MP-Man FIESTA2 Manuel utilisateur

FIESTA2

FOR MODEL NO

Mp3 Player with Speaker

Instruction Manual

Please read this instruction carefully before the operation

Page 1

User Manual

KEY DEFINITIONS

①PowerON/OFF

②Play:Play/PauseButton

③MENU:MenuButton

④NEXT: Next music

⑤LAST: Previous music

⑥VOL: VOL+/ VOL-

⑦Earphone jack.

⑧USB plug

⑨MICRO SD CARD

Page 2

Key Operation

1. Power on / Play / Pause / Stop, hereinafter referred to as the "PLAY" button.

2. “MODE” Enter the main menu or previous menu.

3. “VOL”：Enter the volume interface.

4. “Next”：Next option, Fast-forward. Volume increases, the fast increase.

5. “Last”：Previous option, Rewind., Volume reduction, and faster reduction.

6. “USB”：USB plug.

7. “ON/OFF”：Power switch.

8. “Headphone jack”：Headphone standard jack.

zAudio mode

1. In music mode, there are two different menus available: one is pressing M while playing. It will appear

the following menu:

- Equalizer

- Repeat: normal, repeat one, repeat all

- Replay

- Exit

2. A variety of sound effects (EQ), the specific menu as follows:

Natural

Rock

Pop

Classical

Soft

Jazz

DBB

3. Toggle the Next button to select, short press Mode key to confirm.

The other menu will appears wile pressing M key in the Stop or Pause mode, you will find the following

menu: local folder, delete file, delete all and exit.

zsynchronous lyrics display

The player supports "* LRC" lyrics files, lyrics and songs synchronous playback.

Native songs match the appropriate lyrics are automatically read during playback. Do not need to

press any key allows you to use with ease

Page 3

Sound recording

Native support for 99 recording files are stored for each directory.

zIn the recording mode to record

1. Enter the main menu: “Recording”

2. Toggle the Next button to select the recording mode.

3. Short press Mode key to enter the recording mode, the graphics are as follows:

4. Short press the Play button to start recording.

During recording, short press the Play button to pause recording, long press the Play button to save

the audio file. Long press Mode button to exit the recording mode and save the recording file.

The recording process only responds to the "Play" button and the Mode button.

zTo select the recording type

1. In the recording stop interface

2. Short press Mode key to enter record submenu

3. Toggle the Next button, select the "recording type" sub-menu item, press the Mode button to enter

Fine

recording

wav format, the sound quality is better.

Long-term

recording

wav format, the sound quality is ordinary.

Super

recording

Wav format, high bit rate recording file

4. Press Next to select the right type of recording, and a short press Mode key to confirm the selected

type.

5. Press the Play button to start recording.

Play recording file

1. Enter the main menu

2. Toggle Next button, select "Voice"

3. Press play

4. Select the recording file.

Last button：Select the previous recording file.

Next button：Select the next recording file.

System Settings

Here you can set system parameters, the options change with the firmware upgrade.

1. Enter the main menu

Page 4

2. Toggle Next key to select "System Settings"

3. Short press Mode key to enter the "System Settings"

zLcd set

zLanguage

zPower off

zMemory info

zFirmware version

zExit

zEach parameter project profiles

zDetailed instructions for use

zSystem

zLcd set

zLanguage

zPower off

zMermory info

zFirmware version

zExit

LCD Set

Contrast adjustment

Language Selection

Shutdown Settings

Storage conditions:

●Indicate the total disk capacity, expressed as a percentage of the space than has been used.

●Firmware version

●You can view the firmware version currently in use by the player.

Tips: after the option is set press the Mode button to exit or you can press the Play button to quickly

exit the menu. Press the Play button to quickly exit the menu function on all menus.

E-book

LCD Set set the system to play / stop mode, the screen saver

Language to set a different languages

Power off to set a countdown time (minutes), the time will

automatically shut down

Memory info Shows device information

Firmware version Display the firmware version of the player

(Exit) exit this interface

Page 5

Under the main menu, select E-Book by pressing the M button.

