DRP/BXP/RKP Series Computers Linux

Installation Manual

Version 1.0, October 2023

www.moxa.com/products

DRP/BXP/RKP Series Computers Linux Installation Manual

The software described in this manual is furnished under a license agreement and may be used only in accordance

with the terms of that agreement.

Trademarks

The MOXA logo is a registered trademark of Moxa Inc.

All other trademarks or registered marks in this manual belong to their respective manufacturers.

Disclaimer

•Information in this document is subject to change without notice and does not represent a commitment

on the part of Moxa.

•Moxa provides this document as is, without warranty of any kind, either expressed or implied, including,

but not limited to, its particular purpose. Moxa reserves the right to make improvements and/or

changes to this manual, or to the products and/or the programs described in this manual, at any time.

•Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no

responsibility for its use, or for any infringements on the rights of third parties that may result from its

use.

•This product might include unintentional technical or typographical errors. Changes are periodically

made to the information herein to correct such errors, and these changes are incorporated into new

editions of the publication.

Technical Support Contact Information

www.moxa.com/support

Table of Contents

1. Moxa x86 Linux SDK .............................................................................................................................4

Introduction ..........................................................................................................................................4

Supported Series and Linux Distributions ..........................................................................................4

Prerequisites..................................................................................................................................4

The x86 Linux Installation Wizard ............................................................................................................4

Extracting the Installation Wizard Files..............................................................................................5

Installing the Linux Drivers .....................................................................................................................5

Checking the Installation Status .......................................................................................................6

Displaying the Help Page.................................................................................................................7

Displaying the Driver Version...........................................................................................................7

Using the --yes Option ....................................................................................................................7

Using the --dry-run Option ..............................................................................................................8

Uninstalling the Linux Drivers ..................................................................................................................9

Checking the Log file..............................................................................................................................9

Moxa x86 Peripherals Control Tools........................................................................................................ 10

mx-uart-ctl.................................................................................................................................. 10

mx-dio-ctl ................................................................................................................................... 11

DRP/BXP/RKP Series Computers Linux Installation Manual

1. Moxa x86 Linux SDK

Introduction

The Moxa x86 Linux SDK enables easy deployment of Linux on the RKP/BXP/DRP series x-86. The SDK

includes peripheral drivers, peripheral control tools, and configuration files. The SDK also provides

deployment functions such as build & installation log, dry-run, and self-test on target models.

Supported Series and Linux Distributions

Series Name

Debian 11

Ubuntu 22.04

RHEL 9

RKP-A110



RKP-C110



BXP-A100



BXP-C100



DRP-A100



DRP-C100



Prerequisites

•A system running Linux (Debian, Ubuntu, RedHat)

•Access to the terminal/command line

•A user account with sudo/root privileges

•The network settings configured before installation

The x86 Linux Installation Wizard

The x86 Linux SDK zip file consists of the following:

<wizard>.tgz - the tarball file of x86 Linux SDK Install Wizard

README.docx - this file in docx format

sources_list - the list of source of x86 Linux SDK Install Wizard

build_info - x86 Linux SDK build information

Support Models and Linux Distributions

Extract the files from the zip file. The installation wizard files are packaged in a tarball (*tgz) file.

DRP/BXP/RKP Series Computers Linux Installation Manual

Extracting the Installation Wizard Files

NOTE

The installation file should be extracted to a system running a Linux OS (Debian, Ubuntu, or RedHat)

environment.

Extract the wizard installation files from the tarball (*tgz) file.

tar xvf Moxa_x86_Linux_Install_Wizard_<ver>_Build_<build_date>.tgz

cd Moxa_x86_Linux_Install_Wizard_<ver>_Build_<build_date>

The x86 Linux Installation Wizard consists of the following directories and files:

product.d/ - congfiguration files for products

scripts/ - install wizard generic programs

src/ - source code for the drivers and tools

install.sh - entry program for build and install the SDK

README.md - this file: introduction and build instructions

CHANGELOG - change log and difference to the SDK release

LICENSE - MOXA license statement file

version - current version of x86 Linux Install Wizard

Installing the Linux Drivers

By default, the installation wizard installs the latest version. If you want to reinstall the current version or

install an older version, run install.sh with the --force option .

Command

./install.sh

NOTE

This command requires sudo or root privileges.

Result (E.g., RKP-A110)

[info] Product Name: RKPA110

[info] OS Name: Ubuntu

[info] OS Version: 22.04

[info] Kernel Info: Linux moxa 5.19.0-32-generic #33~22.04.1-Ubuntu SMP

PREEMPT_DYNAMIC Mon Jan 30 17:03:34 UTC 2 x86_64 x86_64 x86_64 GNU/Linux

Do you want to continue? [Y/n]y

[info] >>> Execute hook script "install-dev-tools.sh".

