES Ra 3.2 uM.

5. ALL APPLICABLE NAUTILUS STANDARDS AND

SPECIFICATIONS APPLY.

6. ALL DIMENSIONS ARE IN MILLIMETERS

7. ALL DUAL DIMENSIONS ARE IN INCH

UNLESS OTHERWISE SPECIFIED:

METRIC

THIRD ANGLE

PROJECTION

INTERPRET DIMENSIONS AND TOLERANCES

PER ASME Y14.5M - 1994

2.5

1.5

0.75

0.25

1°

X.X

X.XX

X.XXX

ANGULAR

SIZE

This document is the property of Nautilus, Inc. It may not be reproduced in whole or part, provided to third parties, or used for any purposes other than the performance of work for Nautilus, Inc. without written authorization. All rights are reserved, including copyrights.

TOLERANCES.

DRAWN

DESIGNED

DATE

METRIC_C_REV G

NAUTILUS, INC.

16400 SE NAUTILUS DRIVE, VANCOUVER, WA 98683

LIFECYCLE

- -

APPROVALS

- -

- - - -

WARRANTY ITEM:

D.LOVELY

08 /17 / 2009

D.LOVELY

002-2354

TC SHOCK WARNING

MATERIAL.

COLOR.

DIE LINE

PMS 152

PMS 109

BLACK

WHITE

Labels must be created from an agency approved tamper proof labeling system

such as "UL Recognized component marking and labeling system (example: UL PGGU2) or equivalent.

Label and adhesive must be rated for surface it is applied to (painted metal or ABS plastic),

Label and adhesive must be rated for 60 degrees C minimum. Labels must meet UL 1647 Permanence of Marking Test.

72mm

30.5mm

A DRAWING RELEASE

B CHANGED SIZE 8/17/0912745

12247 DLOVELY

DLOVELY

REVISIONS

ECO

REVISION

REV DESCRIPTION

APPROVED

DATE

TITLE.

PART NO.

REV.

SHEET 1 OF 1

SCALE: 1:1

DO NOT SCALE DRAWING

1. ALL ITEMS MUST BE RoHS COMPLIANT

2. ALL DIMENSIONS APPLY BEFORE PLATING OR COATING.

3. REMOVE ALL BURRS, BREAK SHARP EDGES 0.5 MM MAX.

4. ALL MACHINES SURFACES Ra 3.2 uM.

5. ALL APPLICABLE NAUTILUS STANDARDS AND

SPECIFICATIONS APPLY.

6. ALL DIMENSIONS ARE IN MILLIMETERS

7. ALL DUAL DIMENSIONS ARE IN INCH

UNLESS OTHERWISE SPECIFIED:

METRIC

THIRD ANGLE

PROJECTION

INTERPRET DIMENSIONS AND TOLERANCES

PER ASME Y14.5M - 1994

2.5

1.5

0.75

0.25

1°

X.X

X.XX

X.XXX

ANGULAR

SIZE

TOLERANCES.

DRAWN

DESIGNED

DATE

METRIC_C_REV G

NAUTILUS, INC.

16400 SE NAUTILUS DRIVE, VANCOUVER, WA 98683

LIFECYCLE

- -

APPROVALS

- -

- - - -

WARRANTY ITEM:

D.LOVELY

08 /13 / 2009

D.LOVELY

002-2353

TC PULL IN WARNING

MATERIAL.

COLOR.

DIE LINE

PMS 152

PMS 109

BLACK

WHITE

Labels must be created from an agency approved tamper proof labeling system

such as "UL Recognized component marking and labeling system (example: UL PGGU2) or equivalent.

Label and adhesive must be rated for surface it is applied to (painted metal or ABS plastic),

Label and adhesive must be rated for 60 degrees C minimum. Labels must meet UL 1647 Permanence of Marking Test.

A DRAWING RELEASE

B CHANGED SIZE 8/17/0912745

12247 DLOVELY

DLOVELY

120mm

30.5mm

-Moving parts can crush and

cut.

-Keep guards in place.

-Lock out power before

servicing.

SPECIFICATIONS

This product, its packaging, and components contain chemicals known to the State of California to cause

cancer, birth defects, or reproductive harm. This Notice is provided in accordance with California’s Proposi-

tion 65. If you would like additional information, please refer to our website at www.nautilus.com/prop65.