File select

zTest 3 . T XT

●Directory options: Select the root directory of the removable disk.

Short press Mode key to enter the "Select Directory" interface. Toggle the Next button or Last button to

select the directory where the files you want to read. Short press the Play button to open/access the

selected file.

This unit only supports “txt” files.

Using a USB disk

Connected to the PC: The player has three display modes

2. Downloading information

1. Waiting state

3. Uploading information

zDelete mode (Stop submenu)

In the music mode, playback mode , you can delete the corresponding files storage in the unit.

1. Stop interface 2. Short press Mode key to enter the

sub-menu

3. Toggle Next or Last button in the menu, and select

"Delete Files" or "delete all"

4. short press Mode button to enter into

delete interface

5. Struck the Next button "NO" to "YES"

6. Press the Mode key to confirm start

deleting

“Delete All”, the current directory under the current mode delete all the files (such as in the music mode only

can delete all music files, recording file is not deleted)

Delete a document or files on your computer, please be sure to safely eject the

player and then unplug the USB cable, otherwise the files are not deleted and the unit

can result damage.

Page 6

Play Mode (Play submenu)

REPEAT

(normal mode, Normal)

After the catalog of songs to play, continue to

play after a catalog of music, stop until

finished playing all the files.

(Repeat, Repeat One) repeatedly play a single music file

(Full circle, Repeat All) Repeatedly play all the music files

Repeat mode (Play submenu)

■enter through the Play submenu:

○A-B repeat

1. Music playback or playback player.

2 Press the Mode button to enter Play submenu.

3 toggle the Next button to select the "repeat mode" menu item.

4 Press the Mode button to enter the "repeat mode".

5 struck the Next button to determine the starting point A,.

Repeat the key icon in the "A" blinking, waiting to determine the starting point B

6. Toggle the Next button, to determine the starting point B.

The repeat icon is fixed. AB points played repeatedly to exit repeat mode, press the Next

button

Power / Charge

When the power is 3.8V, (Full battery charge) the power displays full. With the increase of use, the

battery indicator will be reduced.

When the power is almost completely run out, the power icon will show blank.

You must turn ON the power switch for charging. Otherwise, the player will not be able to respond to

the charge task.

CHARGING THE UNIT

This unit recharges the battery when connected to a USB port, the battery will be fully charged in around 4

hour.

It is recommended a longer period of time for the first charging, around 6 hours

Page 7

TechnicalSpecifications

Dimensions 84mm(L) * 35mm(W) * 12mm(H)

Weight 46.8g

Display dot-matrix (128 * 64),False OLED LCD display

Connected computer high-speed USB 2.0 (Read 1000K Byte, write 800K Byte)

Memory Flash Memory: 2GB-8GB

Power Power up to 6-8 hours playback time (Headphone)

Power up to 1-2 hours playback time (Speakers)

sampling rate 8KHz

Recording Format WAV（32K bps）、

Recording

Recording time 35Hrs,ACT，128M Flash）

headphone output （L）10mW＋（R）10mW（32Ohm）

MP3 bit rate 8K bps – 320K bps

WMA、WMV、ASF bit rate 5K bps – 384K bps

Frequency Response 20Hz to 20KHz

MP3、WMA、WMV、

ASF

Signal to noise ratio 80dB

receiver frequency range 76MHz – 90MHz / 87MHz – 108MHz

Storage units 20＋20

Maximum headphone output （L）10mW＋（R）10mW（32Ohm）

FM radio

Signal to noise ratio 45dB

Music formats MP3 / WMA

Use temperature -5 to 40 degrees Celsius

Sixteen States

appear in the

language

Simplified Chinese, English, Traditional Chinese, German, French, Italian,

Spanish,etc.

The operating

system

Windows98/SE/ME/2K/XP/Vista/Win7

Note: Product design and specifications are subject to change without notice.

For more information please check our website

www.mpmaneurope.com
