MULTISPAN MTC-1202 Manuel utilisateur

SPECIFICATIONS

1. Microcontroller based. Double Display.

2. Size: 96 x 96 x 110 mm

Panel cutout: 92 x 92 mm

3. Supply: 230 V A.C. 50 Hz (SMPS).

4. Input Sensor: K Type.

5. Output: 2 Relays, 5 A/230V Relay contact.

R1 = For control purpose

R2 = For alarm purpose

1. DISPLAYS: There are two Displays.

A) Display 1 : Upper 4 digit display in RED colour indicates current process temperature value

(PV).

B) Display 2 : Lower 4 digit display in GREEN colour indicates current SET POINT (SP).

C) LED’s : 1) A small Red LED in upper right hand side as R1.

2) A small Red LED in lower right hand side as R2.

2. FRONT KEYS:

These front keys can be used to see and change current values of

FUNCTION DISPLAY RANGE

1. RATE 1  0.1 to 9.9°C/min

2. SET POINT 1  0 - 1191°C

3. HOLD TIME 1  01 to 999 min

4. RATE 2  0.1 to 9.9°C/min

5. SET POINT 2  0 - 1192°C

6. HOLD TIME 2  01 to 999 min

7. RATE 3  0.1 to 9.9°C/min

8. SET POINT 3  0 - 1193°C

9. HOLD TIME 3  01 to 999 min

10. RATE 4  0.1 to 9.9°C/min

11. SET POINT 4  0 - 1194°C

12. HOLD TIME 4  01 to 999 min

13. RATE 5  0.1 to 9.9°C/min

14. SET POINT 5  0 - 1195°C

15. HOLD TIME 5 HLd5 01 to 999 min

16. RATE 6  0.1 to 9.9°C/min

17. SET POINT 6  0 - 1196°C

18. HOLD TIME 6  01 to 999 min

19. RATE 7  0.1 to 9.9°C/min

20. SET POINT 7  0 - 1197°C

21. HOLD TIME 7  01 to 999 min

22. RATE 8  0.1 to 9.9°C/min

23. SET POINT 8  0 - 1198°C

24. HOLD TIME 8  01 to 999 min

25. RATE 9  0.1 to 9.9°C/min

26. SET POINT 9  0 - 1199°C

27. HOLD TIME 9  01 to 999 min

28. ALARM  0 to 1200°C

SET



ENT



OPERATING MANUAL

Nine Stage Profile Temperature Controller

MTC-1202

3. ADJUSTMENT OF SET POINTS:

(a) RATE1 [rat1 ]:

Press key for 2 seconds.

You are in SET MODE.

Display 1 will show rat1.

Display 2 will indicate current value of set point. Range is 0.1 to 9.9°C/min

You can change current value of this set point by following PROCEDURE.

Increase the parameter by key.

Decrease the parameter by key.

Press to store it in memory or press for next step.

If No key is pressed for 5 seconds previous value of parameter is retained and controller goes in control

mode.

(b) SET POINT 1 [Set1]:

Press key for 4 seconds.

You are in SET MODE.

Display 1 will show SEt1.

Display 2 will indicate current value of set point. Range is 0°C to 1200°C

You can change current value of this set point by following PROCEDURE.

Increase the parameter by key.

Decrease the parameter by key.

Press to store it in memory or press for next step.

If No key is pressed for 5 seconds previous value of parameter is retained and controller goes in control

mode.

Press key for 6 seconds.

You are in SET MODE.

Display 1 will show HLd1.

Display 2 will indicate current value of set point. Range is 1 to 999min.

You can change current value of this set point by following PROCEDURE.

Increase the parameter by key.

Decrease the parameter by key.

Press to store it in memory or press for next step.

If No key is pressed for 5 seconds previous value of parameter is retained and controller goes in control

mode.

NOTE: You can do the setting of the remaining parameters Rate2, Setpoint2, Holdtime2 Rate3, Setpoint3,

Holdtime3, Rate4, Setpoint4, Holdtime4, Rate5, Setpoint5, Holdtime5, Rate6, Setpoint6,

Holdtime6, Rate7, Setpoint7, Holdtime7, Rate8, Setpoint8, Holdtime8, & Rate9, Setpoint9,

Holdtime9 just like (a), (b) & (c).

NOTE: Here, the Control Action is On-Off & Hysteresis provided is fixed which is 2°C.

NOTE: Initially as the power is turned on Relay (R2) is turned ON. After completion of hold 9 the

process will be off and r2 goes OFF, when process temperature reaches at ALARM set point

and lower display will show end.

WORKING

1) As the power turns ON upper display shows room temperature/ process temperature and lower

display shows value current temperature, which changes according to the Rate (°C/min).

SET



SET

ENT



SET



SET

ENT



SET



SET

ENT



2) Initially when temperature reaches to the Set value decided, during that period RELAY 1 (R1)

turns ON. When it crosses to the Set value then RELAY R1 becomes OFF. Again when it reaches

SEt - HYS where Hysteresis is fixed 2°C it will turns ON again RELAY (R1).

3) Here, Relay R1 is for controlling purpose. It operates only when temperature reaches to the set

point.

4) By pressing both & keys one can see on the lower display which particular rate or

which particular hold time is going on.

5) Every Higher stage set point is always greater than all its lower stage set point except the last

stage (9) set point. The ninth stage set point can set to any value from 0 to 1200 °C.

Note # 1: When you operate this unit first time, you can freely play with key

to understand key operations, previously set parameter will remain unaffected as long as you

don’t press key.

CONNECTION DIAGRAM

SET





SET





ENT