57.7”

(146.5 cm)

35.2”

(89.5 cm)

72.4”

(184 cm)

Maximum User Weight: 350 lbs. (158.8 kg)

Maximum Inclined Deck Height: 17.2 inches (43.7 cm)

Assembled Weight: approx. 253.5 lbs (115 kgs)

Power Requirements:

Operational Voltage: 120V AC

Operating Current: 15 A

Heart Rate Chest Strap: 1 CR2032 battery

Regulatory Approvals:

• UL1645 Ed. 5 Standard for Safety: Motor-Operated Massage and

Exercise Equipment

• CSA 22.2 No. 68-09 Motor-Operated appliances (household and

commercial)

Grounding Instructions

This product must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for

electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding

conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and

grounded in accordance with all local codes and ordinances.

Improper connection of the equipment-grounding conductor can result in a risk of electric shock.

Check with a qualied electrician or serviceman if you are in doubt as to whether the product is

properly grounded. Do not modify the plug provided with the product – if it will not t the outlet,

have a proper outlet installed by a qualied electrician.

If you connect the machine to an outlet with GFI (ground fault interrupt) or AFI (arc fault interrupt), machine operation can

cause the circuit to trip. This machine is for use on a nominal 120-V circuit, and has a grounding plug that looks like the

plug illustrated below. A temporary adapter that looks like the adapter illustrated may be used to connect this plug to a

2-pole receptacle as shown if a properly grounded outlet is not available.

The temporary adapter should be used only until a properly grounded outlet can be installed by a qualied electrician.

The tab for the grounding screw must be connected to a permanent ground such as a properly grounded outlet box cover.

Whenever the adapter is used, it must be held in place by a metal screw.

Metal Screw

Tab for

Grounding

Screw

Adapter

Grounded

Outlet Box

Grounded

Outlet

Grounding Pin

Emergency Stop Procedure

The Treadmill machine is equipped with a Safety Key that can prevent serious injury, as well as prevent children from

playing with and/or being injured on the machine. If the Safety Key is not correctly inserted into the Safety Key Port, the

belt will not operate.

!Always attach the Safety Key Clip to your clothing during your workout.

When you use the machine, only remove the Safety Key in an emergency. When the key is removed while

the machine is in operation, it will stop quickly, which could cause the loss of balance and possible injury.

For safe storage of the machine, and to prevent unsupervised operation of the machine, always remove

the Safety Key and disconnect the power cord from the wall outlet and the AC input. Place the power cord

in a secure location.

The Console will display “ + SAFETY KEY ”, or add Safety Key, for a Safety Key fault. The Treadmill machine will not start

a Workout, or will end and clear an active Workout, when the Safety Key is removed. Inspect the Safety Key and be sure

it is connected to the Console correctly.

Storage and Moving the Machine

The machine can be moved by one or more persons. Use caution when you move the machine. The

treadmill is heavy and can be awkward. Make sure that your own physical strength is capable of moving the

machine. Use a second person if necessary.

1. Remove the Safety Key.

WARNING! When this machine is not in operation, remove the Safety Key and keep out of the reach of children.

2. Make sure that the power switch is turned Off, and the power cord is disconnected.

Never lift the front of the machine for moving or transport. Rotating or moving parts can pinch, resulting in

personal injury.

3. You must fold the treadmill before you move it. Never move the treadmill if it is not folded.

4. Make sure that there is safe clearance around, on and above your treadmill. Make sure there is no object to spill or

cause blockage from the fully folded position.

Be sure there is adequate height clearance for the raised deck.

5. Press and hold the plastic deck release handle (5a) under the end of the right side rail. Using the support bar (5b)

found below the rear of the walking belt, lift the walking deck and continue to hold the deck handle for the rst part

of the fold process (0-15 degrees). Release the deck handle and lift the walking deck fully upward and engage the

hydraulic lift. Be sure that the hydraulic lift is correctly locked in place

Use proper safety precautions and lifting techniques. Bend your knees and elbows, keep your back straight

and pull up equally with both arms. Make sure that your own physical strength is capable of lifting the

walking deck until it engages the locking mechanism. Use a second person if necessary.

Do not use the walking belt or rear roller to lift the treadmill. These parts do not lock in place and can

abruptly move. Injury to you or damage to the machine can occur.

15°

6. Make sure that the locking mechanism is engaged. Carefully pull back on the walking deck and make sure that it does

not move. When you do this, keep clear of movement path in case the treadmill lock is not engaged.

Do not lean against the treadmill when it is folded. Do not put items on it that could cause it to become

unstable or fall.

Do not connect the power cord or try to operate the treadmill in the folded position.

7. Carefully tilt the base frame of the folded treadmill a small distance back on the transport wheels (5c) while grasping

the support bar (5b).

Do not use the Console, handlebars, or lifted walking deck to lift or move the treadmill. Damage to the

treadmill can occur.

