Munters EC52 Manuel utilisateur

Assembly manual

Spare part list + Assembling guideline

EC52

Exhaust fan

EC52

Ag/MIT/IGB-2206-08/14 rev 1.0

EC52

Assembly manual

Original instructions

This document is destined for the user of the apparatus: it may not be reproduced in whole or in part, committed

to computer memory as a file or delivered to third parties without the prior authorisation of the assembler of the

system.

Munters Italy S.p.A. reserves the right to effect modifications to the apparatus in accordance with technical and

legal developments.

Index

chapter page

1. SPARE PART LIST 4

EC52 exploded view 4

Spare parts 6

2. ASSEMBLING TOOLS 16

3. ASSEMBLING GUIDELINES 19

Housing assembling 19

Centrifugal system and pulley to propeller assembling 21

Propeller and motor to central support assembling 22

Shutter blades assembling 28

Cone discharge assembling 31

Optional belt tensioner assembling 33

Optional pyramidal shape mesh assembling 35

All the components and spare parts MUST be storaged in dry and clean

environment.

WARNING

510

3131

Spare part list

EC52

fig.1

57 56

46 60 58

59 60 55

6362

48 54 53

54 53

3938

42 44

47 38 46

3938

29 27

DETAIL A

fig.2

DETAIL B

fig.3

DETAIL C

fig.4

Spare part listChapter1

DETAIL D: ALIGNEMENT OF SHUTTER BLADE

fig.5

POSITIONING OF REINFORCEMENT

fig.6

ALIGNEMENT OF BELLEVILLE SPRING

fig.7

Spare parts

Ref. Picture Description Q.ty

1 THREADED BUSH M8X12.5 8

2 POP UP RIVET 4.9X7 STEEL 26

Spare part listChapter1

Hex socket screw M8

with spring washer D8 to

fix reinforcement

3 TOP PANEL 1

4 CONVEYOR 1

5 CENTRAL RIGHT PLASTIC BEARING 1

6 RIGHT PLASTIC BEARING 9

7 SHUTTER BLADE 9

8 HEXAGON SCREW M6X16 28

9 PYRAMIDAL REAR SAFETY MESH 1

10 PLASTIC CLIP FOR MESH 10

11 STOP COLLAR D7X17 2

Spare part listChapter1

12 TIE ROD 2

13 HEXAGON NUT M6 2

14 CENTRAL LEFT PLASTIC BEARING 1

15 LEFT PLASTIC BEARING 9

16 CENTRAL SHUTTER BLADE 1

17 COVER PLATE 2

18 SPRING HOOK 2

19 RUBBER GROMMET 1

20 SIDE PANEL 2

Spare part listChapter1

21 BOTTOM PANEL 1

22 CONE SECTOR 2

23 CONE SECTOR CUT 2

24 CONE MESH INTERRUPTED WIRE 1

25 PLASTIC TIE LEGRAND MM9X357 6

26 CONE MESH CONTINUOUS WIRE 1

27 HEXAGON NUT THICK M6 26

28 PLAIN WASHER Ø6.4X24 44

29 SPRING WASHER D6 8

Spare part listChapter1

30 CONE BRACKETS 4

31 SELF TAPPING SCREW 6.3X19 22

32 HEXAGON SOCKET COUNTERSUNK HEAD SCREW M10X30 4

33 OVAL PLATE 2

34 CENTRAL SUPPORT 1

35 EXTERNAL TOOTHED WASHER D10 4

36 HEXAGON NUT M10 4

37 PLAIN WASHER D8X16 2

38 SPRING WASHER D8 8

Spare part listChapter1
