NARGESA MP3003 CNC Manuel utilisateur
INSTRUCTIONS BOOK
PRADA NARGESA, S.L
Ctra. de Garrigàs a Sant Miquel s/n
17476 PALAU DE STA. EULALIA (GIRONA) SPAIN
Tel. 972 568085 - Fax 972 568320
PRESS BRAKE
MP3003 CNC
Thank you for choosing our machines
www.nargesa.com
INSTRUCTIONS BOOK PRESS BRAKE MP3003 CNC 3
INDEX
1. CHARACTERISTICS OF THE MACHINE ............................................................................... 4
1.1. General dimensions .................................................................................................... 4
1.2. Description of the machine .......................................................................................... 4
1.3. Identification of the machine ....................................................................................... 5
1.4. General features ……………….…............................................................................... 6
1.5. Accessories ................................................................................................................. 6
1.5.1. Description of accessories ............................................................................. 6
1.5.2. Tooling ........................................................................................................... 7
1.6. Description of safety devices ...................................................................................... 8
2. TRANSPORTATION AND STORAGE .................................................................................... 9
2.1. Transportation ............................................................................................................. 9
2.2. Storage conditions ………………................................................................................. 9
3. MANINTENANCE .................................................................................................................. 10
3.1. General Maintenance ................................................................................................ 10
4. INSTALLMENT AND START UP .......................................................................................... 11
4.1. Location of the machine ............................................................................................ 11
4.2. Dimensions and working site …................................................................................. 11
4.3. Admissible outer conditions ...................................................................................... 11
4.4. Connection to power supply …………....................................................................... 12
5. ADJUSTMENT OF THE BACK GAUGE HANDLES ............................................................. 13
6. FOLDING GROUP REGULATION ........................................................................................ 15
7. WARNINGS …………………………..……………………………………………………….…….. 16
ANNEX 1. SOFTWARE ESA S630
ANNEX 2. TECHNICAL FEATURES
ANNEX 3. LASER DEVICES
INSTRUCTIONS BOOK PRESS BRAKE MP3003 CNC 4
1. CHARACTERISTICS OF THE MACHINE
1.1. General dimensions
1.2. Description of the machine
The MP3003CNC press brake, is designed specifically for folding sheet in different degrees, any
application other than specified above, exonerates the manufacturer from any responsibility for the damage
to the machine or the people who use it.
The MP3003CNC is according to the European standards and directives for the manufacturing of
industrial Machinery.
INSTRUCTIONS BOOK PRESS BRAKE MP3003 CNC 5
Electric motor
Hydraulic container
Oil emptying cap
1.3. Identificación de la máquina
Screws to level
the machine
Punch
Back gauge handles
Die
Die-holder
Control panel
Lateral protection
Sliding arms
Laser
INSTRUCTIONS BOOK PRESS BRAKE MP3003 CNC 6
1.4. General features
- Motor 9,5 Kw (12CV) at 1400 r.p.m.
- Intensity of 19 A at 400 V / 32 A at 230 V
- Pump 22 l./m.
- Deposit of 100 liters.
- Double acting piston (120 Tm).
- Pressure of the hydraulic pump 225 Kg./cm2
- Total weight 9100 Kg.
- Cleavage of 320 mm.
- Inner folding lenght 2700.
- Total folding lenght 3125 mm.
- Total displacement of top 600 mm.
- Maximum punch displacement 160 mm.
1.5. Accessoires
1.5.1. Description des accessoires
Le poinçon et la matrice sont traités, ce qui assure leur fiabilité et leur résistance pour un usage normal.
Les matrices possèdent plusieurs ouvertures pour les différentes épaisseurs de tôle et rayons de pli.
INSTRUCTIONS BOOK PRESS BRAKE MP3003 CNC 7
1.5.2. Tooling
The press brake MP3003CNC, has been designed for the use with “V” dies, punch and die holder.
Other dies with upper V’s seccioned punches and press brake anvils can be also used. Please ask the
manufacturer.
Punch
Die
Die holder
INSTRUCTIONS BOOK PRESS BRAKE MP3003 CNC 8
1.6. Description of safety devices
Fixed safety devices consisting of CNC press brake MP3003CNC are the side shields to prevent manipula-
tion of tooling on the sides and guards at the rear of the machine covering the belts and pulleys of the rear
gauge.
You can not remove the protective caps unless it is for maintenance and it should be carried out by techni-
cally trained personnel. PRADA NARGESA will not responsible for damage caused by not adhering to the
afore mention instructions.
Left top side
protection
Front protection of
the connecting rods
Left top side
protection
Right side protection
Front protection of
the connecting rods
Left side protection
Lower rear
protection
Left side
protection
INSTRUCTIONS BOOK PRESS BRAKE MP3003 CNC 9
2. TRANSPORTATION AND STORAGE
2.1. Transportation
Lifting should be performed by a crane, on the marking point to that end anchorage. The machine will never
rise by anywhere else other than the specified and provided the two points of the front of the machine will
be used because the weight is found mostly in the front so we will make the machine remain in a horizontal
line when raised.
2.2. Storage conditions
Press brake will not be never stored in a place where the following conditions are not settled:
* Humidity between 30% and 95% non-condensing.
* Temperature -25 to 55 ° C or 75 ° C for periods not exceeding 24 hours (remember that these
temperatures are in storage)
* It is advisable not to stack heavy objects on the machines.
* Do not disassemble for storage.
Lifting points to be
raised by a crane
Lifting points to be
raised by a crane
INSTRUCTIONS BOOK PRESS BRAKE MP3003 CNC 10
3. MAINTENANCE
3.1. General maintenance
At the top of the tank there is the level sightglass. In the absence of oil, fill up to the mark of the peephole.
- Every 1000 hours of use, check the oil level in the tank.
- Replace oil every 4,000 hours of work.
Oil Type: SIL POWER HV-46
WARNING
Stop the machine in order to carry out the maintenance of the machine. In case of replacement of the oil,
start the engine and depress the flashing time increasing the pressure gradually until the circuit is
complete.
- Grease the boulders fixing rods and piston periodically depending on use.
- If the use is daily and continuous, grease each month.
- Grease all guide fittings monthly.
- Check the oil level of the machine.
Filling cap
Oil level sight glass
Emptying cap