Keep clear of the movement path of the lifted walking deck.

8. Roll the machine on the transport wheels (5c) to its new location.

Do not put objects where the walking deck would be if lowered.

NOTICE: Move the machine carefully so that it does not hit other objects. This can damage the Console operation.

9. Prior to use, refer to the “Unfolding the Machine” procedure in this manual.

Unfolding the Machine

1. Make sure there is sufcient space to lower the walking deck.

Keep a minimum clearance behind the machine of 79” (2 m) and 24” (0.6 m) on each side. This is the

recommended safe distance for access, movement and emergency dismounts from the machine.

Place the machine on a clean, hard, level surface, free from unwanted material or other objects that may

hamper your ability to move freely with a sufcient clear workout area. A rubber mat below the machine is

recommended to prevent electrostatic discharge and protect your oor.

Be sure that the workout space you are utilizing has adequate height clearance, taking into consideration

the height of the user and the maximum incline of the deck.

2. Make sure there is no object on or around the treadmill to spill or cause blockage from the fully unfolded position.

3. Move to the right side of the machine. Press and hold the plastic deck release handle (5a) under the end of the right

side rail. While grasping the support bar (5b), release the deck handle.

Keep clear of the movement path of the walking deck.

4. The hydraulic lift is set up to drop lightly. Hold onto the walking deck until approximately 2/3 of the movement down.

Make sure that you use proper lifting technique; bend your knees and keep your back straight. The walking deck can

possibly drop quickly in the last part of the movement.

Leveling the Machine

The machine needs to be leveled if your workout area is uneven. To adjust:

1. Place the machine in your workout area.

2. Adjust the levelers until they all contact the oor.

Do not adjust the levelers to such a height that they detach or unscrew from the machine. Injury to you or

damage to the machine can occur.

3. Adjust until the machine is level.

Make sure the machine is level and stable before you exercise.

Treadmill Belt

Your treadmill comes equipped with a durable, high quality walking belt designed to provide many hours of reliable ser-

vice. The walking belt on a treadmill that has not been operated for a length of time, either in factory packaging or after

assembly, can exhibit a “thumping” noise when started. This is due to the belt taking on the curve of the front and rear roll-

ers. This is a common occurrence and does not indicate a problem with your machine. After the treadmill has been used

for a short period of time the thumping noise will discontinue. The amount of time will vary depending on the temperature

and humidity of the environment where the treadmill is placed.

Bluetooth®Connectivity with the “Nautilus Trainer™” Fitness App

This tness machine is equipped with Bluetooth®connectivity and can wirelessly sync with the “Nautilus Trainer™”

Fitness App on supported devices. The Software App syncs with your tness machine to track total calories burned, time,

distance, and more. It records and stores every workout for quick reference. Plus, it automatically syncs your workout data

with MyFitnessPal®, and Under Armour®Connected Fitness to make hitting your daily calorie goal easier than ever! Track

your results and share with friends and family.

1. Download the free Software App, named Nautilus Trainer™. The software app is available on iTunes®and Google

Play™.

Note: For a complete list of supported devices, review the software app on iTunes®or Google Play™.

2. Follow the instructions on the Software App to sync your device to your exercise machine.

3. To sync your workout data with MyFitnessPal®or Under Armour®Connected Fitness, click on the desired program

and login with your information.

Note: The “Nautilus Trainer™” Fitness App will automatically sync your workouts after the initial syncing.

USB Charging

If a USB Device is attached to the USB Port, the Port will attempt to charge the Device. The power supplied from the USB

Port may not be enough to operate the Device and charge it at the same time.

CONNECTIVITY

MAINTENANCE

Read all maintenance instructions fully before you start any repair work. In some conditions, an assistant is required to do

the necessary tasks.

Equipment must be regularly examined for damage and repairs. The owner is responsible to make sure that

regular maintenance is done. Worn or damaged components must be repaired or replaced immediately.

Only manufacturer supplied components can be used to maintain and repair the equipment.

If at any time the Warning labels become loose, unreadable or dislodged, contact Nautilus Customer

Service for replacement labels.

To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the

power cord from the wall outlet and the machine and wait 5 minutes before cleaning, maintaining or repairing the

machine. Place the power cord in a secure location.

Daily: Before each use, examine the exercise machine for loose, broken, damaged, or worn parts. Do not

use if found in this condition. Repair or replace all parts at the rst sign of wear or damage, except

for the Walking Deck. The Walking Deck is designed for wear on both sides of it. If only one side of

the Walking Deck is worn, a replacement Deck is not required. It is recommended that a qualied

service technician is used to ip the Walking Deck. After each workout, use a damp cloth to wipe

your machine and Console free of moisture.