[info] <<< Execute hook script "install-dev-tools.sh" done.

[info] >>> Execute hook script "build-and-install-source.sh".

[info] === Run pre-install

[info] === Install driver

Do you want to install moxa-it87-gpio-driver (5.2+1.5.0-1)? [Y/n]y

[info] Installing moxa-it87-gpio-driver (5.2+1.5.0-1)

Do you want to install moxa-it87-wdt-driver (5.2+1.5.0-1)? [Y/n]y

[info] Installing moxa-it87-wdt-driver (5.2+1.5.0-1)

...

... (skip)

...

[info] Done. Please reboot machine for installation to take effect.

Do you want to reboot now? [Y/n]

DRP/BXP/RKP Series Computers Linux Installation Manual

A prompt asking if you want to reboot the system is displayed.

Do you want to reboot now? [Y/n]

Enter y, Y, or yes to reboot the system, or n, N, or no to exit the installation process.

Checking the Installation Status

To check the installation status of the driver, run install.sh with the --selftest option.

Command

./install.sh --selftest

Result (E.g., RKP-A110)

•Name: Driver or tool name

•Installed: Installation status of the driver or tool

Yes: The driver/tool is installed

No: The driver/tool is not installed

•Status: Shows the readiness of the installed driver or tool

Loaded: The driver is loaded

Active: The tool or service is active

•Version: The version of the driver or tool

[info] Product Name: RKPA110

[info] OS Name: Ubuntu

[info] OS Version: 22.04

[info] Kernel Info: Linux moxa 5.19.0-32-generic #33~22.04.1-Ubuntu SMP

PREEMPT_DYNAMIC Mon Jan 30 17:03:34 UTC 2 x86_64 x86_64 x86_64 GNU/Linux

[info] >>> Execute hook script "self-test.sh".

[info] ------------------------------------------------------------------------

---

[info] Name Installed Status Version

[info]

===========================================================================

[info] moxa-it87-gpio-driver 5.2+1.5.0-1

[info] - gpio_it87 Yes Loaded

[info] moxa-it87-wdt-driver 5.2+1.5.0-1

[info] - it87_wdt Yes Loaded

[info] - watchdog service Yes Active

[info] moxa-it87-serial-driver 1.4.1+u2

[info] - it87_serial Yes Loaded

[info] moxa-mxuport-driver

5.1.1_build_23080316

[info] - mxuport Yes Loaded

[info] moxa-x86-control-tools 1.8.1

[info] - mx-uart-ctl Yes 6 ports

[info] - mx-dio-ctl Yes 8 DI / 8 DO

[info] ------------------------------------------------------------------------

---

[info] <<< Execute hook script "self-test.sh" done.

DRP/BXP/RKP Series Computers Linux Installation Manual

Displaying the Help Page

Run the install.sh --help command to show the help page that contains a usage summary of all the

command options.

Command

./install.sh --help

Result

███╗ ███╗ ██████╗ ██╗ ██╗ █████╗

████╗ ████║██╔═══██╗╚██╗██╔╝██╔══██╗

██╔████╔██║██║ ██║ ╚███╔╝ ██║ ██║

██║╚██╔╝██║██║ ██║ ██╔██╗ ██║ ██║

██║ ╚═╝ ██║╚██████╔╝██╔╝ ██╗██║ ██║

╚═╝ ╚═╝ ╚═════╝ ╚═╝ ╚═╝╚═╝ ╚═╝

------------------------------------

X86 INSTALL WIZARD

Usage: install.sh [option]

Options:

-h, --help Display this help page

-y, --yes Automatically answer yes

-v, --version Display the version information

-s, --selftest Run the self test cases

--dry-run List available driver(s) and tool(s) only

--uninstall Uninstall driver(s) and tool(s)

--force Install driver and tool even if the

version is the same or older (default is

to install newer version)

Without passing any option, it would run the installation directly.

Displaying the Driver Version

Command

./install.sh --version

Expected result

1.0.0

Using the --yes Option

The --yes (alternatively, -y) option automatically returns yes at all prompts. It can be used with other

options as indicated below.

For example, assume “yes” as answer to all prompts during installation process.

./install.sh --yes

Assume “yes” as answer to all prompts during uninstallation process.

./install.sh --yes --uninstall

DRP/BXP/RKP Series Computers Linux Installation Manual

Using the --dry-run Option

The --dry-run option simulates the installation process to show what would be installed without installing

anything or making any changes to the system.

