Mountain Buggy Urban Jungle Designer Manuel utilisateur

mountain

buggy®

life without limit

WARNINGS

Check you have the correct travel system for your carseat.

WARNINGS

Do not use this travel system until you have read and understood

the instructions!

WARNINGS

Never leave your child unattended.

WARNINGS

Do not use accessories not designed for your buggy as they may be unsafe.

WARNINGS

Do not leave your baby in carseat (on or oﬀ stroller) for long periods of time.

installation instructions

urban jungle™

universal travel system

mountain

buggy®

life without limit

For any assistance, please contact your nearest retailer listed at

www.mountainbuggy.com

Model MB1-CLIP1

Issue August 2009

Safety certiﬁed: ASTM F833-08

EN 1888:2005

AS/NZS 2088:2000

send 102-112 Daniell St, Newtown 6021, Wellington, New Zealand

ph +64 4 380 0833

fax +64 4 380 0137

Designed in New Zealand. Made in China.

FITTING TRAVEL SYSTEM TO BUGGY (continued)

3. Ensure fabric passes over and around frame tubes.

4. Open snap locks and press travel system onto frame directly above

bottom fasteners on side tubes.

5. Close both snap locks down ﬂat, making sure you hear the lock

“click indicating they are fully locked.

OPEN POSITION

30mm

Snap

Lock “CLICK”

CLOSED POSITION

Bottom

Fastener

IMPORTANT CHECKS

• Makesurebabyisharnessedintocarseatusingthemanufacturer’s

instructions.

• Whenttingcarseatontotravelsystem,ALWAYSkeepasteadyhand

on carseat and baby.

• Checktravelsystemisengagedcorrectlyontobuggyframeand

cannot move in any direction. (Refer back to installation instructions

to ensure positioning of snap locks are correct).

• Donotusetravelsystemifyouareunabletosecurecarseatortravel

system. In this case, contact your store/distributor where the buggy

was purchased from, for more help.

• Itisrecommendedthatyoupractisethefollowinginstructionswithout

baby in carseat.

PREPARING THE BUGGY

WARNINGS

ALWAYSputthebuggybrakeon.

Note: the sunhood and seat need to be removed from buggy before

ﬁtting travel system.

1. Temporarily remove sunhood.

2. Unfasten seat from frame along side tubes,

including straps at point A & B on both sides

of buggy, and strap underneath seat at point C.

3. Remove seat.

FITTING TRAVEL SYSTEM TO BUGGY

1. Attach the fasteners on travel system

fabric to fasteners on buggy frame at

points A,B,C & D.

2. Fasteners at A&B are above sunhood lug.

Fasteners C & D are below hinge joint.

FITTING CARSEAT ONTO

TRAVEL SYSTEM

1. Place carseat in travel system so that

baby faces buggy handle bar.

2. Pass wide straps around frame directly

below sunhood lugs and through slots

provided on each side of carseat.

(the slots are the same as used for

carseat belt).

3. Buckle wide strap across top of carseat

at point Z and tighten ﬁrmly by pulling

on free end of strap.

Sunhood Lug

Wide Strap

Sunhood

Lug

Hinge Joint

REMOVE CARSEAT FROM TRAVEL SYSTEM

1. Unbuckle travel system buckle and remove straps from slots on carseat.

2. Lift carseat oﬀ travel system.

REMOVE TRAVEL SYSTEM FROM BUGGY

1. Open two snap locks and take snap locks oﬀ frame tube.

2. Unfasten four fasteners on frame and lift travel system oﬀ buggy.
