MUTOH VJ-2606 Mode d'emploi

VJ-2606

User

Maintenance

and Cleaning

Guide

Page 1 of 7

ATTENTION: This is a supplementary document and is to be

used in conjunction with the ValueJet 1604 User Operations Manual.

Please refer to Section 4: Daily Maintenance of the Quick Reference

Guide or Section 6: Maintenance of the Operation Manual CD, for

complete step by step instructions for performing these items.

Section 1: Intervals

User Level Maintenance Intervals VJ-2606

1-2 times per week Once a week Every 1-2 Months

□Clean Wiper

□Clean around caps

□Clean Around Print

Heads

□Replace Flushing Box

Sponge

Section 2: Supplies

1. Supplies for cleaning the VJ-2606 can purchased as a kit P/N: 11606-0001

1

2

3

4

5

6

7

Item # Description Qty

1 Absorbent Pad 1 box of 3

2 Foam Swabs 25

3 Tweezers 1

4 Lint Free Cloth 36

5 Flushing Box Foam Pad 1 box of 5

6 250ml bottle eco-cleaning 1

7 Rubber Gloves 5 pair

Please Note: If item #6 is not present please use Isopropyl Alcohol only.

Page 2 of 7

Section 3: Cleaning Procedures

** Clean Wipers

Do not touch Wipers. Oil from your hands may prevent the wipers from cleaning the

head properly.

1. The wipers can be cleaned using either the foam swabs or the lint free cloth. Either Eco-

cleaning solution or Isopropyl Alcohol may be used in conjunction with the cleaning

utensil of choice.

Page 3 of 7

** Clean around caps

Do not touch the Rubber Caps. Oil from your hands may prevent the caps from

sealing properly.

1. Using either a foam swab or a lint free cloth soaked in Eco-cleaning solution or Isopropyl

Alcohol, wipe around the edges of the rubber caps. This ensures a good seal is

maintained during head cleaning process.

Page 4 of 7

** Clean around Print Head

CAUTION

•When cleaning around Print Heads

Do Not Touch the Bottom of the heads.

Do Not Clean the Nozzle Surface with the cleaning device.

Do not use water to clean the head. Nozzle clogging may occur

Do Not Re-use dirty foam swabs or lint free cloths

1. Using a foam swab or lint free cloth clean the following areas under the carriage.

•Stainless steel ring around the head

•Bottom sides of the guides on either side of the carriage.

•Any other areas under the print head carriage that appears to have ink or dirt build-up.

Page 5 of 7

Clean the stainless steel ring

around the head, being extra

careful not to touch the nozzle

surface.

Clean any dirt or debris that

has accumulated on the

guides on either side of the

carriage.

Page 6 of 7

** Replace Flush Box Sponge

1. Open the front cover.

2. Remove and replace the flush box sponge using a pair of tweezers.

Please Note: Replace the sponge on the left hand side of the printer as need, if the left

side flush box is not used often and the sponge appears clean it does not need changed.

Page 7 of 7
