Mxr Dyna Comp Bass Compressor Manuel utilisateur

M282 | Dyna Comp© Bass Compressor 2

1OUTPUT knob adjusts volume of compressed signal

2CLEAN knob adjusts wet/dry signal mix added to the compressor’s output

3SENSITIVITY knob adjusts sustain time

4ATTACK switch toggles between slow & fast attack times

5TONE knob cuts/boosts midrange at 1kHz

6FOOTSWITCH toggles effect on/bypass (blue LED indicates on)

1

2

5

4

3

6

External Controls

M282 | Dyna Comp© Bass Compressor 3

Basic Operation

1 Run a cable from your guitar to the M282’s INPUT jack and run

another cable from the M282’s OUTPUT jack to your ampliﬁer.

2 Start with all knobs set to 12 o’clock.

3 Turn the effect on by depressing the footswitch.

4 Rotate CLEAN knob to increase amount of unaffected signal to be

added to compressor’s output or counterclockwise to decrease it.

5 Rotate SENSITIVITY knob clockwise to increase sustain time or

counterclockwise to decrease it.

6 Push ATTACK switch to toggle between default slow attack time

and fast attack time, indicated by red LED.

7 Rotate OUTPUT knob clockwise to increase effect volume or

counterclockwise to decrease it.

8 Rotate TONE knob clockwise to boost midrange at 1kHz or

counterclockwise to cut it.

The Dyna Comp®Bass Compressor is powered by one

9-volt battery (remove bottom plate to install), the Dunlop

ECB003 9-volt adapter, or the DC Brick™, Iso-Brick™, and

Mini Iso-Brick™ power supplies.

Power

Directions

M282 | Dyna Comp© Bass Compressor 4

Speciﬁcations

Input Impedance 600 kΩ

Output Impedance 25 kΩ

Max Input Level -5 dBV

Max Output Level +2 dBV

Max Compression 36 dB

THD* 0.2%

Noise Floor** -100 dBV

Current Draw 11 ma

Tone +/- 7dB, 1kHZ

Power Supply 9 VDC

* Measurements made at -dBV, 1kHZ

** A-weighted, all controls mid position