With the Walking Deck lowered, if an edge of the Walking Belt can be seen, adjust it

until the edge is not visible.

Note: Avoid excessive moisture on the Console.

Weekly: Check for smooth roller operation. Wipe the machine to remove dust, dirt, or grime.

Do not remove the Motor Control Board (MCB) Cover. Dangerous voltages and moving

parts are present. The components are serviceable only by approved service personnel

or by following service procedures supplied by Nautilus, Inc.

Note: Do not use petroleum based products.

Monthly

or after 20 hours:

Make sure all bolts and screws are tight. Tighten as necessary.

Quarterly: Or after 25 hours—Lubricate the walking belt with a silicone-based lubricant.

Silicone lubricant is not intended for human consumption. Keep out of reach of

children. Store in a safe place.

NOTICE: Do not clean with a petroleum based solvent or an automotive cleaner. Be sure to keep the Console free

of moisture.

Cleaning

To reduce the risk of electrical shock, always unplug the power cord and wait 5 minutes before

cleaning, maintaining or repairing this machine.

Wipe the treadmill down after each use to keep the treadmill clean and dry. It may be necessary to use a mild detergent at

times to remove all dirt and salt from the belt, painted parts and the display.

NOTICE: To prevent damage to the nish of the machine or Console, do not clean with a petroleum based solvent.

Do not apply too much moisture to the Console.

Autres manuels pour T618

Table des matières

Autres manuels Nautilus tapis roulant

Nautilus

Nautilus Be Strong Commerical T914 Manuel de service

Nautilus

Nautilus T686 Manuel utilisateur

Nautilus

Nautilus T624 Manuel utilisateur

Nautilus

Nautilus T618 Manuel utilisateur

Nautilus

Nautilus Quinton Manuel utilisateur

Nautilus

Nautilus Be Strong Commerical T912 Manuel utilisateur

Nautilus

Nautilus T618 Manuel utilisateur

Nautilus

Nautilus T7.16 Manuel utilisateur

Nautilus

Nautilus 6 Series Manuel utilisateur

Nautilus

Nautilus T684 Manuel utilisateur

Nautilus

Nautilus Be Strong Commerical T916 Manuel utilisateur

Nautilus

Nautilus T616 Manuel utilisateur

Nautilus

Nautilus T9 Series Manuel d'utilisation

Nautilus

Nautilus Sport Series T514 Manuel utilisateur

Nautilus

Nautilus Commercial Series TreadClimber TC916 Manuel utilisateur

Nautilus

Nautilus Be Strong Commerical T916 Manuel utilisateur

Nautilus

Nautilus T7000 Manuel utilisateur

Nautilus

Nautilus Commercial Series TreadClimber TC916 Manuel utilisateur

Nautilus

Nautilus T624 Manuel utilisateur

Nautilus

Nautilus StairMaster ClubTrack 2100 Series Manuel utilisateur

Nautilus

Nautilus Sport Series T516 Manuel utilisateur

Nautilus

Nautilus T626 Manuel utilisateur

Nautilus

Nautilus T614 Manuel utilisateur

Nautilus

Nautilus Be Strong Commerical T912 Manuel utilisateur

Manuels tapis roulant populaires d'autres marques

Treadly

Treadly TREADLY 2 Manuel utilisateur

HEALTH ONE

HEALTH ONE Walk Ro Manuel utilisateur

NordicTrack

NordicTrack NTL12941 Manuel utilisateur

NordicTrack

NordicTrack T7.5 S Manuel utilisateur

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Manuel utilisateur

Merax

Merax MS282992 Manuel utilisateur

FYTTER

FYTTER RU-2SX Manuel utilisateur

Precor

Precor 903 Manuel utilisateur

FitLogic

FitLogic freewill d225 Manuel utilisateur

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Manuel utilisateur

Horizon Fitness

Horizon Fitness Adventure 5 Plus Manuel utilisateur

Stamia

Stamia InMotion II Manuel utilisateur

Smooth Fitness

Smooth Fitness EVO 3i Manuel utilisateur

NordicTrack

NordicTrack NETL81810.0 Manuel utilisateur

Schwinn

Schwinn 830/Journey 8.0 Manuel utilisateur

Keys Fitness

Keys Fitness HealthTrainer HT-740T Manuel utilisateur

Spirit

Spirit XT8 Manuel utilisateur

NordicTrack

NordicTrack T 14.0 Treadmill Manuel utilisateur
