Myson TOUCH4 Manuel utilisateur
Model: TOUCH4
Model:
TOUCH4
1Time Clock Series
Model: TOUCH4
1
Time Clock
Series
Model:
TOUCH4
Table of Contents
1
2
3-4
5-6
7
8
9
10
11
12
13
13
14
1
11
7
14
3-4
13
9
Product Image
Table of Contents
Installation Procedure
LCD Display
Normal Run Mode
Setting the Clock
Holiday
Selecting 5/2 Day or 7 Day Programming
Adjusting the Switching Times
Copy Function
Mode Select
Boost Facility
Wiring Diagram
Model: TOUCH4 2
3Time Clock Series
Installation Procedure
This time clock is designed to be flush mounted and requires a back box of 35mm
(minimum depth) to be sunk into the wall prior to installation.
Step 1
Carefully separate the front half of the time clock from the back plate by placing a
small flat head terminal driver into the slots on the bottom face of the time clock.
Step 2
Place the front of the time clock somewhere safe.
Terminate the time clock as shown on the wiring diagram on page 14 of this booklet.
Step 3
Screw the time clock back plate securely into the back box.
Step 4
Clip the front of the time clock on to the back plate.
Do
Mount the time clock at eye level.
Read the instructions fully so you get the best from our product..
Don’t
Do not install near to a direct heat source as this will affect functionality.
Do not push hard on the LCD screen as this may cause irreparable damage.
Model: TOUCH4 4
1 2
3 4
5Time Clock Series
1 2
7
4
5
6
8
10
12
9
3
11
5 Time Clock Series
Model: TOUCH4 6
1. Day Indicator - Displays the day.
2. Copy - Enables copying of switching times from one zone to another.
3. On Until/Off Until – Displays the current operational status of the timed output.
4. Timer Status - Displays the current status of the timed output.
5. Up/Down Keys - Increase or decrease values shown on left digit group.
6. Up/Down Keys - Increase or decrease values shown on right digit group.
7. Select Zone - Prompts a zone selection.
8. Boost Left/Holiday Left - Displays the remaining duration of a timed boost
or holiday setting
9. Power: Press once to turn off display. Cancel: Used to exit setup/program operations.
10. Setup/Programming Keys - Used to navigate setup options.
11. Off/Constant/Auto – Displays selected zones’programming mode.
12. Zone/Time Selection Keys – Used with Zone/Times configuration.
LCD Display
7Time Clock Series
7 Time Clock Series
Normal Run Mode
In normal run mode, the time clock will display the current time. It can also be set to
show the status for a particular zone. To display the status of a zone, press
Zone 1 – Zone 4. This screen will be displayed until you press DONE and return to
the main menu.
Normal Run Mode Zone Selected
Model: TOUCH4 8
8Model: TM4
To set the clock, follow these steps:
• Press the Clock key .................................................................................................................
• Use the Left Up/Down keys to set the hour .......................................................
• Use the Right Up/Down arrow keys to set the minute ....................................
• Press the Day key to set the day ........................................................................................
• .........................................................................................
Setting the Clock
Adjust Hours
Adjust Minutes
Minutes
Adjust Day
Current Day
Hours
9Time Clock Series
9 Time Clock Series
All four timed outputs will be disabled during a holiday period.
At the end of your holiday, the time clock will revert back to the programmed setting.
• Press HOLIDAY ..............................................................................................
• Enter the desired duration in days ........................................................
• .............................................................
To cancel a Holiday setting, reduce the holiday time to 00 days.
Holiday
Holiday Days
Note: A holiday period does not start until 00:00 the next day. For example, if you set a holiday
revert back to the programmed schedule at 00:00 on Monday.
