MRC UT-FLU5B Manuel utilisateur

UT-FLU5B

FLUOROMETER

OPERATION MANUAL

3, Hagavish st. Israel 58817 Tel: 972 35595252, Fax: 972 3 5594529

[email protected]

MRC. 12.22

✓

 



 Oil co Protein





, 

  

Preface

Thank you for purchasing this product. This user manual contains the

functions and operation procedures of the instrument. In order to ensure the

correct use of the instrument, please read the manual carefully before

operating the instrument. Please keep the manual in a safe place so that you

can read it quickly if you encounter a problem.

Unpacking Inspection

When the user unpacks the instrument for the first time, please check

the instrument and accessories against the packing list. If the instrument or

accessories are found to be wrong, incomplete or abnormal, please contact

the seller or manufacturer.

III

Matters Needing Attention

1. Important Safety Operating Information

The user needs to have a complete understanding of how the instrument works

before operating the instrument safely. Users should read this manual carefully before

operating the instrument.

2.Safety

The following basic safety precautions must be observed during all operations,

maintenance, and repair of this instrument.Failure to observe these precautions or the

warnings noted elsewhere in this manual may affect the protection provided by the

instrument and the intended range of use of the instrument.

It is forbidden for anyone to operate the instrument without reading the

manual. If you do not follow the instructions in the manual, the

instrument may cause accidental injury during operation, and electric

shock may occur. Please read the following safety tips and guidance

carefully and implement all precautions contained therein.

This instrument is an ordinary device that complies with the GB4793.1

standard, and this instrument is the product for indoor use.

Please read this manual carefully before operating the instrument,

otherwise personal injury may be caused.Only qualified inspectors trained

in the installation and use of electrical equipment should operate this

instrument.

Except for the parts that can be opened by the user as specified in the

manual, it is strictly forbidden for the user to disassemble the instrument.

Failure to do so will void your warranty and may also expose you to electric

shock. If repair is required, the company is responsible for the repair.

This instrument is only used for scientific research experiments and is

not suitable for clinical testing!

CAUTION: Biological contamination. All test samples, quality controls,

calibrators, etc., should be considered infectious, and gloves should be worn

when contacting; parts that have been in contact with test samples should be

considered infectious, and gloves should be worn when touching;

The instrument should be placed in a dry, dust-free place away from water

and direct sunlight and strong light sources. The room should be well

ventilated, free from corrosive gases or strong magnetic fields, and away

from heaters, stoves and all other heat sources. Do not place the instrument

in a humid or dusty place.

Nothing should be covered by the power cord when the instrument is in

use. Do not place the power cord where people move.

Be sure to hold the plug when plugging and unplugging the power cord.

Make sure that the plug is fully inserted into the socket when plugging in,

and do not pull the power cord hard when unplugging.

Turn off the power when it stops working. When the instrument is not used

for a long time, unplug the power plug and cover the instrument with a soft

cloth or plastic paper to prevent dust from entering.

In the following cases, the power plug of the instrument should be unplugged

from the power outlet immediately, and contact the supplier or a trained

service person to deal with it:Liquid spilled into the instrument;

The instrument is drenched or watered;

The instrument falls or the shell is damaged;

The function of the instrument has changed significantly.

Warranty Description

a) Warranty content

Within 1 month from the date of delivery of the instrument, the company will be

responsible for the replacement of the failure caused by defects in materials and

manufacturing.

The instrument is warranted against failures due to defects in material and

manufacture for a period of 12 months from the date of delivery. During the warranty

period, the company will selectively repair or replace instruments that prove to be

defective.

Warranted products must be sent by the user to the maintenance department

determined by the company. The shipping cost of the instrument from the user to the

maintenance department shall be paid by the user. The company bears the shipping cost of

returning the instrument to the user.

For repairs outside the warranty period, the company will properly charge the cost

of repairs.

b) Warranty range

The above warranty does not apply to damage caused by improper use and

maintenance by the user, use in non-compliant conditions, unauthorized repair or

modification.

─1─

Chapter Ⅰ Brief introduction

Fluorescence immunoassay technology has the advantages of strong specificity, high

sensitivity, and good practicability, so it is used to measure biologically active compounds

with very low content,such as proteins (enzymes, receptors, antibodies), nucleic acids,

hormones (steroids, thyroid hormones, phthalohormones), drugs and microorganisms.

This fluorometer is based on fluorescence immunoassay technology, which detects

the luminescence intensity of fluorescent reagents in immunoassays; Under the condition

of low concentration, the concentration of the sample and the fluorescence intensity have

a linear relationship, so the qualitative and quantitative analysis of the detected object is

carried out.

─2─

Chapter Ⅱ Features

Basic parameters and performanc

Normal working conditions

Ambient temperature: 4C 45C

Relative humidity: ≤70%

Power supply: DC 9V 1.5A

Battery:18650 Rechargeable lithium battery(3400mah*2，can last for 5 hours)

Specification:

Product name Light source Excitation

wavelength

Emission

wavelength

UT-FLU5B IFluorimeter Blue LED 460±20nm 525nm

Red LED 625±20nm 690nm

UT-FLU5B II Fluorimeter Blue LED 460±20nm 525nm

UV LED 365±20nm 470nm

UT-FLU5B III Fluorimeter Blue LED 460±20nm 525nm

Green LED 525±20nm 620nm

Else customized

Model

Parameters UT-FLU5B

light source Monochrome LED

Linearity 2

R>0.995

Repeatability <1.5%

Stability <1.5%

Sensitivity Ds DNA：1ng/ml；

Measuring speed 3s（single time）

Dimensions

(WXDXH) 194*155*72.5

Net weight (kg) 1.0Kg

─3─

Chapter Ⅲ Instrument composition

This chapter mainly introduces the structure of the instrument and the preparations before

it is turned on. When using the instrument for the first time, you should familiarize yourself

with the contents of this chapter before turning it on.

Structure diagram:

Figure 1 Instrument structure

USB export

Printer interface

USB port

Power socket

Switch

Display

Sample

cover

─4─

Chapter Ⅳ Instrument installation

1. Unpacking inspection

All fluorometers have been strictly inspected by the company before they are packaged

and shipped. When you receive the instrument, please check carefully before unpacking, and

pay attention to the following damages:

①The outer packaging is inverted or deformed;

②The outer package contains obvious traces of wet water;

③The outer package contains obvious signs of impact;

④signs that the outer packaging has been opened;

Once the above damage is found, please contact the company or notify the local agent

immediately.

If the outer package is in good condition, please open the package and check after

unpacking in the presence of agents and staff:

①According to the packing list, check whether all components are complete;

②Carefully check the appearance of all devices to see if there are cracks, bumps or

deformations.

2.Installation requirements

①Space: a dry, clean, level work surface.

②Working environment

a. The ambient air is clean and free of corrosive steam and smoke.

b. Ambient temperature between +10°C and +40°C.

3.Installation steps

①Place the instrument and packaging lightly on the operating site, open the carton, and then

take out the instrument and place it on the operating table.

②Put the "ON/OFF" switch on the back of the instrument to the "OFF" position. Take out the

15V power adapter, insert its plug into the socket at the rear of the instrument, and connect the

other end to the AC100~220V power supply.