Command

./install.sh --dry-run

Result (E.g., RKP-A110)

•Name: Driver or tool name

•Version: The version of the driver or tool

•Tag: The tag name of the driver or tool in the Git repository

----------------------------------------------------------------------

Product Name: RKPA110

----------------------------------------------------------------------

Name Version Tag

======================================================================

moxa-it87-gpio-driver 5.2+1.5.0-1 master

moxa-it87-wdt-driver 5.2+1.5.0-1 5.2-master

moxa-it87-serial-driver 1.4.1+u2 master

moxa-mxuport-driver 5.1.1_build_23080316 5.x-

5.1.1_build_23080316-develop

moxa-x86-control-tools 1.8.1 master

----------------------------------------------------------------------

DRP/BXP/RKP Series Computers Linux Installation Manual

Uninstalling the Linux Drivers

Use the install.sh --uninstall command to unstill the drivers and tools.

Command

./install.sh --uninstall

NOTE

This command requires sudo or root privileges.

Expected result (RKP-A110)

[info] Product Name: RKPA110

[info] OS Name: Ubuntu

[info] OS Version: 22.04

[info] Kernel Info: Linux moxa 5.19.0-32-generic #33~22.04.1-Ubuntu SMP

PREEMPT_DYNAMIC Mon Jan 30 17:03:34 UTC 2 x86_64 x86_64 x86_64 GNU/Linux

Do you want to continue? [Y/n]y

[info] >>> Execute hook script "uninstall.sh".

[info] === Uninstall driver

Do you want to uninstall moxa-it87-gpio-driver (5.2+1.5.0-1)? [Y/n]y

[info] Uninstall moxa-it87-gpio-driver (5.2+1.5.0-1)

Do you want to uninstall moxa-it87-wdt-driver (5.2+1.5.0-1)? [Y/n]y

[info] Uninstall moxa-it87-wdt-driver (5.2+1.5.0-1)

[info] Remove Watchdog Service

Do you want to uninstall moxa-it87-serial-driver (1.4.1+u2)? [Y/n]y

[info] Uninstall moxa-it87-serial-driver (1.4.1+u2)

...

... (skip)

...

[info] <<< Execute hook script "uninstall.sh" done.

[info] Done. Please reboot machine for uninstallation to take effect.

Do you want to reboot now? [Y/n]

And finally, you’ll see a prompt asking if you want to reboot the system.

Do you want to reboot now? [Y/n]

Enter y, Y, or yes to reboot the system, or n, N, or no to exit out of uninstall process.

Checking the Log file

The installation log file install.log contains information on all events that have taken place during the

installation process. The file is in the same as the driver. Run the following command to access the log file.

Command

cat install.log

DRP/BXP/RKP Series Computers Linux Installation Manual

Moxa x86 Peripherals Control Tools

The Moxa x86 Linux SDK includes tools to manage the serial and the digital I/O ports of the supported

devices.

mx-uart-ctl

The serial port management tool mx-uart-ctl retrieves information on the serial ports of the computer

and sets the operating mode (RS-232/422/RS-485 2-wire/ RS-485 4-wire) for each port.

Supported Series

•BXP-A100

•BXP-C100

•RKP-A110

•RKP-C110

•DRP-A100

•DRP-C100

Usage

Usage:

mx-uart-ctl -p <port_number> [-m <uart_mode>]

OPTIONS:

-p <port_number>

Set target port.

-m <uart_mode>

Set target port to uart_mode

0 --> set to RS-232 mode

1 --> set to RS-485-2W mode

2 --> set to RS-422 mode

3 --> set to RS-485-4W mode

Example:

Get mode from port 0

# mx-uart-ctl -p 0

Set port 1 to mode RS232

# mx-uart-ctl -p 1 -m 0

Autres manuels pour DRP Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Moxa Technologies Ordinateur de bureau

Moxa Technologies

Moxa Technologies DA-662A Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MC-1100 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-2100-W Series Manuel utilisateur

Moxa Technologies

Moxa Technologies V2406C Series Instructions d'utilisation

Moxa Technologies

Moxa Technologies DA-682A-DPP Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MC-4510-C23 Manuel utilisateur

Moxa Technologies

Moxa Technologies MC-7400 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies EM-1240-LX Manuel utilisateur

Moxa Technologies

Moxa Technologies DA-720-C5-DPP Manuel utilisateur

Moxa Technologies

Moxa Technologies DA-681A Series Manuel utilisateur

Moxa Technologies

Moxa Technologies V2101 series Instructions d'utilisation

Moxa Technologies

Moxa Technologies EXPC-1519 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MC-3201 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies V2416 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-8112-ME-T Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MPC-2121 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies V2406C Series Manuel utilisateur

Moxa Technologies

Moxa Technologies ThinkCore V481 Instructions d'utilisation

Moxa Technologies

Moxa Technologies UC-8540 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies V2406-24I Series Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-7402-LX Plus Manuel utilisateur

Moxa Technologies

Moxa Technologies IA260 series Instructions d'utilisation

Moxa Technologies

Moxa Technologies MPC-2120 Series Instructions d'utilisation

Moxa Technologies

Moxa Technologies DA-710 Series. DA-710-XPE Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
