Mxr Clone Looper M303 Manuel utilisateur

Clone Looper Pedal

Whether you’re practicing at home, captivating

audiences with improvisational compositions

onstage, or weaving intricate sonic tapestries in the

studio, the Clone Looper Pedal has you covered.

Packed into a standard MXR housing that’s built like

a tank, it’s easier to use and delivers higher ﬁdelity

signal reproduction than any other looper of its

type—hands down.

M303

jimdunlop.com/m303

™

M303 | Clone Looper™2

1 REC/DUB footswitch controls loop

recording and clear loop quickly functions

2 VOLUME knob controls output level,

loop speed, loop direction and clear loop

quietly functions

3 PLAY/STOP footswitch controls loop

playback and undo/redo functions

4 CTR jack allows tap switch to control

loop speed, loop direction, and clear loop

quietly functions

5 EXP jack allows expression pedal to set

output level or tap switch to engage Play

Loop Once mode

425

External Controls

M303 | Clone Looper™3

Basic Operation

1. Run a cable from your guitar to the M303’s INPUT jack

and run another cable from the M303’s OUTPUT jack to

your ampliﬁer.

2. Start with all controls at 12 o’clock.

3. To record your loop, tap the REC/DUB footswitch. The

ﬂashing red REC/DUB LED indicates that recording mode

is active. Play for a desired length of time, and then tap

the PLAY/STOP footswitch again to close the loop and

start playback.

4. To add a new layer, tap the REC/DUB footswitch.

The green PLAY/STOP LED will ﬂash a 4-count to the

beginning of the loop so that you can play your next

loop in sync with the ﬁrst. Press and hold PLAY/STOP

footswitch to clear the most recent layer.

5. To undo the last loop layer, press and hold the PLAY/

STOP footswitch. Press and hold the PLAY/STOP

footswitch again to redo the last loop layer if you decide

that you want it back. To quickly clear the entire loop,

press and hold REC/DUB switch.

6. Rotate the VOLUME knob clockwise to raise the loop’s

output level or counterclockwise to decrease it.

7. The VOLUME knob’s push function can also be used to

change the speed of the loop and reverse it. Press once

for Half-Speed. Blue LED will illuminate in a steady state.

Double-press for Double-Speed. Blue LED will illuminate

in a ﬂashing state.Press and hold to reverse the loop.

Amber LED will illuminate in a steady state

8. To clear loop quietly, press and hold the VOLUME

knob for 5 seconds. When the red REC/DUB LED ﬂashes,

press the REC/DUB footswitch within 5 seconds to clear

the loop without it playing ﬁrst.

The Clone Looper™ Pedal is powered by the Dunlop ECB003

9-volt adapter or the DC Brick™, Iso-Brick™, and Mini Iso-

Brick™ power supplies. This pedal cannot be powered by a

battery.

Power

M303 | Clone Looper™4

USE AN EXPRESSION PEDAL TO CONTROL

LOOP VOLUME

Connect an expression pedal such as the DVP Volume (X)™

Pedal to the M303’s EXP jack with a TRS cable. Use the rocker

to adjust loop volume. This will disable the VOLUME knob.To

reenable the VOLUME knob after disconnecting the expression

pedal, simply twist the VOLUME knob past 12 o’clock twice.

USE A TAP SWITCH TO PLAY LOOP ONCE

Connect an MXR Tap Tempo Switch to the M303’s EXP jack with

a mono cable. To initiate Play Loop Once mode, tap the switch.

The green PLAY/STOP LED will ﬂash until the loop ends.Tapping

the switch at any time during the loop’s duration will re-trigger

the loop, allowing for a stuttering effect.

USE A TAP SWITCH TO CONTROL VOLUME

KNOB’S PUSH FUNCTIONS

Connect an MXR Tap Tempo Switch to the M303’s CTR jack.

You can now use the tap switch to control the speed and

direction of the loop as well as clear the loop quietly.

TRUE BYPASS MODE

The M303 uses buffered bypass switching by default.To enable

true bypass switching, press and hold the VOLUME knob while

powering up the pedal.

Advanced Operation

M303 | Clone Looper™5

Speciﬁcations

Input Impedance 1MΩ

Output Impedance 100 Ω

Maximum Intput Level +5dBV

Maximum Output Level +5dBV

Frequency Response 20 Hz to 20 kHz

Noise Floor -97 dBV

Sampling Rate 44.1 kHz

Current Draw 225 mA

Power Supply 9 volts DC
